LOVELi (LÖVE Layout & GUI)

A LÖVE 2D retained mode layout and GUI library. Includes StackLayout, AbsoluteLayout, Grid and FlexLayout layouts. Includes Label, Button, ImageButton, Image, CheckBox, RadioButton, Switch, ProgressBar, Slider, TextBox, MaskedTextBox, Picker, Border, GraphicsView and ScrollView controls. This library was inspired by .NET's MAUI controls. Tested on version 11.5.

Control

Layout

Why?

I needed a simple way for creating game menus and overlays. Since I did not find any simple - yet complete - library, I've written my own.

How to

Copy LOVELi folder to your project.
Import the library and hook the following methods:

local loveli = require("LOVELi")
function love.load(arg)
  -- See below --
  layoutmanager = loveli.LayoutManager:new{}
    :with(rootcontrol)
end
function love.keypressed(key, scancode, isrepeat)
  layoutmanager:keypressed(key, scancode, isrepeat)
end
function love.textinput(text)
  layoutmanager:textinput(text)
end
function love.mousepressed(x, y, button, istouch, presses)
  layoutmanager:mousepressed(x, y, button, istouch, presses)
end
function love.mousereleased(x, y, button, istouch, presses)
	layoutmanager:mousereleased(x, y, button, istouch, presses)
end
function love.mousemoved(x, y, dx, dy, istouch)
  layoutmanager:mousemoved(x, y, dx, dy, istouch)
end
function love.wheelmoved(dx, dy)
  layoutmanager:wheelmoved(dx, dy)
end
function love.joystickhat(joystick, hat, direction)
  layoutmanager:joystickhat(joystick, hat, direction)
end
function love.joystickpressed(joystick, button)
  layoutmanager:joystickpressed(joystick, button)
end
function love.resize(w, h)
  layoutmanager:resize(w, h)
end
function love.update(dt)
  layoutmanager:update(dt)
end
function love.draw()
  layoutmanager:draw()
end

Layouts

Use one of the following layouts:

StackLayout

A StackLayout organizes elements in a one-dimensional stack, either horizontally or vertically.

local stacklayout = loveli.StackLayout:new{ orientation = "vertical", spacing = 5, width = "*", height = "*", margin = loveli.Thickness.parse(10) }
  :with(loveli.Button:new{ text = "Button 1", horizontaltextalignment = "start", verticaltextalignment = "center", width = 75, height = 23, horizontaloptions = "start" } )
  :with(loveli.Button:new{ text = "Button 2", horizontaltextalignment = "center", verticaltextalignment = "center", width = 75, height = "*", horizontaloptions = "center" } )
  :with(loveli.Button:new{ text = "Button 3", horizontaltextalignment = "end", verticaltextalignment = "center", width = 75, height = 23, horizontaloptions = "end" } )
local rootcontrol = stacklayout

AbsoluteLayout

An AbsoluteLayout is used to position and size elements using explicit values.

local absolutelayout = loveli.AbsoluteLayout:new{ width = 250, height = 250, margin = loveli.Thickness.parse(10) }
  :with(loveli.Button:new{ text = "Top Left", horizontaltextalignment = "center", verticaltextalignment = "center", x = 0, y = 0, width = 75, height = 23 } )
  :with(loveli.Button:new{ text = "Top Center", horizontaltextalignment = "center", verticaltextalignment = "center", x = 125 -38.5, y = 0, width = 75, height = 23 } )
  :with(loveli.Button:new{ text = "Top Right", horizontaltextalignment = "center", verticaltextalignment = "center", x = 250 -75, y = 0, width = 75, height = 23 } )
  :with(loveli.Button:new{ text = "Center Left", horizontaltextalignment = "center", verticaltextalignment = "center", x = 0, y = 125 -11.5, width = 75, height = 23 } )
  :with(loveli.Button:new{ text = "Center", horizontaltextalignment = "center", verticaltextalignment = "center", x = 125 -38.5, y = 125 -11.5, width = 75, height = 23 } )
  :with(loveli.Button:new{ text = "Center Right", horizontaltextalignment = "center", verticaltextalignment = "center", x = 250 -75, y = 125 -11.5, width = 75, height = 23 } )
  :with(loveli.Button:new{ text = "Bottom Left", horizontaltextalignment = "center", verticaltextalignment = "center", x = 0, y = 250 -23, width = 75, height = 23 } )
  :with(loveli.Button:new{ text = "Bottom Center", horizontaltextalignment = "center", verticaltextalignment = "center", x = 125 -38.5, y = 250 -23, width = 75, height = 23 } )
  :with(loveli.Button:new{ text = "Bottom Right", horizontaltextalignment = "center", verticaltextalignment = "center", x = 250 -75, y = 250 -23, width = 75, height = 23 } )
local rootcontrol = absolutelayout

Grid

A Grid is used for displaying elements in rows and columns, which can have proportional or absolute sizes.

