godbolt.nvim

A powerful Neovim plugin that brings Compiler Explorer (godbolt.org) functionality directly into your editor. Compile your code to assembly, LLVM IR, or other intermediate representations in a split window, with bidirectional line mapping and LLVM optimization pipeline visualization.

Features

• Multi-format output: Assembly, LLVM IR, ClangIR, AST dumps, and object files
• Bidirectional line mapping: Click on source code to highlight corresponding assembly/IR, and vice versa
• LLVM pipeline viewer: Step through optimization passes for both C/C++ files and LLVM IR
• Link-Time Optimization (LTO): Compile and link multiple files with whole-program optimization
• LTO pipeline visualization: Watch cross-module optimizations in action (70+ passes)
• Multi-language support: C, C++, Swift, and LLVM IR
• Per-file compiler arguments: Use comments to specify flags per file
• Automatic output detection: Intelligently detects output type from compiler flags
• Clean output: Separates warnings/errors from the main output buffer

Quick Start

-- 1. Install the plugin using your package manager
{
  'lanza/godbolt.nvim',
  config = function()
    require('godbolt').setup()
  end,
}

-- 2. Open a C/C++ file and run
:Godbolt -O2

-- 3. To see LLVM optimization passes (C/C++ files):
:GodboltPipeline O2

-- 4. For multi-file Link-Time Optimization:
:GodboltLTO main.c utils.c
:GodboltLTOPipeline main.c utils.c -O2

-- Or for .ll files with custom passes:
:!clang -S -emit-llvm -O0 -Xclang -disable-O0-optnone % -o %:r.ll
:edit %:r.ll
:GodboltPipeline mem2reg,instcombine

Installation

Using lazy.nvim:

{
  'lanza/godbolt.nvim',
  config = function()
    require('godbolt').setup({
      -- Your configuration here (see Configuration section below)
    })
  end,
}

Using packer.nvim:

use {
  'lanza/godbolt.nvim',
  config = function()
    require('godbolt').setup()
  end
}

Requirements:

• Neovim 0.7+
• clang/clang++ for C/C++ compilation
• swiftc for Swift compilation (optional)
• opt (LLVM optimizer) for LLVM IR optimization and pipeline viewer (optional)

Lua API

All commands have corresponding Lua functions that accept an options table for programmatic control:

local gb = require('godbolt')

-- Basic compilation with output preference
gb.godbolt("", { output = "llvm" })    -- Force LLVM IR output
gb.godbolt("", { output = "asm" })     -- Force assembly output
gb.godbolt("", { output = "auto" })    -- Auto-detect (default)

-- LTO functions (always output LLVM IR)
gb.godbolt_lto(nil, "", { output = "llvm" })           -- Auto-detect files
gb.godbolt_lto({"main.c", "util.c"}, "-O2", { output = "llvm" })

gb.godbolt_lto_pipeline(nil, "-O2", { output = "llvm" })
gb.godbolt_lto_compare(nil, "-O3", { output = "llvm" })

Output Preference Behavior:

• output = "llvm": Auto-injects -emit-llvm when using compile_commands.json
• output = "asm": Uses assembly output (default for clang)
• output = "auto": No injection, uses compile_commands.json flags as-is
• Default for :Godbolt command: "llvm" (most useful for code inspection)
• Default for LTO commands: "llvm" (LTO always outputs LLVM IR)

When output = "llvm" is set and compile_commands.json is used, the plugin will automatically add -emit-llvm to the compiler flags unless you explicitly specify -emit-* or -S in your arguments.

Configuration

Configure the plugin in your init.lua:

require('godbolt').setup({
  -- Compiler paths (optional, uses these defaults)
  clang = 'clang',
  swiftc = 'swiftc',
  opt = 'opt',

  -- Default compiler arguments
  cpp_args = '-std=c++20',
  c_args = '-std=c17',
  swift_args = '',
  ll_args = '',

  -- Window configuration (optional)
  -- window_cmd = 'split' -- instead of default 'vertical botright new'

  -- Line mapping configuration (Godbolt-style source-to-assembly mapping)
  line_mapping = {
    enabled = true,         -- Enable automatic line mapping
    auto_scroll = false,    -- Auto-scroll windows when cursor moves (only scrolls if off-screen)
    throttle_ms = 150,      -- Throttle cursor updates (ms) for performance
    silent_on_failure = false,  -- Show error messages if debug info is missing
    show_compilation_cmd = true,  -- Show compilation command when debug info fails
  },

  -- Display configuration
  display = {
    strip_debug_metadata = true,   -- Hide debug metadata (!123 = !{...}) in LLVM IR
    annotate_variables = true,     -- Show variable names as comments (e.g., "; %5 = x")
  },

