bwalink

This is a docker container for https://github.com/ccutrer/balboa_worldwide_app that supports a remote serial to IP device or host running ser2net, socat or ESPEasy serial server.

There are 3 components to this solution:

A serial to IP device
Serial to MQTT which this docker image hosts
MQTT to Home Assistant

Installation and configuration of MQTT are beyond the scope of this project as there are a plethora of good articles on setting up an MQTT broker.

bwalink

<small><i><a href='http://ecotrust-canada.github.io/markdown-toc/'>Table of contents generated with markdown-toc</a></i></small>

Disclaimers and Legal Stuff First

As an Amazon Associate I earn from qualifying purchases. I get commissions for purchases made through links in this post. Most hot tubs are fed 240v and are capable of delivering 50-amps of current = 12,000 W so... electricity is dangerous and can cause personal injury or DEATH as well as other property loss or damage if not used or constructed properly. If you have any doubts whatsoever about performing do-it-yourself electrical work, PLEASE do the smart thing and hire a QUALIFIED SPECIALIST to perform the work for you.

NEVER WORK WITH LIVE VOLTAGE. Always disconnect the power source before working with electrical circuits.

Serial to IP Device

Elfin-EW11A-0

I've had great success with the Elfin-EW11A-0 from Hi-Flying Technology. It's a simple $24 RS-485 to WiFi device that takes an input voltage of 5-18VDC, has a web interface for remote admin and an external antenna.

Setup

Supply 5-18VDC to the 2 middle screw terminals as shown below to power up the unit
Connect to the wireless network named EW11_D650
In your browser, navigate to 10.10.100.254 and login with username: admin password: admin
Go to the system settings page and configure the WiFi Settings to match your network

Optionally You can setup a static IP address using the LAN Settings section. Just remember to turn DHCP Server to Off.

Click Submit
Go to the Others page and click Restart
Determine which IP the device acquired from DHCP or use the static IP you assigned and enter it in your browser
Login with username: admin password: admin. This is a good time to change those and will only affect the web admin.
Go to the Serial Port Settings section and configure as follows

Click Submit
Go to the Communication Settings section and configure as follows

Click Submit
Go to the Others page and click Restart

Connection Cable

You'll need an ATX Molex Micro Fit Connector to connect to the communications port of the Balboa equipment. I also recommend:

Silicone coated wire optional if you already have wire but much easier to work with
Heat Shrink Tubing or Electrical Tape
Soldering Iron and solder
Good wire strippers/cutters
Multimeter

My hot tub had a small Y-Cable hanging outside of the control box that you can plug into for power and to get to the RS-485 communications of the tub. If you don't have this cable, you can likely plug into the main control board if it has the same outlet type. This should be the same type of connector that goes to your control panel.

Note that the tab is on the left of the connector

Y-Cable

The connection is an ATX Molex Micro Fit Connector 4Pin (no, not the same as your old ATX power supply, I know, I tried too). Cut the one you ordered in half since you'll be making your own cable. Strip the ends of the ATX Molex Micro Fit connector. Be careful not to short anything and plug that into your tubs Y-cable or J33/J45 port. Confirm and tag the wires for +V, ground and RS-485 A/+ and B-, they should match the image.

Disconnect the cable and solder ~36-inches of Silicone coated wire onto each of the ends using the color that corresponds to the pin. Use some Heat Shrink Tubing or electrical tape to protect your soldered connections. I suggest crimping some 22AWG ferrules to the ends of those cables or you can just tin them and be careful.

You can now connect the wires as show in the image below to the screw block at the end of the EW11 interface cable.

NOTE: You can disconnect the terminal block to make it easier to work with.

EW11 Interface Conversion Cable

Y-Cable

Plug everything in and confirm you can access the web interface of the EW11.

I drilled a small hole in the bottom of the hot tubs plastic media device enclosure, routed the cable in and stashed the EW11 in there. The media pocket has the added benefit of being unshielded, unlike the rest of the tub which has foil insulation.

BWALink Docker Setup

Installation and configuration of Docker and docker-compose are beyond the scope of this project as there are a plethora of good articles on setting up Docker.

