Sparse RREF

(exact) Sparse Reduced Row Echelon Form (RREF) with row and column permutations in C++

---

Sparse Gaussian elimination is more an art than a science. -- Spasm (Charles Bouillaguet)

---

This header-only library intends to compute the exact RREF with row and column permutations of a sparse matrix over finite field or rational field, which is a common problem in linear algebra, and is widely used for number theory, cryptography, theoretical physics, etc.. The code is based on the FLINT library, which is a C library for number theory.

Some algorithms are inspired by Spasm, but we do not depend on it. The algorithm here is definite (Spasm is random), so once the parameters are given, the result is stable, which is important for some purposes.

License

The MIT License (MIT)

Dependence

The code mainly depends on FLINT to support arithmetic, and BS::thread_pool, wxf_parser and argparse (they are included) are also used to support thread pool, WXF format and parse args.

If one use functions on sparse_tensor, it also requires to link tbb (Threading Building Blocks) library (for GCC and CLANG), since the Parallel STL of C++20 is used there.

What to compute?

For a sparse matrix $M$, the code computes its RREF $\Lambda$ with row and column permutations. Instead of permute the row and column directly, we keep the row and column ordering of the matrix, i.e. the i-th row/column of $\Lambda$ is the i-th row/column of $M$, and the row and column permutation of this RREF is implicitly given by its pivots, which is a list of pairs of (row,col). In the ordering of pivots, the submatrix $\Lambda[\text{rows in pivots},\text{cols in pivots}]$ of $\Lambda$ is an identity matrix (if --no-backward-substitution is enabled, it is upper triangular).

How to compile the code

We now only support the rational field $\mathbb Q$ and the $\mathbb Z/p\mathbb Z$, where $p$ is a prime less than $2^{\texttt{BIT}-1}$ (it's $2^{63}$ on a 64-bit machine), but it is possible to generalize to other fields/rings by some small modification.

It is recommended to use mimalloc (or other similar library) to dynamically override the standard malloc, especially on Windows.

Example build commands (also add -lpthread if pthread is required by the compiler):

Standalone executable:

g++ main.cpp -o sparserref -O3 -std=c++20 -I$INCULDE -L$LIB -lflint -lgmp

Shared library for Wolfram LibraryLink API (used by Mathematica package SparseRREF.wl, see below):

g++ sprreflink.cpp -fPIC -shared -O3 -std=c++20 -o sprreflink.dll -I$MATHEMATICA_HOME/SystemFiles/IncludeFiles/C -I$INCLUDE -L$LIB -lflint -lgmp

where we assume that the FLINT library and GMP library are installed in $LIB, the header files are in $INCLUDE, and $MATHEMATICA_HOME/SystemFiles/IncludeFiles/C is the path of Mathematica C header files.

How to use the code

Standalone executable

The file main.cpp is an example to use the header-only library, the help is

Usage: SparseRREF [--help] [--version] [--output VAR]
                  [--kernel] [--method VAR] [--output-pivots]
                  [--field VAR] [--prime VAR] [--threads VAR]
                  [--verbose] [--print_step VAR]
                  [--no-backward-substitution]
                  input_file

(exact) Sparse Reduced Row Echelon Form v0.3.6

Positional arguments:
  input_file                       input file in the Matrix Market exchange formats (MTX) or
                                   Sparse/Symbolic Matrix Storage (SMS)

Optional arguments:
  -h, --help                       shows help message and exits
  -v, --version                    prints version information and exits
  -o, --output                     output file in MTX format [default: "<input_file>.rref"]
  -k, --kernel                     output the kernel (null vectors)
  -m, --method                     method of RREF  [default: 0]
  -op, --output-pivots             output pivots
  -F, --field                      QQ: rational field
                                   Zp or Fp: Z/p for a prime p [default: "QQ"]
  -p, --prime                      a prime number, only vaild when field is Zp  [default: "34534567"]
  -t, --threads                    the number of threads  [default: 1]
  -V, --verbose                    prints information of calculation
  -ps, --print_step                print step when --verbose is enabled [default: 100]
  -nb, --no-backward-substitution  no backward substitution

The format (matrix market-like format) of input file looks like this:

% some comments
number_of_rows number_of_columns number_of_non_zero_values
row_index_1 column_index_1 value_1
row_index_2 column_index_2 value_2
...
row_index_n column_index_n value_n

where the row and column indices are 1-based.