  -- Pipeline viewer configuration
  pipeline = {
    enabled = true,         -- Enable pipeline viewer
    show_stats = true,      -- Show instruction and basic block statistics
    start_at_final = false, -- Start at first pass instead of final result
    filter_unchanged = false, -- Filter out passes that don't change the IR

    -- Optimization remarks configuration (OFF by default)
    remarks = false,  -- Set to true to enable all categories
    -- OR granular control:
    -- remarks = {
    --   pass = true,        -- ✓ Show successful optimizations
    --   missed = true,      -- ✗ Show missed opportunities
    --   analysis = false,   -- ℹ Show detailed analysis (verbose)
    --   filter = "inline",  -- Regex filter for which passes (default: "inline")
    -- },
  },
})

All fields are optional and will use sensible defaults if not specified.

Commands

Basic Compilation

:Godbolt [compiler-args]

Compiles the current file to assembly/IR in a new split window.

Auto-Detection from compile_commands.json:

If you run :Godbolt without arguments, it will automatically use compiler flags from compile_commands.json for the current file if found:

" Auto-detect compiler flags from compile_commands.json
:Godbolt

" Or manually specify flags (overrides compile_commands.json)
:Godbolt -O3 -march=native

The plugin extracts flags like -O2, -std=c++20, -I, -D from your build system configuration and applies them automatically.

Examples:

:Godbolt              " Auto-detect flags or basic compilation
:Godbolt -O3          " With optimization
:Godbolt -O2 -march=native
:Godbolt -emit-llvm   " Output LLVM IR instead of assembly
:Godbolt -emit-cir    " Output ClangIR (MLIR)

Pipeline Viewer

:GodboltPipeline [passes]

Runs LLVM optimization passes and opens an interactive 3-pane viewer showing each pass's transformations.

Supported file types:

• .ll files: Use custom pass lists or O-levels
• .c/.cpp files: Use O-levels only (O0, O1, O2, O3)

Examples:

" For C/C++ files - view frontend optimization passes
:GodboltPipeline O2                 " Use O2 optimization level
:GodboltPipeline O3                 " Use O3 optimization level

" For .ll files - use custom passes or O-levels
:GodboltPipeline                    " Use default O2 pipeline
:GodboltPipeline O3                 " Use O3 optimization level
:GodboltPipeline mem2reg,instcombine " Run specific passes

" Workflow for custom passes on C/C++ code:
" 1. First compile to LLVM IR with O0
:Godbolt -emit-llvm -O0 -Xclang -disable-O0-optnone
" 2. Then run custom passes on the .ll file
:edit %:r.ll
:GodboltPipeline mem2reg,sroa,instcombine

Note: For C/C++ files, custom pass lists are not supported due to clang's compilation model. Compile to .ll first if you need custom passes.

Pass Scope Indicators:

The pipeline viewer shows scope indicators for each pass:

• [M] - Module pass: operates on the entire module (all functions, globals)
• [F] - Function pass: operates on a single function
• [C] - CGSCC pass: operates on a call graph strongly-connected component

Module passes show the full module before/after, while function passes show only the specific function being optimized.

Pipeline Navigation Commands:

• :NextPass - Navigate to the next optimization pass
• :PrevPass - Navigate to the previous optimization pass
• :GotoPass [N] - Jump to pass number N (or show picker if N omitted)
• :FirstPass - Jump to the first pass
• :LastPass - Jump to the last pass

Keybindings in Pipeline Viewer:

In the pass list pane:

• j/k - Navigate through all visible lines (modules, group headers, function entries)
• Tab/Shift-Tab - Jump to next/previous changed pass (auto-unfolds groups)
• Enter - Select and view the pass/function under cursor
• o - Toggle fold/unfold for groups (▸ → ▾)
• q - Quit the pipeline viewer
• g[ - Jump to first pass
• g] - Jump to last pass

In the before/after panes:

• ]p / [p or Tab / Shift-Tab - Next/Previous pass
• Standard diff commands (]c, [c for next/previous diff)

Pipeline Viewer Features:

• Smart Grouping: Function/CGSCC passes are grouped together
  • Groups display as ▸ [F] PassName (N functions) when folded
  • Press o or Enter to unfold and see individual functions
  • Module passes ([M]) automatically close all open groups
  • Interleaved passes are correctly merged into groups
• Auto-Unfold Navigation: Tab automatically unfolds groups when navigating to changed passes
• Sorted Functions: Within each group, changed functions appear first
• Visual Indicators:
  • > marks the currently selected pass/function
  • ● marks the selected function entry within an unfolded group
  • Changed passes/functions are highlighted in color
  • Unchanged passes/functions are grayed out
• All Groups Start Folded: Even groups with 1000+ functions start folded for usability

Optimization Remarks (Optional)

LLVM optimization remarks provide detailed information about optimization decisions made by the compiler. This is useful for und
