sgip

SGIP protocol v1.2 (China Unicom). It implements a bridge from TCP to HTTP.

SGIP is used to send or receive SMS between SP and SGP. SGIP is based on TCP, but i like HTTP more than TCP. So this project implements a bridge from TCP to HTTP. With this project, all the business logic code in SP would be based on HTTP.

Requirements

• Go 1.1 or higher
• seelog

Build

You need to create a golang project which has main package, then initialize the sgip package and start the sgip server.

For example:

package main

import (
	"fmt"
	"github.com/cihub/seelog"
	"github.com/liuben/sgip"
	"os"
	"time"
)

func main() {
	// init seelog
	logger, err := seelog.LoggerFromConfigAsFile("/www/sgip/etc/seelog.xml")
	if err != nil {
		fmt.Fprintf(os.Stderr, "%s -- seelog init error:%s\n", time.Now().String(), err.Error())
		panic("seelog init error")
	}
	seelog.ReplaceLogger(logger)
	defer seelog.Flush()

    // init sgip package
	var sgipConfig sgip.SgipConfig
	sgipConfig.SgpIp = "192.168.1.3"
	sgipConfig.SgpPort = 8881
	sgipConfig.SpTcpListenPort = 8801
	sgipConfig.SpWebListenPort = 8802
    sgipConfig.ReportCallbackUrl = "http://127.0.0.1/report"
    sgipConfig.DeliverCallbackUrl = "http://127.0.0.1/deliver"
	sgipConfig.ReadTimeoutSecond = 60
	sgipConfig.WriteTimeoutSecond = 10
    sgipConfig.SpAppIp = "127.0.0.1"
	sgipConfig.Logger = logger
	sgipConfig.TcpClientCount = 2
	sgipConfig.SubmitQueueDepth = 4
    sgipConfig.AreaPhoneNo = 10
    sgipConfig.CorpId = 12345
	sgipConfig.LoginUserName = "abcde"
	sgipConfig.LoginPassword = "abcde"
	sgip.Init(&sgipConfig)

    // start the sgip server
	sgip.Start()
}

Build & Run

go build -o sgip
./sgip or use supervisor

Usage

When you start the sgip server, it will wait for the SGP connection and business logic request.

Submit

Business logic can request the url as follow to submit a SMS:

http://127.0.0.1:8801/submit?spNumber=123456789&chargeNumber=&userNumber=861381123457&corpId=666666&serviceType=01020304&feeType=00&feeValue=0&givenValue=%00&agentFlag=00&mtFlag=02&priority=00&expireTime=%00&scheduleTime=%00&reportFlag=00&tppid=08&tpudhi=00&msgCoding=00&&msgContent=616263&reserve=0000000000000000

These fields use ascii, they could be shorter than SGIP protocol requirement:

• spNumber
• chargeNumber
• userNumber
• corpId
• serviceType
• feeValue
• givenValue
• expireTime
• scheduleTime

Thess fields use number in hex string format, 0F means 15, they should be as long as SGIP protocol requirement exactly:

• feeType
• agentFlag
• mtFlag
• priority
• reportFlag
• tppid
• tpudhi
• msgCoding
• msgContent
• reserve

The response of this HTTP request is in JSON format as

{"result":0,"sequence":"0102030405060708090A0B0C"}

Sequence is the submit's sequence number, which has 12 bytes. If failed, the result would be 1, and sequence would be empty string.

Deliver

When sgip server receives a deliver, it will callback the business logic's web service.

http://127.0.0.1/deliver?msgCoding=00&msgContent=616263&spNumber=123456789&tppid=00&tpudhi=00&userNumber=8613811234567&reserve=0000000000000000

So business logic should implements the callback web service, and initilize it to DeliverCallbackUrl.

Report

When sgip server receives a report, it will callback the business logic's web service.

http://127.0.0.1/report?errorCode=67&reportType=00&state=02&submitSeq=B44EC4FD3D1AEE6600000001&userNumber=8613811234567

So business logic should implements the callback web service, and initilize it to ReportCallbackUrl.
