Warning: this software is very-much a work-in-progress at the moment, and the code is alpha-quality, (at best). This is not production code. It has very little in the way of tests, and is bound to be full of bugs.

libdumpalloc

libdumpalloc is a tool for monitoring and debugging (heap) memory usage on embedded Linux devices. It currently supports only MIPS devices, but may be enhanced in the future to support other architectures.

libdumpalloc is intended to be used on the target device and is intended to be LD_PRELOADed when started the program to be monitored.

Like many other malloc debuggers, it works by interposing malloc(), realloc(), calloc(), free() etc., to track memory allocation and deallocation events.

Additionally, it generates a stacktrace for each allocation/deallocation, which is then either logged to a file, or to a remote process, via a TCP socket.

The stacktrace is generated using instruction-scanning with a termination heuristic. This is an inherently processor-specific technique, and is the reason that libdumpalloc currently only works on MIPS. However, an advantage of this technique is that it works quite well with release builds, and doesn't require unwind tables (as would be required by libunwind).

readalloc

readalloc is a program that is intended to be run on a Linux development PC, and is capable of reading the data gathered by libdumpalloc, resolving addresses to symbol names, and producing reports.

Currently, readalloc can generate reports in Callgrind format, which can be read using KCachegrind, among other tools.

libdumpalloc doesn't require readalloc to operate, rather it is one tool that can be used with the generated output.

Licensing

libdumpalloc is licensed under LGPL. See libdumpalloc/COPYING.

readalloc is licensed under GPL3. See readalloc/COPYING.

Building

Prerequisities

Dependencies are deliberately kept to a minimum.

CMake is required for building.

libdumpalloc requires only a working toolchain, C library and libpthread.

readalloc requires Boost and ZLib to be installed on the build machine. It also uses BFD (part of GNU binutils), but the CMake build takes care of downloading and building this.

Building libdumpalloc.so

It is usual to cross-compile libdumpmalloc.so for the embedded device. In order to do this, it is necessary to feed CMake a toolchain file appropriate for the toolchain you are using. For example, my-mips-toolchain.cmake might look something like this:

	SET(CMAKE_SYSTEM_NAME Linux)
	SET(CMAKE_SYSTEM_VERSION 1)

	# specify the cross compiler
	SET(CMAKE_C_COMPILER   /opt/toolchains/my-mips-toolchain/bin/mipsel-linux-gcc)
	SET(CMAKE_CXX_COMPILER /opt/toolchains/my-mips-toolchain/bin/mipsel-linux-g++)

	# where is the target environment
	SET(CMAKE_FIND_ROOT_PATH  /opt/staging-rootfs)

	# search for programs in the build host directories
	SET(CMAKE_FIND_ROOT_PATH_MODE_PROGRAM NEVER)

	# for libraries and headers in the target directories
	SET(CMAKE_FIND_ROOT_PATH_MODE_LIBRARY ONLY)
	SET(CMAKE_FIND_ROOT_PATH_MODE_INCLUDE ONLY)

Assuming the dumpalloc source directory is in the current directory we then do this to build the library:

	mkdir dumpalloc-build-target
	cd dumpalloc-build-target
	cmake -DCMAKE_TOOLCHAIN_FILE=my-mips-toolchain.cmake ../dumpalloc/libdumpalloc
	make

Building and running libdumpalloc tests

Obviously, a native build is required in order to run the tests:

	mkdir dumpalloc-build-host
	cd dumpalloc-build-host
	cmake ../dumpalloc/libdumpalloc
	make

Building readalloc

	mkdir readalloc-build-host
	cd readalloc-build-host
	cmake ../dumpalloc/readalloc
	make

This will also build download the binutils source package and build BFD.

The resulting executable can be found in dumpalloc-build-host/readalloc/

Usage

Take a copy of the root filesystem from the embedded device

In order for readalloc to be able to decode the stack frames it receives from libdumpalloc, it must at least have access to the executable that is being monitored, and all libraries that are used by this executable. Since readalloc will be running on a PC, the simplest thing to do is to just take a local copy of the entire rootfs from the target device.

Dumping directly to readalloc over a socket

First, on the PC, launch readalloc on the PC. Since we want libdumpalloc to send the captured data directly to readalloc we need a listening socket, so we do this:

	nc -l 7000 | readalloc /path/to/device/rootfs

readalloc itself doesn't listen on a socket. We instead are using netcat (nc) to do this for us. readalloc then just reads from stdin. In this example we're using port 7000. /path/to/device/rootfs should be wherever you copied the root filesystem to.

Next, on the target device, launch the program to be monitored like this:

	DUMPALLOC_SERVER=mypc:7000 LD_PRELOAD=/some/path/libdumpalloc.so myprogram

Where mypc is the hostname, or address, of the PC running readalloc, and myprogram is the program you wish to monitor.

libdumpalloc will now begin capturing allocation events and sending them to the remote readalloc, which will maintain a live view of current allocations.

To generate a Callgrind output file, send SIGINT or SIGTERM to readalloc. On exiting, it will write a file named like: myprogram.1234.callgrind, where 1234 is the PID of the remote process.

Dumping to a file and processing offline

Sometimes there is no network connection between the target device and the PC. In this situation, libdumpalloc can be told to dump directly to a file. Launch it like this:

	DUMPALLOC_FILE=/some/file LD_PRELOAD=/some/path/libdumpalloc.so myprogram

Then, assuming the file can somehow later be transferred to the PC, it can be processed by readalloc by doing:

	cat /some/file | readalloc /path/to/device/rootfs

Dumping to a file and gzipping the output

Dump files quickly grow in size, but benefit greatly from compression. In order to keep libdumpalloc as simple as possible, it doesn't implement any compression of dump files. However, if you have netcat and gzip on the target you can do this:

	nc -lp 7000 | gzip -c > /somepath/myprog.dump.gz &

Followed by:

	DUMPALLOC_SERVER=localhost:7000 LD_PRELOAD=/some/path/libdumpalloc.so myprogram

Then, once the resulting file has been copied to the PC, do:

	gunzip -cd /somepath/myprog.dump.gz | readalloc /path/to/device/rootfs
