NuSock

NuSock is a lightweight, high-performance WebSocket library designed for embedded systems. It bridges the gap between ease of use and raw performance by offering a Dual-Mode Architecture (Generic vs LwIP) and Secure WebSocket (WSS) support.

It features a Zero-Interrupt Architecture for Generic mode, ensuring stability on UART-based WiFi modules like the Arduino UNO R4 WiFi, Nano 33 IoT, Portenta C33, and Uno WiFi Rev2.

📑 Table of Contents

Features
Supported Platforms
Installation
Configuration Macros
RFC 6455 Compliance
Usage Guide
Advanced Features
- Sending Fragmented Data
- Graceful Disconnect
License

🚀 Features

🔒 Secure WebSockets (WSS):
- ESP32: Native, high-performance WSS Server and Client using the internal esp_tls stack.
- ESP8266 / Pico W: WSS Server/Client support via WiFiServerSecure / WiFiClientSecure wrapping.
⚡ Dual-Mode Architecture:
- Generic Mode: Maximum compatibility using standard WiFiServer / WiFiClient wrapping. Supports accept() logic for robust connection handling on newer boards.
- LwIP Mode: High-performance, low-overhead mode using native LwIP callbacks (ESP32/ESP8266).
📜 RFC 6455 Compliance:
- Fragmentation: Supports sending and receiving large messages via streaming fragments.
- Close Handshake: Supports graceful shutdowns with status codes and reasoning.
- Strict Mode: Optional strict UTF-8 validation and Masking enforcement for enterprise environments.
🛡️ Robust Stability:
- Zero-Interrupt Locking: Prevents UART deadlocks on Arduino Uno R4 WiFi, Nano 33 IoT, Portenta C33, and Uno WiFi Rev2.
- Smart Duplicate Detection: Automatically handles and cleans up duplicate socket handles returned by underlying WiFi libraries.
📨 Event-Driven: Non-blocking, callback-based architecture for handling Connect, Disconnect, Text, Binary, and Fragment events.

📦 Supported Platforms

| Platform | WS Server | WSS Server | WS Client | WSS Client | Mode | | :--- | :---: | :---: | :---: | :---: | :--- | | ESP32 | ✅ | ✅ | ✅ | ✅ | LwIP / Generic | | ESP8266 | ✅ | ✅ | ✅ | ✅ | LwIP / Generic | | RP2040 (Pico W) | ✅ | ✅ | ✅ | ✅ | Generic | | Arduino UNO R4 WiFi | ✅ | ❌ | ✅ | ✅ | Generic | | Portenta / Giga / Opta | ✅ | ❌ | ✅ | ✅ | Generic | | Arduino UNO WiFi Rev2 | ✅ | ❌ | ✅ | ✅ | Generic | | SAMD (MKR / Nano 33)| ✅ | ❌ | ✅ | ✅ | Generic | | Teensy 3.2 - 4.1 | ✅ | ❌ | ✅ | ✅ | Generic | | STM32| ✅ | ❌ | ✅ | ✅ | Generic | | AVR| ✅ | ❌ | ✅ | ✅ | Generic |

📝 Platform Notes

ESP8266 / Pico W:
- WSS Server requires passing a WiFiServerSecure instance to begin().
Arduino Pro (Portenta/Giga/Opta):
- Portenta C33: Uses WiFiC3.h.
- Portenta H7 / Giga R1 / Opta: Use the mbed-native WiFi.h.
Arduino R4 / SAMD / AVR:
- WS Server requires passing a WiFiServer instance.
- WSS Client requires Root CA certificates to be uploaded via the Firmware Updater tool where applicable.
STM32 / AVR (Ethernet): * Requires passing EthernetClient or EthernetServer instances.

📦 Installation

Option 1: Arduino IDE

Navigate to Sketch → Include Library → Manage Libraries...
Search for NuSock.
Click Install.

Option 2: PlatformIO

Add the following to your platformio.ini:

lib_deps =
    suwatchai/NuSock

⚙️ Configuration Macros

Define these macros before including NuSock.h to enable specific modes.

📜 RFC 6455 Compliance Macros

Use these to enable strict protocol features.

📖 Usage Guide

1. Secure WebSocket Server (WSS) [ESP32 Native]

ESP32 uses the native NuSockServerSecure class for optimal performance without relying on WiFiClientSecure.

