esp32Micronet
This project communicates with Tacktick/Raymarine Micronet devices using an ESP32 coupled with a CC1000 or CC1101 radio module. It is capable of sending and receiving data as well as hosting the network or joining as a node. If you add a CAN bus transceiver module it is capable of bridging the Micronet to a NMEA2000 network. Also included is code to read data from an analog AIRMAR ST850-P17 speed transducer and Raymarine masthead wind transducer.
It is rough and needs a lot of testing but functional.
What it does:
• Can use either a CC1000 or CC1101 radio chip.
• Can connect to a Micronet as either a node or host its own network.
• Uses proper window timing for all 4 known network round robins.
• Can send and receive all known data PIDs including node info (it identifies as a type 8 device in settings->health).
• Handles enough command packets to not get booted off the network.
• Handles 0x0A/0x0B device status packets.
• Handles remote shutdown messages.
• Monitors NMEA2k network for PIDs the network can display and forwards them to the Micronet.
• Monitors Micronet for PIDs the NMEA2k network can use and forwards them.
• Can dump packets and monitor other networks.
• Scrolling waypoint names on Dual Displays.
Known issues:
• The CC1101's settings are not completely correct for communicating with the older CC1000 radios. This limits range to about half.
• Settings are hardcoded and should be moved to flash.
• A lot of the N2k < Micronet bridge is untested as I don't have the right equipment.
• There's a few areas in the Micronet class that need to be made thread safe (data structs)
• Tons of fixme's.
Needed libraries
For CC1101
-SPI
For N2kbridge
-NMEA2000 (https://github.com/ttlappalainen/NMEA2000)
For transducers
-RunningAngle (https://github.com/RobTillaart/runningAngle)
-RunningAverage (https://github.com/RobTillaart/RunningAverage)
Quick start guide
Download the project and either comment out the parts you'll not be using (transducers and/or bridge) or download the needed libraries for them.
Open radio.h and select which radio you'll be using, the pins it is connected to, the frequincy your gear uses, desired power level and your network's ID if you know it.
Compile, upload and hopefully you'll start seeing packets from your network. If so you can get its ID and update radio.h.
Wiring
Most pins on the esp32 can be used but I'd stay away from 0, 1, 3, and 6 - 12 because they can interfere with the boot process. This is how I've wired my project.

A word on CC1101 modules
There's a few different CC1101 modules available and the quality of the boards varies greatly. I had to buy three different modules before finding one that output a decent signal. If you’re having range issues try testing your module with a rtl-sdr dongle to see if it’s putting out a strong clean signal. If you're buying a new module I'd suggest one of the red board ones with a 1x8 pin header.
NMEA2000 Message information
esp32Micronet will receive the following messages:
PGN59392
PGN59904
PGN60928
PGN65240
PGN126208
PGN126464
PGN126993
PGN126996
PGN126998
PGN128259
PGN128275
PGN130310
PGN128267
PGN130306
PGN127250
PGN129026
PGN129029
PGN129284
PGN129285
PGN129283
PGN127508
PGN129033
PGN126992
esp32Micronet can transmit the following messages:
PGN59392
PGN59904
PGN60928
PGN65240
PGN126208
PGN126464
PGN126993
PGN126996
PGN126998
PGN126992
PGN127250
PGN127506
PGN127513
PGN128259
PGN128267
PGN128275
PGN129025
PGN129026
PGN129029
PGN129033
PGN129283
PGN129284
PGN129285
PGN130306
PGN130310
Reverse Engineering Micronet
The bulk of what I know of the Micronet protocol can be found in Micronet.h. Included in the project are logic analyzer captures of the hull transmitter's mcu and cc1000 radio chip (backwards_engineering_data), timing logs (backwards_engineering_data) and the code to test timing (old_code).
These notes are chaotic.
Some info maybe old or wrong.
Abandon all hope.
(if you want to organize this go for it)
Basic time specs.
13.02 us per bit
104.17 us per byte
1771 us for 17 bytes (standard preamble)
Max packet size: 200
Max nodes: 32
NW = Network Id
DI = Device Id
UK = Unknown, believed to be a reciever mask or sender status bits.
NQ = Network quality (RSSI) for responce packets. 0-9 scale, 0 being didn't recieve the packet, 9 being strongest RSSI.
CS = Checksum. Previous bytes added togeather from the last checksum limited to one byte.
LN = Total packet length minus the LN fields.
0x01 Network synchronization packet.
-First ring.
NW NW NW NW DI DI DI DI *01* UK NQ CS LN CS *81 00 01 00 00 00 00 12*
0x02 Data packet.
-Second ring.
NW NW NW NW DI DI DI DI *02* UK NQ CS LN CS *04 04 05 13 89 A9 04 1B 05 00 78 9C*
0x03 Add transmit slot packet.
-Third ring.
-Can and does collide with other third ring packets.
NW NW NW NW DI DI DI DI *03* UK NQ CS LN CS *00 1A 1A*
0x04 Remove transmit slot packet.
-Third ring.
NW NW NW NW DI DI DI DI *04* UK NQ CS LN CS
0x05 Adjust transmit slot packet.
-Third ring.
NW NW NW NW DI DI DI DI *05* UK NQ CS LN CS *1A 1A*
0x06 Command packet.
-Third ring.
-Every node should reply with an 0x07. If not the node keeps sending the 0x06 for 5 times.
-Only one command packet can be handled a round.
NW NW NW NW DI DI DI DI *06* UK NQ CS LN CS *E5 00 10 F5*
0x07 Announcement/Ack.
-Forth ring.
-Forth ring runs backwards.
NW NW NW NW DI DI DI DI *07* UK NQ CS LN CS
0x08 Node leaving network.
