Geolib

Library to provide basic geospatial operations like distance calculation, conversion of decimal coordinates to sexagesimal and vice versa, etc. This library is currently 2D, meaning that altitude/elevation is not yet supported by any of its functions!

Changelog

A detailed changelog can be found in CHANGELOG.md

Install

npm install geolib

yarn add geolib

Usage

There is a UMD build and an ES Module build. You can either use the UMD build in Node like any other library:

const geolib = require('geolib');

or in the browser by using a simple script element:

<script src="lib/geolib.js"></script>

If you load it in the browser, you can access all the functions via window.geolib.

If you're working with a bundler (like Webpack or Parcel) or have an environment that supports ES Modules natively, you can either import certain functions from the package directly:

import { getDistance } from 'geolib';

or load the whole library:

import * as geolib from 'geolib';

or you can import single functions directly to potentially make use of treeshaking (recommended):

import getDistance from 'geolib/es/getDistance';

General

This library is written in TypeScript. You don't have to know TypeScript to use Geolib but the type definitions give you valuable information about the general usage, input parameters etc.

Supported values and formats

All methods that are working with coordinates accept either an object with a lat/latitude and a lon/lng/longitude property, or a GeoJSON coordinates array, like: [lon, lat]. All values can be either in decimal (53.471) or sexagesimal (53° 21' 16") format.

Distance values are always floats and represent the distance in meters.

Functions

getDistance(start, end, accuracy = 1)

Calculates the distance between two geo coordinates.

This function takes up to 3 arguments. First 2 arguments must be valid GeolibInputCoordinates (e.g. {latitude: 52.518611, longitude: 13.408056}). Coordinates can be in sexagesimal or decimal format. The third argument is accuracy (in meters). By default the accuracy is 1 meter. If you need a more accurate result, you can set it to a lower value, e.g. to 0.01 for centimeter accuracy. You can set it higher to have the result rounded to the next value that is divisible by your chosen accuracy (e.g. 25428 with an accuracy of 100 becomes 25400).

getDistance(
    { latitude: 51.5103, longitude: 7.49347 },
    { latitude: "51° 31' N", longitude: "7° 28' E" }
);

// Working with W3C Geolocation API
navigator.geolocation.getCurrentPosition(
    (position) => {
        console.log(
            'You are ',
            geolib.getDistance(position.coords, {
                latitude: 51.525,
                longitude: 7.4575,
            }),
            'meters away from 51.525, 7.4575'
        );
    },
    () => {
        alert('Position could not be determined.');
    }
);

Returns the distance in meters as a numeric value.

getPreciseDistance(start, end, accuracy = 1)

Calculates the distance between two geo coordinates. This method is more accurate then getDistance, especially for long distances but it is also slower. It is using the Vincenty inverse formula for ellipsoids.

It takes the same (up to 3) arguments as getDistance.

geolib.getPreciseDistance(
    { latitude: 51.5103, longitude: 7.49347 },
    { latitude: "51° 31' N", longitude: "7° 28' E" }
);

getCenter(coords)

Calculates the geographical center of all points in a collection of geo coordinates. Takes an array of coordinates and calculates the center of it.

geolib.getCenter([
    { latitude: 52.516272, longitude: 13.377722 },
    { latitude: 51.515, longitude: 7.453619 },
    { latitude: 51.503333, longitude: -0.119722 },
]);

Returns an object:

{
    "latitude": centerLat,
    "longitude": centerLon
}

getCenterOfBounds(coords)

Calculates the center of the bounds of geo coordinates.

Takes an array of coordinates, calculate the border of those, and gives back the center of that rectangle.

On polygons like political borders (eg. states), this may gives a closer result to human expectation, than getCenter, because that function can be disturbed by uneven distribution of point in different sides.

Imagine the US state Oklahoma: getCenter on that gives a southern point, because the southern border contains a lot more nodes, than the others.

geolib.getCenterOfBounds([
    { latitude: 51.513357512, longitude: 7.45574331 },
    { latitude: 51.515400598, longitude: 7.45518541 },
    { latitude: 51.516241842, longitude: 7.456494328 },
    { latitude: 51.516722545, longitude: 7.459863183 },
    { latitude: 51.517443592, longitude: 7.463232037 },
]);

Returns an object:

{
    "latitude": centerLat,
    "longitude": centerLng
}

getBounds(points)

Calculates the bounds of geo coordinates.

geolib.getBounds([
    { latitude: 52.516272, longitude: 13.377722 },
    { latitude: 51.515, longitude: 7.453619 },
    { latitude: 51.503333, longitude: -0.119722 },
]);

