git2dot

Visualize a git repository using the graphviz dot tool optionally with pan and zoom.

It is useful for understanding how git works in detail. You can use it to analyze repositories before and after operations like merge and rebase to really get a feeling for what happens. It can also be used for looking at subsets of history on live repositories.

I have created a docker image to allow git2dot to be used without installing graphviz on the target system. See https://github.com/jlinoff/docker-images/tree/master/git2dot for details.

Here is an example that shows the PNG file generated by test04 in the test directory.

        <img src="https://cloud.githubusercontent.com/assets/2991242/22413672/a3357722-e66e-11e6-8cc8-332b5123a561.png" alt="test04 example">

Here is a quick rundown of what you are seeing:

1. The bisque (tan) nodes are commits. Each commit has the short id, the commit date, the subject (truncated to 32 characters) and the change-id (if it exists). The fields are the same for merged and squashed nodes as well.
2. The light red nodes are merged nodes. They are commits that resulted from a merge (they have 2 or more children).
3. The dark red nodes are squashed nodes. They are the end-points of squashed commit chains. Squashed commit chains do not have any branches, tags, change-ids or merges. They are just a long chain of work. If you turn off squashing, you will see 6 additional commit nodes and the two read squashed nodes will disappear.
4. The bluish boxes underneath commit and merge nodes are the branches associated with the commit. There is one box for each branch.
5. The light purple boxes above the commit and merge nodes are the tags associated with the commit. There is one box for each tag.
6. The arrows on the edges show the back (parent) pointer relationships from the repo. Git does not have child references.
7. The yellow box at the bottom is an optional graph label with custom text.

It works by running over the .git repository in the current directory and generating a commit relationship DAG that has both parent and child relationships.

The generated graph shows commits, tags and branches as nodes. Commits are further broken down into simple commits and merged commits where merged commits are commits with 2 or more children. There is an additional option that allows you to squash long chains of simple commits with no branch or tag data.

It has a number of different options for customizing the nodes, using your own custom git command to generate the data, keeping the generated data for re-use, customizing dot directly and generating graphical output like PNG, SVG or even HTML files.

Here is an example run:

   $ cd SANDBOX
   $ git2dot.py --png git.dot
   $ open -a Preview git.dot.png  # on Mac OS X
   $ display git.dot.png          # linux

If you want to create a simple HTML page that allows panning and zooming of the generated SVG then use the --html option like this.

   $ cd SANDBOX
   $ git2dot.py --svg --html ~/web/index.html ~/web/git.dot
   $ $ ls ~/web
   git.dot          git.dot.svg      git.html         svg-pan-zoom.js
   $ cd ~/web
   $ python -m SimpleHTTPServer 8090  # start server
   $ # Browse to http://localhost:8090/git.dot.svg

It assumes that existence of svg-pan-zoom.js from the https://github.com/ariutta/svg-pan-zoom package.

The output is pretty customizable. For example, to add the subject and commit date to the commit node names use -l '%s|%cr'. The items come from the git format placeholders or variables that you define using -D. The | separator is used to define the end of a line. The maximum width of each line can be specified by -w. Variables are defined by -D and come from text in the commit message. See -D for more details.

You can customize the attributes of the different types of nodes and edges in the graph using the -?node and -?edge attributes. The table below briefly describes the different node types:

| Node Type | Brief Description | | --------- | ----------------- | | bedge | Edge connecting to a bnode. | | bnode | Branch node associated with a commit. | | cnode | Commit node (simple commit node). | | mnode | Merge node. A commit node with multiple children. | | snode | Squashed node. End point of a sequence of squashed nodes. | | tedge | Edge connecting to a tnode. | | tnode | Tag node associated with a commit. |

If you have long chains of single commits use the --squash option to squash out the middle ones. That is generally helpful for filtering out extraneous commit details for moderately sized repos.

If you find that dot is placing your bnode and tnode nodes in odd places, use the --crunch option to collapse the bnode nodes into a single node and the tnodes into a single node for each commit.

If you want to limit the analysis to commits between certain dates, use the --since and --until options.

If you want to limit the analysis to commits in a certain range use the --range option.

If you want to limit the analysis to a small set of branches or tags you can use the --choose-branch and --choose-tag options. These options prune the graph so that only parents of commits with the choose branch or tag ids are included in the graph. This gives you more detail controlled that the git options allowed in the --range command. It is very useful for determining where branches occurred.