Download or copy the docker-compose.yaml file and modify the MQTT_URI and BRIDGE_IP to match your set up
Run docker-compose up -d and let Docker do its magic.

NOTE: MQTT_URI must be properly escaped, e.g. mqtt://useename:pa##word@10.1.10.2 would need to be mqtt://username:pa%23%23word@10.1.10.2. See https://www.urlencoder.org/ for details.

Alternatively, you can execute docker run --rm ghcr.io/jshank/bwalink:latest -e MQTT_URI='your_mqtt_uri' -e BRIDGE_IP='your_ew11_ip'

If everything went well, you can subscribe to the homie/# topic of your MQTT broker and should see something like this:

homie/bwa/$homie 4.0.0
homie/bwa/$name BWA Spa
homie/bwa/$state ready
homie/bwa/$nodes spa
homie/bwa/spa/$name BWA Spa
homie/bwa/spa/$type CL501X1
homie/bwa/spa/$properties priming,heatingmode,temperaturescale,24htime,heating,temperaturerange,currenttemperature,settemperature,filter1,filter2,pump1,pump2,pump3,light1,circpump
homie/bwa/spa/priming true
homie/bwa/spa/priming/$name Is the pump priming
homie/bwa/spa/priming/$datatype boolean
homie/bwa/spa/heatingmode ready

Run BWALink as a Home Aassistant Addon

If you use Home Assistant, you don't need to run your own docker setup - you can run it as an addon.

Under /addons, create a new directory called bwalink. More info: Tutorial: Making your first add-on
Copy the full content of ha-addon into the new directory
Open the Home Assistant frontend
Go to "Settings"
Click on "Add-ons"
Click "add-on store" in the bottom right corner.
On the top right overflow menu, click the "Check for updates" button
You should now see a new section at the top of the store called "Local add-ons" that lists your add-on!
Click on your add-on to go to the add-on details page.
Install your add-on
Adjust configuration
Start your add-on
Click on the "Logs" tab, and refresh the logs of your add-on, you should now see the details in your logs.

Home Assistant Configuration

If you have MQTT Discovery enabled, Home Assistant will get a new BWA device along with all of the discovered sensors and switches for the spa. Otherwise, you'll need to manually create them as follows.

Switches

  - platform: mqtt
    name: "Hot Tub 24hour Clock Mode"
    state_topic: "homie/bwa/spa/24htime"
    availability:
    - topic: "homie/bwa/$state"
      payload_available: "ready"
      payload_not_available: "lost"
    command_topic: "homie/bwa/spa/24htime/set"
    payload_on: "true"
    payload_off: "false"
    icon: mdi:wrench-clock

  - platform: mqtt
    name: "Hot Tub Pump 1 (Lounge)"
    state_topic: "homie/bwa/spa/pump1"
    availability:
    - topic: "homie/bwa/$state"
      payload_available: "ready"
      payload_not_available: "lost"
    command_topic: "homie/bwa/spa/pump1/set"
    payload_on: "toggle"
    payload_off: "toggle"
    state_on: 2
    state_off: 0
    icon: mdi:chart-bubble

  - platform: mqtt
    name: "Hot Tub Pump 2 (Seats)"
    state_topic: "homie/bwa/spa/pump2"
    availability:
    - topic: "homie/bwa/$state"
      payload_available: "ready"
      payload_not_available: "lost"
    command_topic: "homie/bwa/spa/pump2/set"
    payload_on: "toggle"
    payload_off: "toggle"
    state_on: 2
    state_off: 0
    icon: mdi:chart-bubble

  - platform: mqtt
    name: "Hot Tub Pump 3 (Feet)"
    state_topic: "homie/bwa/spa/pump3"
    availability:
    - topic: "homie/bwa/$state"
      payload_available: "ready"
      payload_not_available: "lost"
    command_topic: "homie/bwa/spa/pump3/set"
    payload_on: "toggle"
    payload_off: "toggle"
    state_on: 2
    state_off: 0
    icon
