Tinsel

Tinsel is a game engine and hosted web service that enables the creation of telephony-based interactive audio experiences. If you want to make something that uses a touch tone dial pad for input and either text-to-speech or recorded audio for output, Tinsel might be the tool for you!

Although it wasn't built using Tinsel, Here And There Along The Echo is a great example of the sort of experience you could use Tinsel to build. A few other sample projects also exist:

• Call (858) 215-1980 for a Flappy Bird clone (source)

Why the name Tinsel? It's vaguely like Twine, but it involves (phone) trees. I know, you're groaning. Tinsel is also heavily inspired by the lovely Cheap Bots Done Quick.

What actually is it?

At a high level, Tinsel is a web app that lets you create scripts in a specific format, point a Twilio app at its servers, and magically have a functioning interactive phone tree you can call on any touch-tone phone.

In actuality, Tinsel is really three different things.

• A JSON-based grammar to declaratively describe content nodes and relationships between them based on numberpad input.

• A web application that offers a browser-based UI for creating and editing Tinsel documents. It then dynamically transforms those scripts into Twilio-compatible TwiML files.

• An integration that allows you to use the Twine 2 editor to create stories, automatically converting from Twine's format into Tinsel scripts and exporting those scripts to the hosted Tinsel service.

The Twine integration specifically lives in the Tinsel-Twison GitHub repo.

(Looking for the old, Ruby-based version of Tinsel? Check out the ruby branch: http://github.com/lazerwalker/tinsel/tree/ruby)

So how do I use it?

http://www.maketinsel.com is the hosted version of Tinsel. That's probably what you want.

A caveat on stability and security

Tinsel is very rough prototype software, with many bugs and missing features. Furthermore, it has been designed largely for games and interactive art, a choice that doesn't place particular importance on security or privacy. Which is to say: use Tinsel to make cool things. If you're trying to use it to fulfill a business need, you're likely better off building a custom solution yourself on top of Twilio.

Using Twine to make Tinsel scripts

The easiest way to use Tinsel is to write your stories using Twine 2. This section will talk about how to get that set up, as well as how to actually write and export your stories from Twine to Tinsel.

Setup

Make sure you are using Twine 2. Either the web-based or downloadable versions will work, but you need to be using Twine 2; Twine 1 is not currently supported.

From the Twine 2 story select screen, add a story format (click the "Formats" button on the right, then "Add a story format". Enter the url http://lazerwalker.com/tinsel-twison/format.js.

From within your story, set its story format to Tinsel. You can do this by clicking the bottom toolbar item with the name of your story, and then selecting "Change Story Format".

From here on out, choosing "Play" from within the story editor will give you a Tinsel-compatible JSON file you can copy and paste straight into the Tinsel web editor at http://maketinsel.com.

Once you've done that, you'll be able to play your story on an actual telephone by following the instructions in the "Conneting to Twilio" section below.

Writing With Twine

This guide assumes familiarity with Twine 2. If you've never used it, you might want to check out the resources for beginners on the Twine 2 wiki.

Writing Tinsel stories in Twine is generally the same as regular Twine use, but there are a bunch of specifics to note.

For the most part, your Tinsel stories will communicate with the player in one of two ways: text to speech, or prerecorded audio. In a given Twine node, you can do either or both of these, as well as insert a silent pause, automatically redirect to another node, and link to other nodes based on the result of the player's numeric input.

Hello, World!

If you just have plain text inside a Twine node, Tinsel will read that out as text-to-speech using the default Twilio voice (a male voice with an American accent).

The simplest possible functioning Tinsel story would be a single node with the following text:

Hello, world!

Alternate Text-To-Speech Options

Twilio (and subsequently Tinsel) offer three different voices: a male voice (called "man"), and two female voices ("woman" and "alice"). As mentioned above, the default voice is "man", but you can explicitly specify any of these voices by prefixing your text with the name of the voice and a colon.

woman: This will be said in a female voice

Mixing and matching multiple voices

You can have multiple voices within a single node by putting two newlines between text.

man: I'm late! I'm late!

woman: Off with their heads!

alice: I really shouldn't have fallen down that rabbithole!