We also support the SMS format. It looks like this:

number_of_rows number_of_columns value_type
row_index_1 column_index_1 value_1
row_index_2 column_index_2 value_2
...
row_index_n column_index_n value_n
0 0 0

The last line is a dummy line, which is used to indicate the end of the matrix.

The main function is sparse_mat_rref, its output is its pivots, and it modifies the input matrix $M$ to its RREF $\Lambda$.

Mathematica API

The Mathematica package SparseRREF.wl allows to call functions exported in sprreflink.cpp:

Example usage:

Needs["SparseRREF`"];
(* or: Needs["SparseRREF`", "/path/to/SparseRREF.wl"]; *)

(* rationals *)
mat = SparseArray @ { {1, 0, 2}, {1/2, 1/3, 1/4} };
rref = SparseRREF[mat];
{rref, kernel, pivots} = SparseRREF[mat, "OutputMode" -> "RREF,Kernel,Pivots", "Method" -> "Right", "BackwardSubstitution" -> True, "Threads" -> $ProcessorCount, "Verbose" -> True, "PrintStep" -> 10];

(* integers mod p *)
mat = SparseArray @ { {10, 0, 20}, {30, 40, 50} };
p = 7;
{rref, kernel} = SparseRREF[mat, Modulus -> p, "OutputMode" -> "RREF,Kernel", "Method" -> "Hybrid", "Threads" -> 0];

To use this package, you have to compile sprreflink.cpp to a shared library (sprreflink.dll on Windows, sprreflink.so on Linux, sprreflink.dylib on macOS) in the same directory with SparseRREF.wl.

See comments in SparseRREF.wl for more details.

BenchMark

We compare it with Spasm. Platform and Configuration:

CPU: Intel(R) Core(TM) Ultra 9 185H (6P+8E+2LPE)
MEM: 24.5G + SWAP on PCIE4.0 SSD
OS: Arch Linux x86-64
Compiler: gcc (GCC) 15.2.1 20250813 with mimalloc
FLINT: v3.1.2
SparseRREF: v0.3.4
Prime number: 1073741827 ~ 2^30
Configuration:
  - Spasm: Default configuration for Spasm, first spasm_echelonize and then spasm_rref
  - SparseRREF: -V -t 16 -F Zp -p 1073741827

First two test matrices come from https://hpac.imag.fr, bs comes from symbol bootstrap, ibp comes from IBP of Feynman integrals:

| Matrix | (#row, #col, #non-zero-values, rank) | Spasm (echelonize + rref) | SparseRREF | | -------- | -------------------------------------- | ---------------------------- | ---------- | | GL7d24 | (21074, 105054, 593892, 18549) | 20.8001s + 38.2s | 2.93s | | M0,6-D10 | (1274688, 616320, 5342400, 493432) | 49.9s + 19.3s | 49.39s | | bs-1 | (202552, 64350, 11690309, 62130) | 4.19241s + 1.1s | 0.68s | | bs-2 | (709620, 732600, 48819232, 709620) | too slow | 149.68s | | bs-3 | (10011551, 2958306, 33896262, 2867955) | 484s + 327.1s | 34.00s | | ibp-1 | (69153, 73316, 1117324, 58252) | (rank is wrong) 2543.92s + ? | 2.96s | | ibp-2 | (169323, 161970, 2801475, 135009) | too slow | 15.27s |

Some tests for Spasm are slow since the physical memory is not enough, and it uses swap. In the most of cases, SparseRREF uses less memory than Spasm since its result has less non zero values.

TODO

• Add document.
• Improve the algorithms.
• Add PLUQ decomposition.
• Add more fields/rings.
• Add more functions and parameters to Mathematica API
