opnsense

OpnSense Custom Auto update of alias lists to Block of bad acting IP Addresses as detected in the /var/log/filter.log file. Also includes auto allow for service IP addresses such as Amazon, Facebook, Microsoft, etc..

Looking for

Looking for anyone who can provide some guidnace on implementing this capability via the OpnSense web interface. Having some trouble with the HelloWorld example and my limited PHP knowledge.

Prerequisits

Create an OpnSense API key. Instructions can be found at https://docs.opnsense.org/development/how-tos/api.html.

Implementation

1. Copy actions_autoblock.conf to /usr/local/opnsense/service/conf/actions.d/
2. Copy actions_autoallow.conf to /usr/local/opnsense/service/conf/actions.d/
3. Copy rc.autoblock /to /usr/local/etc/
4. Copy rc.autoallow /to /usr/local/etc/
5. Create an Alias called BlockedAuto

Firewall -> Aliases

| Field | Value | |-------------|------------------------------------| | Enabled | checked | | Name | BlockedAuto | | Type | URL (IPs) | | Content | https://127.0.0.1/blocked.txt | | Statistics | unchecked | | Description | Auto Block Bad Acting IP Addresses |

6. Create an Alias called AllowedAuto

Firewall -> Aliases

| Field | Value | |-------------|------------------------------------| | Enabled | checked | | Name | AllowedAuto | | Type | URL (IPs) | | Content | https://127.0.0.1/allowed.txt | | Statistics | unchecked | | Description | Auto Allow Addresses for Services |

7. Add outgoing Firewall Rule to WAN

Firewall -> Rules -> WAN

| Field | Value | |---------------------------|-----------------------------------| | Action: | Block | | Disabled: | unchecked | | Quick: | checked | | Interface: | WAN | | Direction: | out | | TCP/IP Version: | IPv4 | | Protocol: | any | | Source / Invert: | unchecked | | Source: | BlockedAuto | | Destination / Invert: | unchecked | | Destination: | any | | Destination port range: | any to any | | Log: | checked | | Category: | Blocked | | Description: DROP: | Blocked Bad Acting IPs (In) | | Source OS: | any | | No XMLRPC Sync: | unchecked | | Schedule: | none | | Gateway: | default |

8. Add incoming Firewall Rule to WAN

Firewall -> Rules -> WAN

| Field | Value | |---------------------------|-----------------------------------| | Action: | Block | | Disabled: | unchecked | | Quick: | checked | | Interface: | WAN | | Direction: | out | | TCP/IP Version: | IPv4 | | Protocol: | any | | Source / Invert: | unchecked | | Source: | any | | Destination / Invert: | unchecked | | Destination: | BlockedAuto | | Destination port range: | any to any | | Log: | checked | | Category: | Blocked | | Description: DROP: | Blocked Bad Acting IPs (In) | | Source OS: | any | | No XMLRPC Sync: | unchecked | | Schedule: | none | | Gateway: | default |

9. Add outgoing Firewall Rule to WAN, put these before any GeoBlock rules so the services will work regardless of country blocking rules.

Firewall -> Rules -> WAN

| Field | Value | |---------------------------|-----------------------------------| | Action: | PASS | | Disabled: | unchecked | | Quick: | checked | | Interface: | WAN | | Direction: | out | | TCP/IP Version: | IPv4 | | Protocol: | any | | Source / Invert: | unchecked | | Source: | AllowedAuto | | Destination / Invert: | unchecked | | Destination: | any | | Destination port range: | 80 to 80 | | Log: | checked | | Category: | ALLOWED | | Description: DROP: | ALLOW Service IPs (out) | | Source OS: | any | | No XMLRPC Sync: | unchecked | | Schedule: | none | | Gateway: | default |

10. Add outgoing Firewall Rule to WAN

Firewall -> Rules -> WAN

| Field | Value | |---------------------------|-----------------------------------| | Action: | PASS | | Disabled: | unchecked | | Quick: | checked | | Interface: | WAN | | Direction: | out | | TCP/IP Version: | IPv4 | | Protocol: | any | | Source / Invert: | unchecked | | Source: | AllowedAuto | | Destination / Invert: | unchecked | | Destination: | any | | Destination port range: | 443 to 443 | | Log: | checked | | Category: | ALLOWED | | Description: DROP: | ALLOW Service IPs (out) | | Source OS: | any | | No XMLRPC Sync: | unchecked | | Schedule: | none | | Gateway: | default |

11. Run the following to refresh the Available CRON job entries list.

service configd restart

12. Add CRON entries for Block and Allow lists

System -> Settings -> CRON

Update Allowed Destination Alias

12. Add CRON entries for Block and Allow lists

System -> Settings -> CRON

Update Auto Blocked Alias
