Leanorama - a jQuery plugin for displaying and navigating Virtual Tours based on panoramic images

Leanorama is essentially abandonware. That means Leandigo is no longer actively developing this. Still, pull requests will be accepted.

What is this

Look at the Demo_.

Leanorama started as a client-side infrastructure component of a virtual tour product.

Leanorama allows navigation inside equirectangular_-turned-cubic_ panoramic images on HTML5 websites. As a jQuery plugin, it's easy to embed and configure. It's working on modern webkit browsers, including mobile browsers of iOS 4+ and Android 3+, and IE10.

Features

At the time of writing, Leanorama is the first and only 100% HTML5/CSS3/JavaScript panorama viewer available as a standalone solution. It doesn't require paying for a specific software or service in order to be used.

All you need is some very basic HTML/JavaScript skills, and a cubic_ remap of an equirectangular_ panoramic image. You'll be able to create virtual tours supporting:

Works on Safari, Chrome, Internet Explorer 10+
3D immersive rendition of cubic panorama images
Pitch, yaw and zoom view manipulation
Control inputs: keyboard, mouse, touch, orientation (accelerometer or gyro on mobile devices)
Yes, that means it works on phones and tablets - you can hold them and look around
Controls bar with on-screen buttons (via extension)
Hotspots for navigaion, information and links (via extension)
Title and description (via extension)

I say "via extension" a lot. That's because you can write your own extensions for leanorama using a very simple API.

Attributions

The implementation is loosely inspired by this three.js demo: <http://threejs.org/examples/css3d_panorama.html>_ by mrdoob_.

This code is bundled with a slightly tweaked version of Transit_ by Rico Sta. Cruz_

The example loads panoramic photographs by:

Alexandre Duret-Lutz_
heiwa4126_
jannefoo_

HowTo

Required Scripts

Include the required scripts (jQuery, Bootstrap, **bundled** Transit, Leanorama core) and stylesheets::

    <script src="http://code.jquery.com/jquery-1.10.2.min.js"></script>
    <script src="http://netdna.bootstrapcdn.com/twitter-bootstrap/2.3.2/js/bootstrap.min.js"></script>
    <script src="js/jquery.transit.js"></script>
    <script src="js/jquery.leanorama.js"></script>
    <link href="http://netdna.bootstrapcdn.com/twitter-bootstrap/2.3.2/css/bootstrap-combined.min.css" rel="stylesheet">
    <link rel="stylesheet" href="css/leanorama.css">

Initialization Parameters

In a script, initialize Leanorama in a DOM element of your choosing::

$('#pano').leanorama({ /* ... params ... */ })

.. csv-table:: Supported Initialization Parameters :header: Parameter, Type, Default, Description :widths: 15, 10, 15, 60

``sides``,      Array,      ,     "**(required)** URLs for the panorama images: [right, back, left, front, up, down]"
``limit``,      object,     "``{ top: 85, bottom: -85, right: 999, left: -999 }``", "Field of vision limits in degrees"
``lon``,        number,     0,      "Initial yaw angle"
``lat``,        number,     0,      "Initial pitch angle"
``scale``,      number,     1,      "Initial zoom factor"
``autorotate``, number,     0,      "Initial autorotation speed"
``fading``,     boolean,    true,   "Enable fade in/out when starting/stopping"
``mouse``,      boolean,    true,   "Enable mouse controls"
``kbd``,        boolean,    true,   "Enable keyboard controls"
``touch``,      boolean,    true,   "Enable touch controls"
``gyro``,       boolean,    true,   "Enable gyro/accelerometer controls"
``delay``,      integer,    25,     "Delay in milliseconds between view updates(frames)"

Control Bar Extension

This displays a collapsible controls toolbar at the lower-left corner of the panorama object.

Add the control bar extension and CSS::

    <script src="js/jquery.leanorama.controlbar.js"></script>
    <link rel="stylesheet" href="css/leanorama.controlbar.css">

That's it.

Infobox Extension
`````````````````
This displays a static box at the upper-right corner of the panorama object with any HTML inside.

Add the infobox extension and CSS::

    <script src="js/jquery.leanorama.infobox.js"></script>
    <link rel="stylesheet" href="css/leanorama.infobox.css">

Add the following initialization parameter to your parameters object:

.. csv-table:: Infobox Initialization Parameters
    :header: Parameter, Type, Default, Description
    :widths: 15, 10, 15, 60

    ``infobox``, string, ,The HTML that will be inserted to the infobox

Hotspot Extension
``````````````````
This lets you show hotspots on panorama's surfaces for navigation, information, links, or custom actions.

