<div align="center">

Diffusion-Aided Joint Source Channel Coding for High Realism Wireless Image Transmission

<img src="images/Main.png" alt="overview" width="800"/> </div>

This is the official implementation of "Diffusion-Aided Joint Source Channel Coding for High Realism Wireless Image Transmission"

Installation

git clone https://github.com/mingyuyng/DiffJSCC.git
cd DiffJSCC

# create environment
conda create -n diffjscc python=3.9
conda activate diffjscc
pip install -r requirements.txt

Datasets

OpenImage dataset

Please run the script below to prepare the OpenImage dataset. Note that awscli needs to be installed before running this script. Please refer to OpenImage download

bash prepare_OpenImage.sh

Other datasets

We also provide other datasets, including CelebAHQ512 and Kodak. The readers could download them from Google Drive.

Data folder structure

/data                            # Root directory
|-- /OpenImage                   # Open Image dataset
|   |-- /018ed13fabd94731.jpg
|   |-- /00e48838f27aa1a3.jpg
|-- /CelebAHQ_train_512          # CelebAHQ train set
|   |-- /0.png
|   |-- /1.png
|-- /CelebAHQ_test_512           # CelebAHQ test set
|   |-- /27000.png
|   |-- /27001.png
|-- /Kodak                       # Kodak dataset
|   |-- /1.png
|   |-- /2.png

Split the train and val set

Please run the following script to split the training set and validation set. The list of images will be placed in datalist folder

bash create_data_list.sh

Train the JSCC encoder and decoder

OpenImage dataset

ResNet structure

python train.py --config ./configs/train_jscc_cnn.yaml --name "jscc_cnn_openimage" --refresh_rate 1

SwinJSCC

python train.py --config ./configs/train_jscc_swin.yaml --name "jscc_swin_openimage" --refresh_rate 1

Note that the data paths in configs/dataset/JSCC_OpenImage_train.yaml and configs/dataset/JSCC_OpenImage_val.yaml need to be modified

CelebA dataset

ResNet structure

python train.py --config ./configs/train_jscc_cnn_CelebA.yaml --name "jscc_cnn_CelebA" --refresh_rate 1

SwinJSCC

python train.py --config ./configs/train_jscc_swin_CelebA.yaml --name "jscc_swin_CelebA" --refresh_rate 1

Note that the data paths in configs/dataset/JSCC_CelebA_train.yaml and configs/dataset/JSCC_CelebA_val.yaml need to be modified

Train the conditional diffusion model

Download the weights of Stable Diffusion

wget https://huggingface.co/stabilityai/stable-diffusion-2-1-base/resolve/main/v2-1_512-ema-pruned.ckpt --no-check-certificate

Merge the Stable Diffusion weights with the JSCC encoder and decoder

Here is an example of merging the weights of SD and ResNet-based JSCC

python scripts/make_stage2_init_weight.py \
           --cldm_config configs/model/cldm_cnn.yaml \
           --sd_weight v2-1_512-ema-pruned.ckpt\
           --jscc_weight path/to/the/weights \
           --output ./init_weights/weights_cnn.ckpt

Train the conditional diffusion model

OpenImage dataset

python train.py --config ./configs/train_cldm.yaml --name 'cldm_cnn_OpenImage' --refresh_rate 1

Note that the paths within /configs/train_cldm.yaml need to be modified.

Pre-trained models

We have moved all the checkpoints to HuggingFace and modified the inference code accordingly.

| Model | Link | | ------- | ------- | | DiffJSCC trained on OpenImage dataset with C_channel=4 (CBR=1/384) | HuggingFace | | DiffJSCC trained on OpenImage dataset with C_channel=16 (CBR=1/96) | HuggingFace | | DiffJSCC trained on CelebAHQ dataset with C_channel=2 (CBR=1/768) | HuggingFace | | DiffJSCC trained on CelebAHQ dataset with C_channel=8 (CBR=1/192) | HuggingFace |

Inference

Kodak dataset

python inference_cldm.py \
    --ckpt Mingyuyang/DiffJSCC-OpenImage-CBR-1-384 \
    --input ./data/Kodak \
    --output ./results/Kodak-CBR-1-384 \
    --steps 100 \
    --device cuda \
    --repeat_times 5 \
    --SNR 1 \
    --show_lq \
    # --use_guidance --Lambda 100 --g_t_start 1001 --g_t_stop -1 --g_repeat 1 \ # uncomment this if want to apply intermediate guidance

CelebAHQ dataset

python inference_cldm.py \
    --ckpt Mingyuyang/DiffJSCC-CelebA-CBR-1-768 \
    --input ./data/CelebAHQ_test_512 \
    --output ./results/CelebA-CBR-1-768 \
    --steps 100 \
    --device cuda \
    --repeat_times 1 \
    --SNR -5 \
    --show_lq \
    #--use_guidance --Lambda 100 --g_t_start 1001 --g_t_stop -1 --g_repeat 1 \ # uncomment this if want to apply intermediate guidance

Visualizations

Kodak Images (CBR=1/384, SNR=1dB)

<img src="images/vis_new.png" alt="kodak" width="700"/>

CelebAHQ Images (CBR=1/768, SNR=-5dB)

<img src="images/visualization_CelebA.png" alt="celebA" width="700"/>

Acknowledgement

This project is largely based on DiffBIR and SwinJSCC. Thanks for their awesome work.

Reference

Mingyu Yang, Bowen Liu, Boyang Wang, Hun-Seok Kim, "Diffusion-Aided Joint Source Channel Coding For High Realism Wireless Image Transmission"

@article{yang2024diffusion,
  title={Diffusion-Aided Joint Source Channel Coding For High Realism Wireless Image Transmission},
  author={Yang, Mingyu and Liu, Bowen and Wang, Boyang and Kim, Hun-Seok},
  journal={arXiv preprint arXiv:2404.17736},
  year={2024}
}
