OSM Buildings is a JavaScript library for showing building geometry on interactive maps.

Example: https://osmbuildings.org/

The standalone WebGL version odf OSM Buildings is located here: https://github.com/OSMBuildings/OSMBuildings

There is also documentation of OSM Buildings Server side: https://github.com/kekscom/osmbuildings/blob/master/docs/server.md

Example https://osmbuildings.org/

It's safe use the master branch for production.

For further information visit https://osmbuildings.org, follow @osmbuildings on Twitter or report issues here on Github.

Documentation

Integration with Leaflet

Link Leaflet and OSM Buildings files in your HTML head section.

<head>
  <link rel="stylesheet" href="https://unpkg.com/leaflet@1.6.0/dist/leaflet.css"/>
  <script src="https://unpkg.com/leaflet@1.6.0/dist/leaflet.js"></script>
  <script src="OSMBuildings-Leaflet.js"></script>
</head>

Initialize the map engine and add a map tile layer.<br> Position is set to Berlin at zoom level 17, I'm using Mapbox tiles here.

var map = new L.Map('map').setView([52.52020, 13.37570], 17);
new L.TileLayer('https://{s}.tiles.mapbox.com/v3/<YOUR KEY HERE>/{z}/{x}/{y}.png',
  { attribution: 'Map tiles &copy; <a href="https://mapbox.com">Mapbox</a>', maxZoom: 17 }).addTo(map);

Add the buildings layer.

new OSMBuildings(map).load();

As a popular alternative, you could pass a <a href="http://www.geojson.org/geojson-spec.html">GeoJSON</a> FeatureCollection object.<br> Geometry types Polygon, Multipolygon and GeometryCollection are supported.<br> Make sure the building coordinates are projected in <a href="http://spatialreference.org/ref/epsg/4326/">EPSG:4326</a>.<br> Height units m, ft, yd, mi are accepted, no given unit defaults to meters.

var geoJSON = {
  "type": "FeatureCollection",
  "features": [{
    "type": "Feature",
    "id": 134,
    "geometry": {
      "type": "Polygon",
      "coordinates": [[
        [13.37356, 52.52064],
        [13.37350, 52.51971],
        [13.37664, 52.51973],
        [13.37594, 52.52062],
        [13.37356, 52.52064]
      ]]
    },
    "properties": {
      "wallColor": "rgb(255,0,0)",
      "roofColor": "rgb(255,128,0)",
      "height": 500,
      "minHeight": 0
    }
  }]
};

new OSMBuildings(map).set(geoJSON);

Integration with OpenLayers

NEW: for Integration with OpenLayers 5 see /tests/openlayers-5.3.0 *

Link OpenLayers and OSM Buildings files in your HTML head section.

<head>
  <script src="http://www.openlayers.org/api/OpenLayers.js"></script>
  <script src="OSMBuildings-OpenLayers.js"></script>
</head>

Initialize the map engine and add a map tile layer.<br> Position is set to Berlin at zoom level 17.

var map = new OpenLayers.Map('map');
map.addControl(new OpenLayers.Control.LayerSwitcher());

var osm = new OpenLayers.Layer.OSM();
map.addLayer(osm);

map.setCenter(
  new OpenLayers.LonLat(13.37570, 52.52020)
    .transform(
      new OpenLayers.Projection('EPSG:4326'),
      map.getProjectionObject()
    ),
  17
);

Add the buildings layer.

new OSMBuildings(map).load();

API

Constructors

<table> <tr> <th>Constructor</th> <th>Description</th> </tr> <tr> <td>new OSMBuildings(map)</td> <td>Initializes the buildings layer for a given map engine.<br> Currently Leaflet and OpenLayers are supported.</td> </tr> </table>

Constants

<table> <tr> <th>Option</th> <th>Type</th> <th>Description</th> </tr> <tr> <td>ATTRIBUTION</td> <td>String</td> <td>Holds OSM Buildings copyright information.</td> </tr> <tr> <td>VERSION</td> <td>String</td> <td>Holds current version information.</td> </tr> </table>

Methods

<table> <tr> <th>Method</th> <th>Description</th> </tr> <tr> <td>style({Object})</td> <td>Set default styles. See below for details.</td> </tr> <tr> <td>date(new Date(2017, 15, 1, 10, 30)))</td> <td>Set date/time for shadow projection.</td> </tr> <tr> <td>each({Function})</td> <td>A callback wrapper to override each feature's properties on read. Return false in order to skip a particular feature.<br> Callback receives a feature object as argument.</td> </tr> <tr> <td>click({Function})</td> <td>A callback wrapper to handle click events on features.<br> Callback receives an object { featureId{number,string}, lat{float}, lon{float} } as argument.</td> </tr> <tr> <td>set({GeoJSON FeatureCollection})</td> <td>Just add GeoJSON data to your map.</td> </tr> <tr> <td>load({Provider})</td> <td>Without parameter, it loads OpenStreetMap data tiles via an OSM Buildings proxy. This proxy enables transparent data filtering and caching. Interface of such provider is to be published.</td> </tr> </table>

Styles

<table> <tr> <th>Option</th> <th>Type</th> <th>Description</th> </tr> <tr> <td>color/wallColor</td> <td>String</td> <td>Defines the objects default primary color. I.e. #ffcc00, rgb(255,200,200), rgba(255,200,200,0.9)</td> </tr> <tr> <td>roofColor</td> <td>String</td> <td>Defines the objects default roof color.</td> </tr> <tr> <td>shadows</td> <td>Boolean</td> <td>Enables or disables shadow rendering, default: enabled</td> </tr> </table>

Data

OSM Tags used

<table> <tr> <th>GeoJSON property</th> <th>OSM Tags</th> </tr> <tr> <td>height</td> <td>height, building:height, levels, building:levels</td> </tr> <tr> <td>minHeight</td> <td>min_height, building:min_height, min_level, building:min_level</td> </tr> <tr> <td>color/wallColor</td> <td>building:color, building:colour</td> </tr> <tr> <td>material</td> <td>building:material, building:facade:material, building:cladding</td> </tr> <tr> <td>roofColor</td> <td>roof:color, roof:colour, building:roof:color, building:roof:colour</td> </tr> <tr> <td>roofMaterial</td> <td>roof:material, building:roof:material</td> </tr> <tr> <td>shape</td> <td>building:shape[=cylinder,sphere]</td> </tr> <tr> <td>roofShape</td> <td>roof:shape[=dome]</td> </tr> <tr> <td>roofHeight</td> <td>roof:height</td> </tr> </table>
