xnuspy

^{Output from the kernel log after compiling and running example/open1_hook.c}

xnuspy is a pongoOS module that installs a new system call, xnuspy_ctl, which allows you to hook kernel functions from userspace. It supports iOS 13.x, iOS 14.x, and iOS 15.x on checkra1n 0.12.2 and up. 4K devices are not supported.

This module completely neuters KTRR/KPP and makes it possible to create RWX memory inside EL1. Do not use this on your daily driver.

Requires libusb: brew install libusb

Building

Run make in the top level directory. It'll build the loader and the module.

Build Options

Add these before make.

• XNUSPY_DEBUG=1
  • Send debug output from xnuspy to the kernel log (kprintf).
• XNUSPY_SERIAL=1
  • Send debug output from xnuspy to IOLog.
• XNUSPY_LEAKED_PAGE_LIMIT=n
  • Set the number of pages xnuspy is allowed to leak before its garbage collection thread starts deallocating them. Default is 64. More info can be found under Debugging Kernel Panics.
• XNUSPY_TRAMP_PAGES=n
  • Set the number of pages xnuspy will reserve for its trampoline structures. Default is 1. More info can be found under Limits.

XNUSPY_DEBUG and XNUSPY_SERIAL do not depend on each other.

Usage

After you've built everything, have checkra1n boot your device to a pongo shell: /Applications/checkra1n.app/Contents/MacOS/checkra1n -p

In the same directory you built the loader and the module, do loader/loader module/xnuspy. After doing that, xnuspy will do its thing and in a few seconds your device will boot. loader will wait a couple more seconds after issuing xnuspy-getkernelv in case SEPROM needs to be exploited.

Known Issues

Sometimes a couple of my phones would get stuck at "Booting" after checkra1n's KPF runs. I have yet to figure out what causes this, but if it happens, try again. Also, if the device hangs after bootx, try again. Finally, marking the compiled xnuspy_ctl code as executable on my iPhone X running iOS 13.3.1 is a bit spotty, but succeeds 100% of the time on my other phones. If you panic with a kernel instruction fetch abort when you execute your hook program, try again.

xnuspy_ctl

xnuspy will patch an enosys system call to point to xnuspy_ctl_tramp. This is a small trampoline which marks the compiled xnuspy_ctl code as executable and branches to it. You can find xnuspy_ctl's implementation at module/el1/xnuspy_ctl/xnuspy_ctl.c and examples in the example directory.

Inside include/xnuspy/ is xnuspy_ctl.h, a header which defines constants for xnuspy_ctl. It is meant to be included in all programs which hook kernel functions.

You can use sysctlbyname to figure out which system call was patched:

size_t oldlen = sizeof(long);
long SYS_xnuspy_ctl = 0;
sysctlbyname("kern.xnuspy_ctl_callnum", &SYS_xnuspy_ctl, &oldlen, NULL, 0);

This system call takes four arguments, flavor, arg1, arg2, and arg3. The flavor can either be XNUSPY_CHECK_IF_PATCHED, XNUSPY_INSTALL_HOOK, XNUSPY_REGISTER_DEATH_CALLBACK, XNUSPY_CALL_HOOKME, XNUSPY_CACHE_READ, XNUSPY_KREAD, XNUSPY_KWRITE, or XNUSPY_GET_CURRENT_THREAD. The meaning of the next three arguments depend on the flavor.

XNUSPY_CHECK_IF_PATCHED

This exists so you can check if xnuspy_ctl is present. Invoking it with this flavor will cause it to return 999. The values of the other arguments are ignored.

XNUSPY_INSTALL_HOOK

I designed this flavor to match MSHookFunction's API. arg1 is the UNSLID address of the kernel function you wish to hook. If you supply a slid address, you will most likely panic. arg2 is a pointer to your ABI-compatible replacement function. arg3 is a pointer for xnuspy_ctl to copyout the address of a trampoline that represents the original kernel function. This can be NULL if you don't intend to call the original.

XNUSPY_REGISTER_DEATH_CALLBACK

This flavor allows you to register an optional "death callback", a function xnuspy will call when your hook program exits. It gives you a chance to clean up anything you created from your kernel hooks. If you created any kernel threads, you would tell them to terminate in this function.

Your callback is not invoked asynchronously, so if you block, you're preventing xnuspy's garbage collection thread from executing.

arg1 is a pointer to your callback function. The values of the other arguments are ignored.

XNUSPY_CALL_HOOKME

hookme is a small assembly stub which xnuspy exports through the xnuspy cache for you to hook. Invoking xnuspy_ctl with this flavor will cause hookme to get called, providing a way for you to easily gain kernel code execution without having to hook an actual kernel function.

arg1 is an argument that will be passed to hookme when it is invoked. This can be NULL.

