SatelliteFreqMon - Automated Satellite Tracking and Precise Frequency Recording

The goal of this project is to provide a comprehensive open source solution for accurately monitoring satellite passes^1 using configurable TLE (Two-Line Elements)[^2] and precise frequency recording using the software-defined radio application GQRX[^3].

Hardware Setup

<img src="git-assets/hardware-setup.png?raw=true" width="75%">

Hardware List

• RTL-SDR RTL2832U Dongle
• Wideband LNA
• V Dipole Antenna (tuned for NOAA frequencies)
• Raspberry Pi

TLE File Configuration

Place the TLE files in the sats/ directory.

Syntax

SATELLITE NAME
TLE-LINE-1
TLE-LINE-2
FREQUENCY
BANDWIDTH (Frequency range)

Example

NOAA19
1 33591U 09005A   23156.14173894  .00000208  00000-0  13708-3 0  9991
2 33591  99.1001 201.8759 0012774 277.1213  82.8506 14.12764011738249
137100
42000

Also make sure to adapt the GROUNDSTATION_LOCATION variable to set the groundstation location. This is necessary to accurately calculate the satellite passes.

Example Output

pi@sdrpi:~/sat-tracker $ python tracker.py
===== Passes calculated for: ['METEOR M2', 'NOAA19', 'NOAA15', 'ISS (ZARYA)', 'JAS 2 (FO-29)', 'NOAA18'] =====
=== Configuring GQRX...
M WFM 45000 RPRT 0
L SQL -150 RPRT 0
=== ISS (ZARYA) overpass (2023-06-07 17:52:22 - 2023-06-07 18:02:57 for 0:10:34.696568) on 145800KHz.
F 145800000 RPRT 0
M WFM 40000 RPRT 0
AOS RPRT 0

<img src="git-assets/gqrx-noaa.png?raw=true" width="65%">

Maintainership and License

If you have any suggestions for improvements or would like to contribute to the project, feel free to submit a pull request. This project is licensed under the MIT License[^4]. See the LICENSE file for details.

Copyright (c) 2023 louis-e

[^2]: "A two-line element set (TLE) is a data format encoding a list of orbital elements of an Earth-orbiting object for a given point in time, the epoch." https://en.wikipedia.org/wiki/Two-line_element_set

[^3]: "Gqrx is an open source software defined radio receiver (SDR) powered by the GNU Radio and the Qt graphical toolkit." https://gqrx.dk/