It returns minimum and maximum latitude and minimum and maximum longitude as an object:

{
    "minLat": minimumLatitude,
    "maxLat": maximumLatitude,
    "minLng": minimumLongitude,
    "maxLng": maximumLongitude,
}

isPointInPolygon(point, polygon)

Checks whether a point is inside of a polygon or not.

geolib.isPointInPolygon({ latitude: 51.5125, longitude: 7.485 }, [
    { latitude: 51.5, longitude: 7.4 },
    { latitude: 51.555, longitude: 7.4 },
    { latitude: 51.555, longitude: 7.625 },
    { latitude: 51.5125, longitude: 7.625 },
]);

Returns true or false

isPointWithinRadius(point, centerPoint, radius)

Checks whether a point is inside of a circle or not.

// checks if 51.525/7.4575 is within a radius of 5 km from 51.5175/7.4678
geolib.isPointWithinRadius(
    { latitude: 51.525, longitude: 7.4575 },
    { latitude: 51.5175, longitude: 7.4678 },
    5000
);

Returns true or false

getRhumbLineBearing(origin, destination)

Gets rhumb line bearing of two points. Find out about the difference between rhumb line and great circle bearing on Wikipedia. Rhumb line should be fine in most cases:

http://en.wikipedia.org/wiki/Rhumb_line#General_and_mathematical_description

Function is heavily based on Doug Vanderweide's great PHP version (licensed under GPL 3.0) http://www.dougv.com/2009/07/13/calculating-the-bearing-and-compass-rose-direction-between-two-latitude-longitude-coordinates-in-php/

geolib.getRhumbLineBearing(
    { latitude: 52.518611, longitude: 13.408056 },
    { latitude: 51.519475, longitude: 7.46694444 }
);

Returns calculated bearing as number.

getGreatCircleBearing(origin, destination)

Gets great circle bearing of two points. This is more accurate than rhumb line bearing but also slower.

geolib.getGreatCircleBearing(
    { latitude: 52.518611, longitude: 13.408056 },
    { latitude: 51.519475, longitude: 7.46694444 }
);

Returns calculated bearing as number.

getCompassDirection(origin, destination, bearingFunction = getRhumbLineBearing)

Gets the compass direction from an origin coordinate to a destination coordinate. Optionally a function to determine the bearing can be passed as third parameter. Default is getRhumbLineBearing.

geolib.getCompassDirection(
    { latitude: 52.518611, longitude: 13.408056 },
    { latitude: 51.519475, longitude: 7.46694444 }
);

Returns the direction (e.g. NNE, SW, E, …) as string.

orderByDistance(point, arrayOfPoints)

Sorts an array of coords by distance to a reference coordinate.

geolib.orderByDistance({ latitude: 51.515, longitude: 7.453619 }, [
    { latitude: 52.516272, longitude: 13.377722 },
    { latitude: 51.518, longitude: 7.45425 },
    { latitude: 51.503333, longitude: -0.119722 },
]);

Returns an array of points ordered by their distance to the reference point.

findNearest(point, arrayOfPoints)

Finds the single one nearest point to a reference coordinate. It's actually just a convenience method that uses orderByDistance under the hood and returns the first result.

geolib.findNearest({ latitude: 52.456221, longitude: 12.63128 }, [
    { latitude: 52.516272, longitude: 13.377722 },
    { latitude: 51.515, longitude: 7.453619 },
    { latitude: 51.503333, longitude: -0.119722 },
    { latitude: 55.751667, longitude: 37.617778 },
    { latitude: 48.8583, longitude: 2.2945 },
    { latitude: 59.3275, longitude: 18.0675 },
    { latitude: 59.916911, longitude: 10.727567 },
]);

Returns the point nearest to the reference point.

getPathLength(points, distanceFunction = getDistance)

Calculates the length of a collection of coordinates. Expects an array of points as first argument and optionally a function to determine the distance as second argument. Default is getDistance.

geolib.getPathLength([
    { latitude: 52.516272, longitude: 13.377722 },
    { latitude: 51.515, longitude: 7.453619 },
    { latitude: 51.503333, longitude: -0.119722 },
]);

Returns the length of the path in meters as number.

getDistanceFromLine(point, lineStart, lineEnd, accuracy = 1)

Gets the minimum distance from a point to a line of two points.

geolib.getDistanceFromLine(
    { latitude: 51.516, longitude: 7.456 },
    {
