Grtrans

This is the README file for the code grtrans, which performs polarized general relativistic radiative transfer via ray tracing. The code is described in Dexter (2016), and uses geokerr (Dexter & Agol 2009). If you use grtrans in your own work, please cite those two papers.

This package contains the Fortran source code files (upper level routines in f90 with geodesic calculations, integration, and some other pieces in f77). In addition to these files, cfitsio must be installed. The Makefile.top.sample file should be edited and renamed to Makefile.top. It should include the desired f90 compiler and options, as well as the location of grtrans and the cfitsio library if it is not in the standard library path. The code can then be compiled with make.

For using the Python module, pyfits should also be installed.

QUICK START

Examples of running the code can be found in run_grtrans_test_problems_public.py. The examples called THINDISK, BL09JET, and HARM were used to make Figures 5, 6, and 8 respectively (although for the HARM problem with polarization the argument nvals=4 is needed to use all 4 Stokes parameters).

The test problems script uses both of the methods for running grtrans through Python, as its own module (pgrtrans) or by using input files. See below for more detailed instructions and information on variable names.

RUNNING GRTRANS WITH PYTHON SCRIPT

The easiest way to run grtrans is with the included python script, grtrans_batch.py. From the Python / iPython command line, do:

import grtrans_batch as gr x=gr.grtrans() x.compile_grtrans() x.write_grtrans_inputs('inputs.in') x.run_grtrans() x.read_grtrans_output() x.disp_grtrans_image(0)

All of the inputs are set by write_grtrans_inputs, which can be changed from their default values with keywords, e.g. here are some sample runs you could try (with x.run_grtrans() etc. after each one):

Standard thin disk (stellar mass black hole x-ray images / spectra) x.write_grtrans_inputs('inputs.in',nfreq=25,nmu=1,fmin=2.41e17,fmax=6.31e18,fname="THINDISK")

Numerical inhomogeneous disk model from Dexter & Agol (2011) (toy model so completely pixellated disk) x.write_grtrans_inputs('inputs.in',fname="NUMDISK",nfreq=25,nmu=1,fmin=2.41e17,fmax=6.31e18,ename="BB")

Semi-analytic model for M87 jet by Broderick & Loeb (2009) x.write_grtrans_inputs('inputs.in',fname="FFJET",nfreq=25,nmu=1,fmin=2.41e10,fmax=6.31e14,ename="POLSYNCHPL",nvals=4,spin=0.998,standard=1,nn=[100,100,100],uout=0.01,mbh=6.4e9)

Bondi spherical accretion problem but in GR x.write_grtrans_inputs('inputs.in',fname="SPHACC",nfreq=25,nmu=1,fmin=2.41e10,fmax=6.31e14,ename="POLSYNCHTH",nvals=4,spin=0.,standard=1,nn=[100,100,100])

read_grtrans_output() reads the output into the grtrans object variables ab, nu, spec, ivals which contain the alpha and beta values of the image (camera pixel locations in x and y), observed frequencies, observed spectrum, and observed intensities. The number of Stokes parameters (1 or 4) is set by the input parameter nvals.

INPUT PARAMETERS

The file files.in tells the code the name of the input and output files, set in the python script by iname and oname and using the method set_grtrans_input_file(iname,oname).

The main input file has the following namelists / variables:

geodata -- geodesic-related parameter namelist

standard -- method for computing geodesics. =2 for tracing in polar angle (e.g., to the equatorial plane of a thin disk) and =1 for tracing in radius (e.g., through an extended accretion flow).

mumin, mumax, nmu -- Minimum/maximum/number of mu = cos(i) of observer camera(s). mu=1,0 corresponds to face-on, edge-on.

spin -- dimensionless black hole spin -1 < spin < 1.

uout, uin -- When standard=1, npts points are saved evenly spaced between uout and uin. uout should correspond to the outermost location to use for calculating radiation, and uin=1 traces up to the event horizon.

rcut, nrotype -- camera shape parameters, should = 1.0, 2.

gridvals -- Camera extent in impact parameters alpha and beta.

nn -- number of x pixels, y pixels, and points along each pixel (npts). The camera pixel spacing is set by (gridvals(2)-gridvals(1))/nn(1), (gridvals(4)-gridvals(3))/nn(2). The geodesic resolution is similarly (uout-uin)/nn(3) when standard=1.

i1, i2 -- starting and ending geodesic index. By default these values are 1 and nn(1)*nn(2) so that intensities will be calculated for the entire camera. Instead setting these values to span a smaller range is useful for debugging (e.g. i1=i2=some index that is of interest to study in detail).

extra -- output a large number of quantities as function of geodesic position to the file geodebug.out. This is used for debugging, especially in combination with i1=i2 to run only a single geodesic and study the output in detail. The current variables that are output to that file can be found in read_geodebug_file.py and used in python as e.g. import read_geodebug_file as d after the file is created.