local grid = loveli.Grid:new{ rowdefinitions = { "auto", "1*", "1*" }, columndefinitions = { "auto", "1*", 150 }, width = "*", height = "*", margin = loveli.Thickness.parse(10) }
  :with(1, 1, absolutelayout)
  :with(2, 2, stacklayout)
local rootcontrol = grid

FlexLayout

FlexLayout is a layout that can arrange its children horizontally and vertically in a stack, and can also wrap its children if there are too many to fit in a single row or column. In addition, FlexLayout can control orientation and alignment, and adapt to different screen sizes.

local flexlayout = loveli.FlexLayout:new{ direction = "row", justifycontent = "spaceevenly", aligncontent = "center", width = 300, height = 100, verticaloptions = "center", horizontaloptions = "center", margin = loveli.Thickness.parse(10) }
  :with(loveli.Button:new{ text = "Button 1", width = 75, height = 23 } )
  :with(loveli.Button:new{ text = "Button 2", width = 75, height = 23, margin = loveli.Thickness.parse(10)  } )
  :with(loveli.Button:new{ text = "Button 3", width = 75, height = 23, verticaloptions = "start" } )
  :with(loveli.Button:new{ text = "Button 4", width = 75, height = 23 } )
  :with(loveli.Button:new{ text = "Button 5", width = 75, height = 23 } )
local rootcontrol = flexlayout

Controls

And the following controls:

Label

Label displays single, or multiple, lines of text.

loveli.Label:new{ text = "Label" }

Button

Button displays text and responds to a tap or click that directs an app to carry out a task.

loveli.Button:new{
  text = "Button",
  clicked = function(sender) end,
  -- Default values for text controls:
    ismultiline = false,
    font = love.graphics.getFont(),
    horizontaltextalignment = "center",
    verticaltextalignment = "center",
    textcolor = loveli.Color.parse(0x000000FF),
  -- Default values for style:
    backgroundcolor = loveli.Color.parse(0xC0C0C0FF),
    bordercolor = loveli.Color.parse(0xFFFFFFFF),
  -- Default values for size and position:
    x = 0,
    y = 0,
    width = "auto",
    height = "auto",
    minwidth = 0,
    minheight = math.huge,
    maxwidth = 0,
    maxheight = math.huge,
    margin = loveli.Thickness.parse(0),
    horizontaloptions = "start",
    verticaloptions = "start",
  -- Default values for all controls:
    name = nil,
    isvisible = true,
    isenabled = true
}

ImageButton

ImageButton view combines the Button view and Image view to create a button whose content is an image.

loveli.ImageButton:new{ source = "icon.png", aspect = "aspectfit", width = 64, height = 32, clicked = function(sender) end }


Image displays an image that can be loaded from a local file.

loveli.Image:new{ source = "icon.png", aspect = "aspectfit", width = 64, height = 32 }

CheckBox

CheckBox enables you to select a boolean value using a type of button that can either be checked or empty.

loveli.CheckBox:new{ ischecked = false, checkedchanging = function(sender, oldvalue, newvalue) return true end, checkedchanged = function(sender, oldvalue, newvalue) end }

RadioButton

RadioButton is a type of button that allows the selection of one option from a set.

loveli.RadioButton:new{ ischecked = false, groupname = "1", checkedchanging = function(sender, oldvalue, newvalue) return true end, checkedchanged = function(sender, oldvalue, newvalue) end }

Switch

Switch enables you to select a boolean value using a type of button that can either be on or off.

loveli.Switch:new{ istoggled = false, toggling = function(sender, oldvalue, newvalue) return true end, toggled = function(sender, oldvalue, newvalue) end }

ProgressBar

ProgressBar uses an animation to show that the app is progressing through a lengthy activity.

loveli.ProgressBar:new{ progress = 0.75 }

Slider

Slider enables you to select a value from a range.

loveli.Slider:new{ value = 5, minimum = 0, maximum = 10, valuechanging = function(sender, oldvalue, newvalue) return true end, valuechanged = function(sender, oldvalue, newvalue) end }

TextBox

TextBox enables you to enter and edit a single, or multiple, lines of text.

local textbox = loveli.TextBox:new{ text = "TextBox", ispassword = false, maxlength = 255, textchanging = function(sender, oldvalue, newvalue) return true end, textchanged = function(sender, oldtext, newtext) end }

MaskedTextBox

local maskedtextbox = loveli.MaskedTextBox:new{ mask = "(000) 000-0000", patterns = { ["0"] = { pattern = "%d" } }, textchanging = function(sender, oldvalue, newvalue) return true end, textchanged = function(sender, oldtext, newtext) end }

Picker

Picker displays a short list of items, from which the user can select an item.

local picker = loveli.Picker:new{ selectedindexchanged = function(sender, oldindex, newindex) print(oldindex, newindex) end, itemssource = { "Option 1", "Option 2", "Option 3", "Option 4", { tostring = function(self) return "Option 5" end } }, text = "Select...", width = 100, height = "auto" } )

Border

Border is a container control that adds padding, draws a border, background, or both, around another control.

local border = loveli.Border:new{ padding = loveli.Thickness.parse(10)