You can choose to keep the git output to re-use multiple times with different display options or to share by specifying the -k (--keep) option.

Use the -h option to get detailed information about the available options.

Example

The following example shows how to use git2dot by creating a git repository from scratch and then running the tool to create images.

First we create a repository with a bunch of commits and branches.

git init

echo 'A' >README
git add README
git commit -m 'master - first'
sleep 1

echo 'B' >>README
git add README
git commit -m 'master - second' -m 'Change-Id: I001'
sleep 1

# tag the basis for all of the branches
git tag -a 'v1.0' -m 'Initial version.'
git tag -a 'v1.0a' -m 'Another version.'

git checkout -b branchX1
git checkout master
git checkout -b branchX2

git checkout master
git checkout -b branchA
echo 'C' >> README
git add README
git commit -m 'branchA - first'
sleep 1

echo 'B' >> README
git add README
git commit -m 'branchA - second' -m 'Change-Id: I001'
sleep 1

git checkout master
git checkout -b branchB
echo 'E' >> README
git add README
git commit -m 'branchB - first'
sleep 1

echo 'F' >> README
git add README
git commit -m 'branchB - second'
sleep 1

echo 'B' >> README
git add README
git commit -m 'branchB - third' -m 'Change-Id: I001'
sleep 1

echo 'H' >> README
git add README
git commit -m 'branchB - fourth' -m 'Change-Id: I002'
sleep 1

echo 'I' >> README
git add README
git commit -m 'branchB - fifth'
sleep 1

echo 'J' >> README
git add README
git commit -m 'branchB - sixth'
sleep 1

echo 'K' >> README
git add README
git commit -m 'branchB - seventh'
sleep 1

git checkout master
echo 'L' >> README
git add README
git commit -m 'master - third'

You can verify the repo structure using something like git log.

$ git log --graph --oneline --decorate --all
* da0165b (HEAD -> master) master - third
| * 8e3cf50 (branchB) branchB - seventh
| * e0420c1 branchB - sixth
| * f51497b branchB - fifth
| * cee652e branchB - fourth
| * 2fc95e6 branchB - third
| * 9c654d8 branchB - second
| * 33fbc07 branchB - first
|/
| * 20ea3d2 (branchA) branchA - second
| * 71a0d0c branchA - first
|/
* ecdc7dc (tag: v1.0a, tag: v1.0, branchX2, branchX1) master - second
* c8ae444 master - first

Now run the git2dot tool to generate PNG, HTML and SVG files.

$ git2dot.py --png --svg --html example.html example.dot
$ ls -1 example.*
example.dot
example.dot.svg
example.html

You can now view the PNG and SVG files using local tools.

$ open -a Preview example.dot.png  # on Mac
$ display example.dot.png          # on Linux

To view the generated SVG file with pan and zoom you must download the svg-pan-zoom.min.js file from https://github.com/ariutta/svg-pan-zoom and copy into the current directory.

$ cp ~/work/svg-pan-zoom-3.4.1/dist/svg-pan-zoom.min.js .
$ ls -1 example* svg*
example.dot
example.dot.svg
example.html
svg-pan-zoom.min.js

Now you need to start a server.

$  python -m SimpleHTTPServer 8090

After that you can browse to http://localhost:8090/example.html and you will see this.

        <img src="https://cloud.githubusercontent.com/assets/2991242/22431235/b585cf7e-e6c5-11e6-8f17-6b99847bfe51.png" width="1100" alt="example">

As you can see, there is a long chain of commits, to run it again using the --squash option.

$ git2dot.py --squash --png --svg --html example1.html example1.dot

And browse to http://localhost:8090/example1.html and you will see this.

        <img src="https://cloud.githubusercontent.com/assets/2991242/22431252/c5077344-e6c5-11e6-95b0-54cd02d11aa2.png" width="1100" alt="example1">

Which is a cleaner view of the overall structure.

You will also note that there are two branches and two tags on ecdc7dc. They can be collapsed using the --crunch option like this.

$ git2dot.py --crunch --squash --png --svg --html example1.html example1.dot

When you browse to http://localhost:8090/example2.html and you will see this.

        <img src="https://cloud.githubusercontent.com/assets/2991242/22431258/c89d7e7c-e6c5-11e6-826e-cf7450b9f125.png" width="1100" alt="example2">

For such a small graph the crunch ope
