pystark

Lineshape models for spectral emission from fusion plasma. Four line models are implemented. Not optimised!

Authorship:

• Joseph Allcock (joseph.allcock@durham.ac.uk for contact)
• James Harrison

Prerequisites

Python 3 only.

• numpy
• scipy
• matplotlib
• pandas
• f2py (used to wrap fortran90 code in python. This comes with numpy, but if there are any problems, check you are able to run 'f2py' from the terminal. When i run locally on macOS, i use the GNU Compiler Collection for the Fortran backend, which can be installed easily using homebrew: 'brew install gcc')

Installation

In the top-level cloned pystark directory run terminal command:

pip install -e . --user

Then from python try:

import pystark
pystark.demo()

to see if it is all working.

Objects

• pystark.demo(): Run this to see what is and isn't working. Demonstrates how to use each of the lineshape models, produces an example plot.
• pystark.BalmerLineshape(): Main class, see docstring and demo() for usage.

Line models

• Voigt: Using Griem's empirical scaling for Stark profile FWHM, assuming a Lorentzian lineshape. Quick, but inaccurate in the wings.
• Rosato: interpolates Rosato tabulated profiles (Stark-Zeeman), convolved with Doppler profile. Narrow parameter range but fine tabulated grid and self-consistent treatment of Stark-Zeeman effects. paper.
• Stehle: interpolates Stehle tabulated profiles (Stark-Doppler), convolved with Zeeman split lines (simple, strong-Zeeman approximation). This is SLOW (~0.5 sec to evaluate) and the tabulated grid is coarse -- included for its wide input parameter range. paper
• Stehle param: B. Lomanowski's parameterised model of the tabulated Stehle data. Quick AND accurate, thanks Bart!