A node with these contents will read those three sentences, in the appropriate voices, in the order they are listed.

Pausing

You can insert an explicit pause by using the string pause:x (or pause: x, spaces are okay), where x is the number of seconds to pause. Like including multiple voices, you should separate a pause by two newlines on either side from other content.

man: I see you shiver with anticip-

pause: 1

man: ation.

Playing audio files

If you want to play a prerecorded audio file, it's as simple as putting in a string of the format play: http://icq.com/uhoh.wav.

Tinsel does not currently host audio files for you; you must upload them somewhere else on the web and link to them in your script. Tinsel supports mp3, wav, aiff, gsm, and μ-law files.

As with everything else, separate this by two newlines.

alice: Why was Cinderella so bad at soccer?

pause: 2

alice: Because she kept running away from the ball!

play: http://instantrimshot.com/rimshot.wav

Redirecting

Sometimes you might want to redirect directly to another node. You can do that with the text redirect: nodename, where nodename is the name of the Twine node to redirect to.

As soon as that redirect command is reached, the contents of the next node will be played. If you include text or other content in a node after a redirect, it won't play. Similarly, if you include a redirect within a node that contains one or more routes (described below), the redirect will take precedence over user input.

lilypad1

One!

redirect:lilypad2

lilypad2

Two!

redirect:lilypad3

lilypad3

Three!

Loading the "lilypad1" node will result in the text "One! Two! Three!" being spoken.

Links

Of course, if you have a whole bunch of nodes, you need a way for the player to navigate between them other than automatic redirects.

Twine operates on hyperlinks: you click on a word anywhere inside a node, and it links you to somewhere else. Tinsel is closer to a "choose your own adventure" novel: while in a given node, the player can punch in certain numbers on their phone to link to another node. As a result, you need to think about linking a little bit differently in Tinsel than in normal Twine.

Here is an example of what your links should look like.

You have reached a fork in the road. Press 1 to go left, or 2 to go right.

[[1->left]]
[[2->right]]

This will use text-to-speach to read the first sentence to the player, and then listen for input. If the player presses 1, the node entitled "left" will play; if they press 2, the "right" node will play.

Note that Tinsel does not tell the player about the existence of links. It's up to you as the author to inform your player, through text-to-speech or recorded audio, what their options are. That previous example does that by explicitly telling the player that they can press 1 or 2, and what choice each of those numbers represents.

You can technically put Tinsel links anywhere in the node – they will be properly parsed as links, and not spoken by the text-to-speech engine – but it's recommended that you follow the convention of putting them at the end of the node.

"Any" links

You can also use the "any" label to create a link that will be followed if the player enters a number that doesn't have an explicit link connected to it:

What would you like for dinner? Press 2 for chicken, 4 for fish, or 6 for beef.

[[2->choseChicken]]
[[4->choseFish]]
[[6->choseBeef]]
[[any->choseUnknownFood]]

If the player enters anything other than 2, 4, or 6, they will be routed to the "choseUnknownFood" node.

"Timeout" links

Similarly, you can use the "timeout" label to specify a link that should be followed if the player doesn't enter anything after five seconds have passed.

Call it in the air! One for heads, two for tails.

[[1->heads]]
[[2->tails]]
[[timeout->tooSlow]]

Configuring links

What if you want to use a timeout link, but want the wait period to be shorter or longer than 5 seconds?

It's possible to configure a few options related to links:

• How long the timeout is (5s by default),
• How many digits are expected (default 1)
• If the player should press a specific key after finishing input (no by default).

If you've used Twilio before, these all corresponds to the options for the TwiML Gather verb (which Tinsel uses under the hood).

The price of a cheese pizza and a large soda at Panucci's Pizza is $10.77. To purchase, please enter your 4-digit pin, followed by the pound sign

[[any->emptyBankAccount]]

{{routeOptions}}
	{{timeout}}10{{
