qSticky

qSticky is an automated port forwarding manager for Gluetun and qBittorrent. It automatically updates qBittorrent's listening port whenever Gluetun receives a new forwarded port.

[!IMPORTANT]
Gluetun v3.40.1+ API Change: qSticky now uses Gluetun's new API endpoints (/v1/portforward, /v1/vpn/status). If you're upgrading from an older version or experiencing 401 errors, you'll need to update your config.toml authentication file. See the Authentication Setup section below for the updated configuration.

How it Works

qSticky monitors Gluetun's port forwarding through its control server API and updates qBittorrent's connection settings as needed.

Port Monitoring

• Queries Gluetun's control server API endpoint at /v1/portforward (Gluetun v3.39.0+)
• Supports both Basic Auth and API Key authentication methods
• Polls the API at configurable intervals (default: 30 seconds)

Port Management When a new port is detected, qSticky retrieves the port number from Gluetun's API, connects to qBittorrent's WebUI API, updates qBittorrent's listening port, and verifies the change was successful.

Health Monitoring qSticky maintains a health status file, checks qBittorrent connectivity regularly, tracks port changes and any errors, and provides Docker health checks.

Recovery The application automatically retries on connection failures, maintains session with qBittorrent, handles network interruptions gracefully, and logs important events and errors.

Flow

graph TD;
    A[Gluetun Control Server] -->|API Poll| B[qSticky];
    B -->|Port Update| C[qBittorrent];
    B -->|Status Write| D[Health Monitor];

Quick Start

[!IMPORTANT]
qSticky only supports VPN providers with native port forwarding integration in Gluetun. Currently supported providers: Private Internet Access (PIA), ProtonVPN, Perfect Privacy, and PrivateVPN. I recommend using ProtonVPN and my shill link is here.

Authentication Setup

[!IMPORTANT] 401 Error in qSticky logs? You need to update your Gluetun config.toml file to include the new API endpoints. Follow the configuration examples below to fix authentication issues with Gluetun v3.39.0+.

qSticky requires access to Gluetun's control server API to monitor port forwarding. You need to configure this one of two ways:

[!NOTE]
Authentication is required for qSticky to function. No unauthenticated access is supported, as Gluetun is deprecating unauthenticated endpoints.

Create Authentication Config

Create a config.toml file somewhere to be mapped into gluetun:

[[roles]]
name = "qSticky"
routes = [
    "GET /v1/portforward",
    "GET /v1/vpn/status"
]
auth = "apikey"
apikey = "your_api_key_here"

Or if you prefer basic auth:

[[roles]]
name = "qSticky"
routes = [
    "GET /v1/portforward",
    "GET /v1/vpn/status"
]
auth = "basic"
username = "myusername"
password = "mypassword"

[!NOTE] /v1/portforward is required for dynamic port mapping, and /v1/vpn/status is required for Gluetun's health status checks.

Volume mount

Mount the config in your docker-compose.yml:

services:
  gluetun:
    # ... other gluetun config ...
    volumes:
      - ./gluetun/config.toml:/gluetun/auth/config.toml  # Mount auth config

qSticky Configuration

Configure qSticky to use the same authentication method:

services:
  qSticky:
    # ... other qSticky config ...
    environment:
      # For API Key auth:
      GLUETUN_AUTH_TYPE: apikey
      GLUETUN_APIKEY: your_api_key_here

      # Or for Basic auth:
      # GLUETUN_AUTH_TYPE: basic
      # GLUETUN_USERNAME: myusername
      # GLUETUN_PASSWORD: mypassword

For complete details on Gluetun's control server authentication, check out the official Gluetun documentation.

Gluetun Setup

Gluetun setup is straightforward. If you're already using it you may just need to add some environment variables:

To set up port forwarding:

1. Enable port forwarding in Gluetun by setting VPN_PORT_FORWARDING=on
2. Enable Gluetun's control server with GLUETUN_HTTP_CONTROL_SERVER_ENABLE=on
3. Configure authentication (API key or Basic Auth)
4. Ensure qSticky has network access to Gluetun's control server

A working Gluetun configuration might look like:

services:
  gluetun:
    image: qmcgaw/gluetun:latest
    container_name: gluetun
    environment:
      VPN_SERVICE_PROVIDER: protonvpn
      VPN_TYPE: wireguard
      VPN_PORT_FORWARDING: on
      GLUETUN_HTTP_CONTROL_SERVER_ENABLE: on
      WIREGUARD_PRIVATE_KEY: 'YOURKEY'
      SERVER_COUNTRIES: Netherlands
    volumes:
      - ./gluetun/config.toml:/gluetun/auth/config.toml

[!NOTE]
Since we are using docker compose networking, port 8000 does not need to be explicitly mapped in docker. If you wish to use the API outside of the docker network, you should map the port.

qSticky Setup

[!TIP] A full list of environment variables are listed and explained below.

