Arcan

Arcan is a powerful development framework for creating virtually anything from user interfaces for specialized embedded applications all the way to full-blown standalone desktop environments.

At its heart lies a robust and portable multimedia engine, with a well-tested and well-documented Lua scripting interface. The development emphasizes security, debuggability and performance -- guided by a principle of least surprise in terms of API design.

For more details about capabilities, design, goals, current development, roadmap, changelogs, notes on contributing and so on, please refer to the arcan-wiki.

There is also a website that collects other links, announcements, releases, videos / presentations and so on.

• For community contact, check out the IRC channel #arcan on irc.libera.chat and/or the discord (invite-link)

• For developer information, see the HACKING.md

The github repository is going defunct thanks to Microsofts incresingly abusive practices, and we are thus moving to self-hosted Fossil. The repository will be synched to github for the time being, but no active development activities there. See fossil.arcan-fe.com.

Getting Started

Some distributions, e.g. voidlinux have most of arcan as part of its packages, so you can save yourself some work going for one of those. Other ones with an active community would be through Nix (for example: nix-shell -p arcan.all-wrapped).

Docker- container templates (mainly used for headless development and testing) can be found here, quality varies wildly from bad to poor (just like Docker): dockerfiles.

Compiling from Source

There are many ways to tune the build steps in order to reduce dependencies. There are even more ways to configure and integrate the components depending on what you are going for; running as a native desktop or as an application runtime inside another desktop?

Most options are exposed via the build output from running cmake on the src directory.

For the sake of simplicity over size, there is a build preset, 'everything' which is the one we will use here.

Dependencies

Specific package names depend on your distribution, but common ones are:

sqlite3, openal-soft, sdl2, opengl, luajit, gbm, kms, freetype, harfbuzz
libxkbcommon

For more encoding and decoding options you might also want:

libvlc-core (videolan), the ffmpeg suite, leptonica + tesseract (ocr)
libvncserver libusb1, v4l2-loopback, mupdf

First we need some in-source dependencies that are cloned manually for now:

git clone https://github.com/letoram/arcan.git
cd arcan/external/git
./clone.sh
cd ../../

These are typically not needed, the main use is for ensuring certain build options that might vary between distributions (luajit) and to ensure that a recoverable desktop can be statically linked and executed in an otherwise broken userspace (so embedded bringup). The one exception is OpenAL which is patched to be used by a special (arcan-lwa) build. This is slated for refactoring to remove that dependency, but there are other priorities in the way.

Compiling

Now we can configure and build the main engine:

mkdir build
cd build
cmake -DBUILD_PRESET="everything" ../src

Like with other CMake based projects, you can add:

-DCMAKE_BUILD_TYPE=Debug

To switch from a release build to a debug one.

When it has finished probing dependencies, you will get a report of which dependencies that has been found and which features that were turned on/off, or alert you if some of the required dependencies could not be found.

Make and install like normal (i.e. make, sudo make install). A number of binaries are produced, with the 'main' one being called simply arcan. To test 'in source' (without installing) you should be able to run:

 ./arcan -T ../data/scripts -p ../data/resources ../data/appl/welcome

The -T argument sets our built-in/shared set of scripts, the -p where shared resources like fonts and so on can be found, and the last argument being the actual 'script' to run.

With installation, this should reduce to:

 arcan welcome

It will automatically try to figure out if it should be a native display server or run nested within another or even itself based on the presence of various environment variables (DISPLAY, WAYLAND_DISPLAY, ARCAN_CONNPATH).

'welcome' is a name of a simple builtin welcome screen, that will shut down automatically after a few seconds.

For something of more directly useful, you can try the builtin appl 'console':

arcan console

Which should work just like your normal console command-line, but with the added twist of being able to run (arcan compatible) graphical applications as well. For other projects, see the 'Related Projects' further below.

If input devices are misbehaving, the quick and dirty 'eventtest' in:

arcan /path/to/arcan/tests/interactive/eventtest

Might be useful in figuring out who to blame.