Navigation hotspots require a custom event handler. It can be a really simple function (see Example).

Link and information hotspots work out of the box.

Add the hotspot extension and CSS::

    <script src="js/jquery.leanorama.hotspot.js"></script>
    <link rel="stylesheet" href="css/leanorama.hotspot.css">

Add the following initialization parameter to your parameters object:

.. csv-table:: Hotspot Initialization Parameters
    :header: Parameter, Type, Default, Description
    :widths: 15, 10, 15, 60

    ``hotspots``, Array, , Contains hotspot definition objects

.. csv-table:: Hotspot Definition Object
    :header: Parameter, Type, Default, Description
    :widths: 15, 10, 15, 60

    ``type``, string, 'nav', "One of ['nav', 'info', 'link', 'action']"
    ``id``, string, , "The ID of the hotspot DOM element. In case you want to find it later"
    ``face``, integer, ,"The index of the side on which the hotspot should appear (0..5)"
    ``x``, number, , "The ``left`` coordinate of the hotspot on the face (0..1024)"
    ``y``, number, , "The ``top`` coordinate of the hotspot on the face (0..1024)"
    ``name``, string, , "Varies by hotspot type

    :nav: The string that appears in the tooltip
    :info: The title of the information popup
    :link: The string that appears in the tooltip"
    ``value``, string, , "Varies by hotspot type

    :nav: *Depends on event handler*
    :info: The content of the popup
    :link: The URL of the link"

Events
``````
There are many. Most are internal events you shouldn't care about. Their names are self-explanatory and you can play
with them: ``leanoramaInit, leanoramaResize, leanoramaResized, leanoramaEngineStarted, leanoramaEngineStarting,
leanoramaEngineStopped, leanoramaEngineStopping, leanoramaViewChanged, leanoramaViewTransitionStarted,
leanoramaViewTransitionStopped, leanoramaAutorotateStarted, leanoramaAutorotateStopped``.

One more useful event for developers would be ``leanoramaHotspotClick``, which is for handling hotspot clicks (DUH!),
and ``leanoramaRefresh`` which forces restart of Leanorama with updated settings. Check out the example below of how
can this be glued together.

Example
-------
This is an example virtual tour configuration script::

    var tour = {
        plaza: { // First location: Plaza
            sides: [ // URLs for panorama files
                '/path/to/plaza/right.jpg',
                '/path/to/plaza/back.jpg',
                '/path/to/plaza/left.jpg',
                '/path/to/plaza/front.jpg',
                '/path/to/plaza/up.jpg',
                '/path/to/plaza/down.jpg'
            ],
            hotspots: [ // This location has 3 hotspot: navigation, info with video, and a link
                { // Navigation hotspot which will take you to the Museum.
                    type: 'nav',
                    face: 0,
                    x: 123,
                    y: 456,
                    id: 'nav-plaza-to-museum',
                    name: 'Enter Museum',
                    value: 'museum'
                },
                { // Link to the Leanorama repository
                    type: 'link',
                    face: 2,
                    x: 42,
                    y: 460,
                    id: 'download-link',
                    name: 'Download Leanorama',
                    value:'https://github.com/leandigo/leanorama'
                },
                { // An info popup with a video
                    type: 'info',
                    face: 4,
                    x: 1000,
                    y: 1000,
                    face: 0,
                    id: 'info-video',
                    name: 'That <em>awesome</em> video!',
                    value: '<div id="blah" style="text-align: center">\
                        <iframe width="200" height="113" src="http://www.youtube.com/embed/9bZkp7q19f0" frameborder="0" allowfullscreen></iframe>\
                        <br><br>In case you have forgotten about this awesome video, here it is!<br><br>\
                        <a href="http://youtu.be/9bZkp7q19f0" class="btn btn-success" target="_blank">Watch it on YouTube</a>\
                        </div>'
                }
            ]
        },
        museum: { // Second location: Museum
            autorotate: 0.1         // When entering the location, autorotation will start
            sides: [ // URLs for panorama files
                '/path/to/museum/right.jpg',
                '/path/to/museum/back.jpg',
                '/path/to/museum/left.jpg',
                '/path/to/museum/front.jpg',
                '/path/to/museum/up.jpg',
                '/path/to/museum/down.jpg'
            ],
            hotspots: [
                { // A navigation hotspot to go back to the plaza
                    type: 'nav',
                    face: 2,
                    x: 456,
                    y: 789,
                    id: 'nav-museu