To deploy qSticky, add the service to your compose file as so, changing settings as required:

services:
  qsticky:
    image: ghcr.io/monstermuffin/qsticky:latest
    container_name: qsticky
    environment:
      # qbittorrent settings
      QBITTORRENT_HOST: gluetun
      QBITTORRENT_HTTPS: false
      QBITTORRENT_PORT: 8080
      QBITTORRENT_USER: admin
      QBITTORRENT_PASS: adminadmin
      # gluetun settings
      GLUETUN_HOST: gluetun
      GLUETUN_AUTH_TYPE: apikey
      GLUETUN_APIKEY: your_api_key_here
      # qSticky settings
      LOG_LEVEL: INFO
    healthcheck:
      test: ["CMD", "python3", "-c", "import json; exit(0 if json.load(open('/app/health/status.json'))['healthy'] else 1)"]
      interval: 30s
      timeout: 10s
      retries: 3
    restart: always

[!NOTE]
Put qSticky in the same network as gluetun and your host for both gluetun and qBittorrent will be gluetun. It is adviced to do this as container:gluetun will break the network stack on gluetun restarts.

[!NOTE]
HTTPS and SSL Certificates: When using QBITTORRENT_HTTPS: true, qSticky defaults to accepting self-signed certificates (QBITTORRENT_VERIFY_SSL: false). Set QBITTORRENT_VERIFY_SSL: true if you want strict SSL certificate verification.

qBittorrent Setup

qBittorrent can be deployed like the following example:

services:
  qbittorrent:
    container_name: qbittorrent
    image: linuxserver/qbittorrent:latest
    network_mode: container:gluetun
    environment:
      PUID: 1000
      PGID: 1000
      TZ: UTC
      WEBUI_PORT: 8080
    volumes:
      - ./qbittorrent/config:/config
      - ./downloads:/downloads
    restart: always
    healthcheck:
      test: ["CMD-SHELL", "curl -sf https://api.ipify.org || exit 1"]
      interval: 30s
      timeout: 10s
      retries: 3
    depends_on:
      - gluetun

[!NOTE] I use the above healthcheck to ensure qbittorrent is working. If that check fails, it means qbittorrent can't get out of gluetun's network and marks the container as unhealthy.

Full Stack Example

Here is a complete example stack for deploying Gluetun, qBittorrent and qSticky:

services:
  gluetun:
    container_name: gluetun
    image: qmcgaw/gluetun:latest
    cap_add:
      - NET_ADMIN
    devices:
      - /dev/net/tun:/dev/net/tun
    environment:
      VPN_SERVICE_PROVIDER: protonvpn
      VPN_TYPE: wireguard
      VPN_PORT_FORWARDING: on
      WIREGUARD_PRIVATE_KEY: 'YOURKEY'
      WIREGUARD_ADDRESSES: 'IP'
      SERVER_COUNTRIES: Netherlands
      GLUETUN_HTTP_CONTROL_SERVER_ENABLE: on
    volumes:
      - ./gluetun/config.toml:/gluetun/auth/config.toml
    ports:
      - 8080:8080  # qBittorrent WebUI
    restart: always

  qbittorrent:
    container_name: qbittorrent
    image: linuxserver/qbittorrent:latest
    network_mode: container:gluetun
    environment:
      PUID: 1000
      PGID: 1000
      TZ: UTC
      WEBUI_PORT: 8080
    volumes:
      - ./qbittorrent/config:/config
      - ./downloads:/downloads
    healthcheck:
      test: ["CMD-SHELL", "curl -sf https://api.ipify.org || exit 1"]
      interval: 30s
      timeout: 10s
      retries: 3
    restart: always
    depends_on:
      - gluetun

  qsticky:
    image: ghcr.io/monstermuffin/qsticky:latest
    container_name: qsticky
    environment:
      # qbittorrent settings
      QBITTORRENT_HOST: gluetun
      QBITTORRENT_HTTPS: false
      QBITTORRENT_PORT: 8080
      QBITTORRENT_USER: admin
      QBITTORRENT_PASS: 'YOURPASS'
      # gluetun settings
      GLUETUN_HOST: gluetun
      GLUETUN_AUTH_TYPE: apikey
      GLUETUN_APIKEY: 'YOURAPIKEY'
      # qSticky settings
      LOG_LEVEL: INFO
    healthcheck:
      test: ["CMD", "python3", "-c", "import json; exit(0 if json.load(open('/app/health/status.json'))['healthy'] else 1)"]
      interval: 30s
      timeout: 10s
      retries: 3
    restart: always

Configuration

All configuration is done through environment variables:

| Environment Variable | Description | Default | |---------------------|-------------|---------| | QBITTORRENT_HOST | qBittorrent server hostname | gluetun | | QBITTORRENT_PORT | qBittorrent server port | 8080 | | QBITTORRENT_USER | qBittorrent username | admin | | QBITTORRENT_PASS | qBittorrent password | adminadmin | | QBITTORRENT_HTTPS | Use HTTPS for qBittorrent connection | false | | QBITTORRENT_VERIFY_SSL | Verify SSL certificates for HTTPS connections | false | | CHECK_INTERVAL | API check interval in seconds | 30 | | LOG_LEVEL | Logging level (DEBUG, INFO, ERROR, WARNING) |
