Overview

Minimalistic Javascript implementation of a chess board UI.

It just provides an API to visualize a chess board. If you are after validating chess rules, consider using chess.js.

Dependencies

None! (doesn't require jQuery)

Supported browsers/platforms

• Latest Chrome
• Latest Firefox
• Latest Safari
• PhoneGap

How to use

1. Include chessboard.css and chessboard.js, and make sure that chesspieces.png is in the same location as chessboard.css.

2. Add a board element in your HTML, e.g.: <div id="myBoard"></div>

3. Initialize the chess board: var board = new ChessBoard('myBoard', options), where options is an object.

Options

fen (string)

Defines the initial position on the board. Defaults to the initial chess position.

orientation (string)

Defined the orientation of the board. Should be 'w' or 'b'. Defaults to 'w'.

resize (boolean)

Whether the board will be resizable automatically on window resize. Defaults to true.

onSquareClick (function)

Function that will be called when square is clicked. This function will have the following arguments:

1. clickedSquare - The clicked square (e.g. 'a4', 'h7')
2. selectedSquares - Array of squares that were selected prior to click (e.g. [], ['a7'], ['e2', 'e4'])

API

selectSquare(square)

Selects the given square by adding the 'selected' class to it. Does nothing if the given square was already selected.

Example

board.selectSquare('e6');

unselectSquare(square)

Unselects the given square by removing the 'selected' class from it. Does nothing if the given square wasn't selected.

Example

board.unselectSquare('e6');

unselectAllSquares()

Unselects all the selected squares by removing the 'selected' class from them.

Example

board.unselectAllSquares();

setPosition(fenString)

Sets the given position. fenString must be in one of the following formats:

• rnbqkbnr/pppppppp/8/8/8/8/PPPPPPPP/RNBQKBNR w KQkq - 0 1
• rnbqkbnr/pppppppp/8/8/8/8/PPPPPPPP/RNBQKBNR

askPromotion(color, callback)

Presents a small dialog asking the user to choose a promotion piece (of a specified color, 'w' or 'b'). User has to click on a piece, and then on the "Promote" button, in order to close the dialog.

If a callback function is specified, it is will be called once the dialog is closed, and will have the following argument:

• shortPiece - The selected piece in the following format: 'q', 'r', 'n', 'b'. It can be useful when integrating with other libraries such as chess.js (see the promotion option in move()).

Example

board.askPromotion('w', function(shortPiece) {
  // Now we know which piece user selected.
});