#define NUSOCK_USE_SERVER_SECURE
#include <WiFi.h>
#include "NuSock.h"

// Certificates (Generate using keygen.py)
const char* server_cert = "-----BEGIN CERTIFICATE-----\n...";
const char* server_key = "-----BEGIN PRIVATE KEY-----\n...";

NuSockServerSecure wss;

void setup() {
    WiFi.begin("SSID", "PASS");
    // wait for connection

    wss.onEvent(onEvent); // Define callback
    wss.begin(443, server_cert, server_key);
}

void loop() {
    wss.loop();
}

2. Standard Server (ESP32/ESP8266 - LwIP Mode)

Ideal for high-performance non-SSL applications.

#define NUSOCK_SERVER_USE_LWIP
#include <WiFi.h> // or ESP8266WiFi.h
#include "NuSock.h"

NuSockServer ws;

void setup() {
    WiFi.begin("SSID", "PASS");
    // wait

    ws.onEvent(onEvent);
    ws.begin(80); // Internal LwIP server created automatically
}

void loop() {
    ws.loop();
}

3. Standard Server (Uno R4 / Portenta / Giga / MKR - Generic Mode)

Compatible with Arduino Uno R4 WiFi, Portenta C33/H7, Giga R1, Nano 33 IoT, MKR 1010, Uno WiFi Rev2, etc. NuSock wraps the existing WiFiServer object.

// Select the correct library for your board:
#if defined(ARDUINO_UNOR4_WIFI)
  #include <WiFiS3.h>
#elif defined(ARDUINO_PORTENTA_C33)
  #include <WiFiC3.h>
#elif defined(ARDUINO_PORTENTA_H7_M7) || defined(ARDUINO_GIGA)
  #include <WiFi.h>
#else
  #include <WiFiNINA.h> // Nano 33 IoT, MKR 1010, Vidor 4000, Uno WiFi Rev2
#endif

#include "NuSock.h"

// 1. Create the standard WiFiServer
WiFiServer server(80);
NuSockServer ws;

void setup() {
    WiFi.begin("SSID", "PASS");
    // wait

    // Start the underlying server
    server.begin();

    // Bind NuSock to it
    ws.onEvent(onEvent);
    ws.begin(&server, 80);
}

void loop() {
    ws.loop();
}

4. Secure WebSocket Client (WSS) [ESP32 Native]

ESP32 can use NuSockClientSecure which uses the native esp_tls stack for high performance.

#include <WiFi.h>
#include "NuSock.h"

NuSockClientSecure client;

void setup() {
    WiFi.begin("SSID", "PASS");
    // wait

    // Set custom CA if needed, otherwise uses built-in bundle
    // client.setCACert(root_ca);

    client.onEvent(onEvent);
    client.begin("echo.websocket.org", 443, "/");
    client.connect();
}

void loop() {
    client.loop();
}

5. Generic WebSocket Client (WS/WSS)

Compatible with WiFiClient, WiFiClientSecure, or EthernetClient. Works on all platforms (Uno R4, Portenta, Giga, MKR, ESP8266, Rev2, etc.).

#include <WiFiClientSecure.h>
#include "NuSock.h"

WiFiClientSecure secureClient;
NuSockClient client;

void setup() {
    secureClient.setInsecure(); // Allow self-signed certs (if needed)

    client.begin(&secureClient, "example.com", 443, "/ws");
    client.connect();
}

void loop() {
    client.loop();
}

🛠 Advanced Features

Sending Fragmented Data (Streaming)

You can send large files or data streams by breaking them into chunks.

Server Example:

// 1. Start the stream (isBinary = true)
ws.sendFragmentStart(clientIndex, buffer, len, true);

// 2. Send middle chunks (Loop)
ws.sendFragmentCont(clientIndex, buffer, len);

// 3. Finish the stream
ws.sendFragmentFin(clientIndex, buffer, len);

See Example: examples/Features/Fragmented_File_Send

Client Example:

See Example: examples/Features/Fragmented_File_Receive

Graceful Disconnect (Close Handshake)

Initiate a clean disconnect compliant with RFC 6455 by sending a status code and reason.

// Server: Close specific client with code 1001 (Going Away)
ws.close(clientIndex, 1001, "Server Shutting Down");

// Client: Close connection with code 1000 (Normal)
client.close(1000, "Job Done");

📄 License

MIT License