XNUSPY_CACHE_READ

This flavor gives you a way to read from the xnuspy cache. It contains many useful things like kprintf, current_proc, kernel_thread_start, some libc functions, and the kernel slide so you don't have to find them yourself. For a complete list of cache IDs, check out example/xnuspy_ctl.h.

arg1 is one of the cache IDs defined in xnuspy_ctl.h and arg2 is a pointer for xnuspy_ctl to copyout the address or value of what you requested. The values of the other arguments are ignored.

XNUSPY_KREAD

This flavor gives you an easy way to read kernel memory from userspace without tfp0.

arg1 is a kernel virtual address, arg2 is the address of a userspace buffer, and arg3 is the size of that userspace buffer. arg3 bytes will be written from arg1 to arg2.

XNUSPY_KWRITE

This flavor gives you an easy way to write to kernel memory from userspace without tfp0.

arg1 is a kernel virtual address, arg2 is the address of a userspace buffer, and arg3 is the size of that userspace buffer. arg3 bytes will be written from arg2 to arg1.

XNUSPY_GET_CURRENT_THREAD

This flavor provides userspace the kernel address of the calling thread.

arg1 is a pointer for xnuspy_ctl to copyout the return value of current_thread. The values of the other arguments are ignored.

Errors

For all flavors except XNUSPY_CHECK_IF_PATCHED, 0 is returned on success. Upon error, -1 is returned and errno is set. XNUSPY_CHECK_IF_PATCHED does not return any errors. XNU's mach_to_bsd_errno is used to convert a kern_return_t to the appropriate errno.

Errors Pertaining to XNUSPY_INSTALL_HOOK

errno is set to...

• EEXIST if:
  • A hook already exists for the unslid kernel function denoted by arg1.
• ENOMEM if:
  • unified_kalloc returned NULL.
• ENOSPC if:
  • There are no free xnuspy_tramp structs, a data structure internal to xnuspy. This shouldn't happen unless you're hooking hundreds of kernel functions at the same time. If you need more function hooks, check out Limits.
• ENOTSUP if:
  • The caller is not from a Mach-O executable or dynamic library.
• ENOENT if:
  • mh_for_addr was unable to determine the Mach-O header corresponding to arg2 inside the caller's address space.
• EFAULT if:
  • The determined Mach-O header is not actually a Mach-O header. This will probably never happen.
• EIO if:
  • mach_make_memory_entry_64 did not return a memory entry for the entirety of the determined Mach-O header's __TEXT and __DATA segments.

errno also depends on the return value of vm_map_wire_external, mach_vm_map_external, mach_make_memory_entry_64, copyin, copyout, and if applicable, the one-time initialization function.

If this flavor returns an error, the target kernel function was not hooked. If you passed a non-NULL pointer for arg3, it may or may not have been initialized. It's unsafe to use if it was.

Errors Pertaining to XNUSPY_REGISTER_DEATH_CALLBACK

errno is set to...

• ENOENT if:
  • The calling process hasn't hooked any kernel functions.

If this flavor returns an error, your death callback was not registered.

Errors Pertaining to XNUSPY_CALL_HOOKME

errno is set to...

• ENOTSUP if:
  • hookme is too far away from the memory containing the xnuspy_tramp structures. This is determined inside of pongoOS, and can only happen if xnuspy had to fallback to unused code already inside of the kernelcache. In this case, calling hookme would almost certainly cause a kernel panic, and you'll have to figure out another kernel function to hook.

If this flavor returns an error, hookme was not called.

Errors Pertaining to XNUSPY_CACHE_READ

errno is set to...

• EINVAL if:
  • The constant denoted by arg1 does not represent anything in the cache.
  • arg1 was IO_LOCK, but the kernel is iOS 14.4.2 or below or iOS 15.x.
  • arg1 was IPC_OBJECT_LOCK, but the kernel is iOS 15.x.
  • arg1 was IPC_PORT_RELEASE_SEND, but the kernel is iOS 14.5 or above.
  • arg1 was IPC_PORT_RELEASE_SEND_AND_UNLOCK, but the kernel is iOS 14.4.2 or below.
  • arg1 was KALLOC_CANBLOCK, but the kernel is iOS 14.x or above.
  • arg1 was KALLOC_EXTERNAL, but the kernel is iOS 13.x.
  • arg1 was KFREE_ADDR, but the kernel is iOS 14.x or above.
  • arg1 was KFREE_EXT, but the kernel is iOS 13.x.
  • arg1 was PROC_REF, but the kernel is iOS 14.8 or below.
  • arg1 was PROC_REF_LOCKED, but the kernel is iOS 15.x.
  • arg1 was PROC_RELE, but the kernel is iOS 14.8 or below.
  • arg1 was PROC_RELE_LOCKED, but the kernel is iOS 15.x.
  • arg1 was VM_MAP_UNWIRE, but the kernel is iOS 15.x.
  • arg1 was VM_MAP_UNWIRE_NESTED, but the kernel is iOS 14.8 or below.

errno also depends on the return value of copyout and if applicable, the return value of the one-time initialization function.

If this flavor returns an error, the point
