About BoardUI

<div align="left"> <img src="boardui-screenshot-1.webp" alt="Logo" width="400"> </div>

BoardUI is a set of libraries for visualization of printed circuit boards in format IPC-2581 in browser.

The project consists of 5 packages:

• boardui-parser - Parser for IPC-2581 and data model classes.
• boardui-renderer - Renderer of IPC-2581 to SVG.
• boardui-angular - Angular component to easily integrate parser and renderer with regular controls into Angular app.
• boardui-core - Shared lib
• boardui-demo - Demo angular app - also available at demo.boardui.com