-Third ring? (verify me pls)
NW NW NW NW DI DI DI DI *08* UK NQ CS LN CS
0x09 Unknown, unseen, no reply.
NW NW NW NW DI DI DI DI *09* UK NQ CS LN CS
0x0A Network status ping.
-Third ring, network controller only
-Used to cull dead nodes from sync list.
-Also checks to see if there is a device that wants to take over as scheduler.
NW NW NW NW DI DI DI DI *0A* UK NQ 7E LN CS
0x0B Netowrk status pong.
-Forth ring.
NW NW NW NW DI DI DI DI *0B* UK NQ 01 LN CS *00 00*
0x18 Passing scheduling duty to another device. The device's id reversed is the data.
NW NW NW NW DI DI DI DI *18* UK NQ CS LN CS *7C 62 03 81 62*
0x19 Acknolegement of passing scheduling duty by device taking over.
NW NW NW NW DI DI DI DI *19* UK NQ CS LN CS
0x01 Network synchronization packet.
-First device in the list is always the scheduler and the it's window size is 3 + (5 * iMNNodes).
-The network sync packet has a hard limit of ~32ms length.
0x02 Data packets.
-Types:
-0x01 - 06 byte Speed 0x04, 0x01, 0x05, 0x00, 0x64, 0x6E
-0x02 - 12 byte Trip/Log 0x0A, 0x02, 0x05, 0x00, 0x00, 0x00, 0x64, 0x00, 0x00, 0x00, 0x0A, 0x7F
-0x03 - 05 byte Temp 0x03, 0x03, 0x05, 0x02, 0x0D
-0x04 - 06 byte Depth 0x04, 0x04, 0x05, 0x00, 0x0A, 0x17
-0x05 - 06 byte App Wind Speed 0x04, 0x05, 0x05, 0x00, 0x0A, 0x18
-0x06 - 06 byte App Wind Dir 0x04, 0x06, 0x05, 0x00, 0x01, 0x10
-0x07 - 06 byte HDG 0x04, 0x07, 0x05, 0x00, 0x01, 0x11
-0x08 - 08 byte SOG/COG 0x06, 0x08, 0x05, 0x00, 0x0A, 0x00, 0x01, 0x1E
-0x09 - 11 byte LAT/LONG 0x09, 0x09, 0x05, 0x01, 0x03, 0xE8, 0x01, 0x03, 0xE8, 0x00, 0xEF
-0x0A - 12 byte BTW 0x0A, 0x0A, 0x05, 0x01, 0x01, 0x01, 0x01, 0x01, 0x01, 0x01, 0x01, 0x21
-0x0B - 06 byte XTE 0x04, 0x0B, 0x05, 0x00, 0x64, 0x78
-0x0C - 06 byte Time 0x04, 0x0C, 0x05, 0x01, 0x00, 0x16
-0x0D - 07 byte Date 0x05, 0x0D, 0x05, 0x01, 0x01, 0x01, 0x1A
- ...
-0x10 - 08 byte Node Info 0x06, 0x10 0x01, 0x02, 0x20, 0x23, 0x08, 0x64
- ...
-0x12 - 06 byte VMG-WP 0x04, 0x12, 0x05, 0x00, 0x64, 0x7F
- ...
-0x1B - 06 byte Battery 0x04, 0x1B, 0x05, 0x00, 0x0A, 0x2E
- ...
-0x1F - 08 byte DTW 0x06, 0x1F, 0x05, 0x00, 0x00, 0x00, 0x01, 0x2B
- ...
-0xFD - 08 byte timer stop/start/set 0x06, 0xFD, 0x00, 0x01, 0x00, 0x00, 0x00, 0x04
-TWDIR needs App Wind Speed, App Wind Dir, HDG
-BEAUF needs App Wind Speed, App Wind Dir, HDG
-MAG TWDIR needs App Wind Speed, App Wind Dir, HDG
-HEAD/LIFT needs App Wind Speed, App Wind Dir, HDG (this one takes a little bit to fill in as its a running average)
-VMG needs App Wind Speed, App Wind Dir, Speed
-TRUE WIND SPEED needs App Wind Speed, App Wind Dir, Speed
-TRUE WIND DIR needs App Wind Speed, App Wind Dir, Speed
-ETA/TTG needs VMG-WP and DTW.
0x03 Add transmit slot packet.
-Data is an unknown 0x00 byte followed by the window size you want then a checksum. Repeating this packet with a different window size does not change your window size.
-First byte might be an 0x0A byte to signal wanting sync duty. Need to check.
0x04 Remove transmit slot packet.
-Send this will remove your node's id from the sync list.
0x05 Adjust transmit slot packet.
-Data is one byte which is the new window size and a checksum.
0x06 Command packets.
0xE5 0x00 Display backlight command.
Backlight Off: 01 0A 8B 60 81 03 61 7C 06 09 00 66 10 10 E5 00 10 F5
Backlight L1: 01 0A 8B 60 81 03 61 7C 06 09 00 66 10 10 E5 01 0D F3
Backlight L2: 01 0A 8B 60 81 03 61 7C 06 09 00 66 10 10 E5 02 0E F5
Backlight L3: 01 0A 8B 60 81 03 61 7C 06 09 00 66 10 10 E5 03 0F F7
0xFF Settings command.
FF 01 01 00 24 25
CW RG SS SS CT CS
CW = Command word.
RG = Registry.
SS = Settings.
CT = Counter. Every time a setting is changed this increments. Probably for synchronization. Doesn't seem to matter as I've sent out 00 multiple times and the display took the setting.
CS = Checksum.
0xFF Reg 0x00 Speed adj. +/- 200%
speed +1%: 01 0A 8B 60 81 03 61 7C 06 09 00 66 12