debug -- calculates "images" of many other ray-averaged or ray-integrated quantities, which are stored in the output as though they are additional Stokes parameters. These are:

\tau_I \tau_Q \tau_U \tau_V \tau_\rhoQ \tau_\rhoV

which are the total optical depth along the ray for the transfer coefficients \alpha_I,Q,U,V and \rho_Q,V. In addition the following quantities are unpolarized Stokes I intensity weighted, e.g.

xbar = \int d\lambda x(\lambda) j e^-\tau / \int d\lambda j e^-\tau

for the quantities x, which are:

r \theta \phi n T_e B \beta

and the last quantity is \beta = p_gas / p_mag.

fluiddata -- Fluid model related parameters

fname -- name of fluid model. Possibilities are:

    "THINDISK" -- Shakura & Sunyaev (1973), Novikov & Thorne (1973) thin accretion disk
  	solution with Page & Thorne (1974) extension to GR. For this model should use
standard=2, muf=0.0, nn(3)=1 (equatorial plane). Emission is usually
BB, FBB, BBPOL, FBBPOL.

"PHATDISK" -- Dexter & Agol (2011) "no-zone" inhomogeneous disk model. The average
surface brightness of each annulus is the same as in THINDISK, but the temperature in
each annulus is assumed to be log-normally distributed with width
\sigma = (log(10) \sigma_T)^2 / 2. Geodesic parameters same as THINDISK, emission
from INTERPEMIS.

"NUMDISK" -- Generic optically thick, geometrically thin disk model specified by
Teff(r,\phi). Geodesic parameters and emissivities same as THINDISK.

"SPHACC" -- General relativistic version of Bondi (1952) spherical accretion solution
based on Michel (1972) (see also Shapiro & Teukolsky 1983). For this model use
standard=1, uout > 0.0025 (where stored numerical flow solution begins). Emission
is usually synchrotron (SYNCHEMIS, POLSYNCHEMIS, SYNCHPL, POLSYNCHPL).

"FFJET" -- Semi-analytic jet model of Broderick & Loeb (2009). Quantities are
specified numerically. Geodesic parameters are standard=1, uout > umin where umin
is determined by outer radius saved for numerical solution. (WHAT IS IT IN MY DEFAULT?)


"HARM" -- Numerical general relativistic MHD (GRMHD) accretion flow model from publicly
available HARM code (Gammie et al. 2003, Noble et al. 2006). Template for other 2D
numerical models. Requires time-dependent rad trans, coordinate transformations
(KS <--> BL), ability to read HARM binary files.

"HOTSPOT" -- Time-dependent orbiting hotspot model of Schnittman & Bertschinger (2004),
Broderick & Loeb (2006), etc. Geodesic parameters are same as THINDISK.

emisdata -- Emissivity related parameters

ename -- Name of emission model. The possibilities so far are:

  "lambda" -- emissivity = affine parameter of ray. Unphysical but useful for geodesic
  tests.

  "INTERP" -- Interpolate numerically stored emission/absorption coefficients to desired
  observed frequencies. Used i.e. with PHATDISK.

  "INTERPPOL" -- same as INTERP but for polarized case.

  "BB" -- Blackbody emissivity. Also used to compute absorption coefficients for synchrotron
  emissivities from Kirchoff's Law.

  "BBPOL" -- Like BB but with other Stokes parameters (set to zero). Used for polarized
  thin disk problems for example.

  "FBB" -- Color-corrected blackbody emissivity fbnu(T,f,nu)=f**(-4) bnu(f*T,nu).

  "POLSYNCHTH" -- Polarized synchrotron emission from a thermal particle distribution.
  Emission coefficients from Huang et al. (2009), Dexter (2011) based on Melrose (1983?).
  Absorption from Kirchoff's assuming LTE.

  "POLSYNCHPL" -- Polarized synchrotron emission from a power law particle distribution.
  Emission & absorption coefficients from Dexter (2011) based on Melrose (1983?). Take into
  account lower/upper energy cutoffs to the distribution.

  TO ADD:

  "EMISTABLE" -- Interpolation of emissivity to fluid variables e.g. n, B, T for synchrotron
  radiation for arbitrary distribution function. Could calculate table in advance and store,
  then use EMISTABLE to calculate at observed frequency and fluid vars.

Each fluid model and emissivity has associated parameters, e.g. for specifying the accretion rate onto the black hole for a numerical simulation or the cutoff Lorentz factors for synchrotron emission from a power law distributed population of electrons.

OUTPUT FORMAT

Code output is either stored in FITS or plain binary format.

When using the python as above, you can do

x.read_grtrans_output()

after which the intensity values will be an array x.ivals, and the spectrum will be in x.spec.

In python, you could then do for example

x.disp_grtrans_image(0)

to view the first image, and change the argument 0 to choose different images (e.g. with different observed frequencies or other parameter
