Schematic

<img src="/Schematics/schematic.png" width="300">

Configuration

Power up the device and connect to WiFi network NTRIPConfig. You should be forwarded to the WiFiManager WebUI, if not browse to 192.168.4.1 The config portal will disable itself after 25s (if not in use). Connecting pin config to GND skips the configuration phase.

Images

<img src="/Images/config1.jpg" width="200"><img src="/Images/config2.jpg" width="200"> <img src="/Images/menu.jpg" width="200"> <img src="/Images/esp.jpg" width="200">