SUID Notes

The produced egl-dri platform 'arcan' binary installs suid by default. This is not strictly necessary unless some specific features are desired, e.g. laptop backlight controls on Linux as those require access to sysfs and friends.

If that is not relevant, you can strip the suid property on the binary, but do note that your current user still requires access to relevant /dev/input/event and /dev/dri/cardN and /dev/dri/renderN files to work properly -- otherwise input and/or graphics devices might not be detected or useable.

The binary does split off into a non-suid part that the main engine runs off of, see posix/psep_open.c for auditing what is being run with higher privileges as well as the code for dropping privileges. The privileged process is responsible for negotiating device access, implementing virtual-terminal switching and as a watchdog for recovering the main process on live locks or some GPU failures.

Hook-Scripts

Another way to extend engine behavior regardless of the appl being used are so called hook-scripts. These reside inside the 'system script path' covered by the -T command-line argument, or the default of shared/arcan/scripts.

The idea is that these should be able to provide 'toggle on' features that would need cooperation from within the engine, in order to do quick custom modifications or help bridge other tools.

A good example is 'external_input':

arcan -H hooks/external_input.lua -H hooks/external_input.lua myappl

This would open up two connection points, 'extio_1', 'extio_2' that will allow one client to connect and provide input that will appear to the 'myappl' appl as coming from the engine.

These are covered in more detail in the manpage.

Networking

Arcan-net is a binary that allows you to forward one or many arcan clients over a network. It is built by default, and can be triggered both as a separate network tool as well as being launched indirectly from shmif by setting ARCAN_CONNPATH=a12://id@host:port, or when issuing a migration request by the window manager.

See also: src/a12/net/README.md and src/a12/net/HACKING.md.

Wayland

The 'arcan-wayland' or 'waybridge', as it is refered to in some places is binary adds support for wayland and X clients (via Xwayland). It can be run as either a global system service, e.g.

arcan-wayland -xwl

Or on a case by case basis, like:

arcan-wayland -exec weston-terminal

For a compliant wayland client, and:

arcan-wayland -exec-x11 xterm

For an X client. The 'per case' basis is recommended as it is safer and more secure than letting multiple clients share the same bridge process, at a negilable cost. The downside is that some complex clients that rely on making multiple distinct wayland connections may fail to work properly. Firefox is a known offender.

There is a number of tuning and troubleshooting options due to the complexity of using wayland, consult the manpage and the --help toggle.

Database

All runtime configuration is consolidated into a database, either the default 'arcan.sqlite' one or an explicitly set one (arcan -d mydb.sqlite).

This is used for platform specific options, engine specific options and for trusted clients that the running scripts are allowed to start. It is also used as a configuration key-value store for any arcan applications that are running.

As a quick example, this is how to inspect and modify keys that 'Durden' are currently using:

arcan_db show_appl durden
arcan_db add_appl_kv durden shadow_on true

Advanced configuration for some video platforms can be set via the reserved arcan appl name. This would, for instance, set the primary graphics card device name for the 'egl-dri' platform version:

arcan_db add_appl_kv arcan video_device=/dev/dri/card2

To add 'launch targets', you can use something like:

arcan_db add_target net BIN /usr/bin/arcan-net -l netfwd
arcan_db add_config arcan-net default 10.0.0.10 6666
arcan_db add_target xterm BIN /usr/bin/arcan-wayland -exec-x11

This allow applications to start a program as a trusted child (that inherits its connection primitives rather than to try and find them using some OS dependent namespace). The example above would have spawned arcan-net in the local mode where clients connecting to the 'netfwd' connpath would be redirected to the server listening at 10.0.0.10:6666.

There are many controls and options for this tool, so it is suggested that you look at its manpage for further detail and instructions.

Headless Mode

The 'everything' build option should also produce a binary called 'arcan_headless', at least on BSDs and Linux. This binary can be used to run arcan without interfering with your other graphics and display system. Given access to a 'render node' (/dev/dri/renderD128 and so on) and it should al
