Motivation

The bff (Backend for Frontend) proxy was built out of the requirement to have an API-aware proxy that is capable of routing, filtering, verifying and modifing HTTP request and response.

It is built on top of Google's Martian proxy framework, therefore bff supports the same built-in modifiers as martian does by default.

In addition to that, it provides a modifier to fetch and aggregate remote resources. Additionally, modifiers to merge and patch request and responses are provided out of the box.

These modifiers can be composed together to solve most use-cases that a BFF service may need.

You can learn more about the BFF cloud pattern here:

https://www.thoughtworks.com/insights/blog/bff-soundcloud
https://samnewman.io/patterns/architectural/bff/

Install

Executable

# make a temp directory
cd $(mktemp -d)

# download the bff executable into it
curl -sfL https://github.com/imranismail/bff/releases/download/v0.6.3/bff_0.6.3_Linux_x86_64.tar.gz | tar xvz

# move it into $PATH dir
mv bff /usr/local/bin

# test it
bff --help

Container

Github Container Registry

Supported Flags

  -c, --config string      config file (default is $XDG_CONFIG_HOME/bff/config.yaml)
  -h, --help               help for bff
  -i, --insecure           Skip TLS verify
  -p, --port string        Port to run the server on (default "5000")
  -u, --url string         Proxy url
  -v, --verbosity int      Verbosity

Usage

The proxy is configured with a YAML configuration file. The file path can be set using the --config flag, it defaults to $XDG_CONFIG_HOME/bff/config.yaml

Executable

bff <<YAML
# fetch resources concurrently
- body.MultiFetcher:
    resources:
      - body.JSONResource:
          method: GET
          url: https://jsonplaceholder.typicode.com/users/1
          behavior: replace # replaces upstream http response
          modifier:
            status.Verifier:
              statusCode: 200 # verify that the resource returns 200 status code
      - body.JSONResource:
          method: GET
          url: https://jsonplaceholder.typicode.com/users/1/todos
          behavior: merge # merge with the previous resource
          group: todos # group this response into "todos" key
          modifier:
            status.Verifier:
              statusCode: 200 # verify that the resource returns 200 status code
- body.JSONPatch:
    scope: [response]
    patch:
      - {op: move, from: /todos, path: /Todos}
YAML

Container

# make a temp directory
cd $(mktemp -d)

# create config file
cat > config.yml <<EOF
modifiers: |-
  # fetch resources concurrently
  - body.MultiFetcher:
      resources:
        - body.JSONResource:
            method: GET
            url: https://jsonplaceholder.typicode.com/users/1
            behavior: replace # replaces upstream http response
            modifier:
              status.Verifier:
                statusCode: 200 # verify that the resource returns 200 status code
        - body.JSONResource:
            method: GET
            url: https://jsonplaceholder.typicode.com/users/1/todos
            behavior: merge # merge with the previous resource
            group: todos # group this response into "todos" key
            modifier:
              status.Verifier:
                statusCode: 200 # verify that the resource returns 200 status code
  - body.JSONPatch:
      scope: [response]
      patch:
        - {op: move, from: /todos, path: /Todos}
EOF

# run it
docker run --rm -it -v $(pwd)/config.yml:/srv/config.yml ghcr.io/imranismail/bff:latest

Config Reference

`config.yml`

# env: BFF_INSECURE
# flag: --insecure -i
# type: bool
# required: false
# default: false
insecure: false

# env: BFF_PORT
# flag: -p --port
# type: int
# required: false
# default: 5000
port: 5000

# env: BFF_URL
# flag: -u --url
# type: string
# required: false
url: ""

# env: BFF_VERBOSITY
# flag: -v --verbosity
# type: int
# required: false
# default: 1
# options:
# - panic 5
# - fatal 4
# - error 3
# - warn 2
# - info 1
# - debug 0
# - trace -1
verbosity: 1

# env: BFF_MODIFIERS
# flag: N/A instead it can be set via linux pipe. example: `cat modifiers.yaml | bff` or `bff <<EOF ...config EOF`
# type: string
# required: false
# default: ""
modifiers: |
  - body.MultiFetcher:
      resources:
        - body.JSONResource:
            method: GET
            url: https://jsonplaceholder.typicode.com/users/1
            behavior: replace # replaces upstream http response
            modifier:
              status.Verifier:
                statusCode: 200 # verify that the resource returns 200 status code
        - body.JSONResource:
            method: GET
            url: https://jsonplaceholder.typicode.com/users/1/todos
            behavior: merge # merge with the previous resource
            group: todos # group this response into "todos" key
            modifier:
              status.Verifier:
                statusCode: 200 # verify that the resource returns 200 status code
  - body.JSONPatch:
      scope: [response]
      patch:
        - {op: move, from: /todos, path: /Todos}

Modifiers

This reference is adapted from Martian's wiki

Modifiers are able to mutate a request, a response or both.

JSONResource

The body.JSONResource fetches a remote JSON resource and merges/replaces the upstream response body with the response of the remote request depending on the behavior option. Defaults to the merge behavior.

The merging is done using RFC7386: JSON Merge Patch

body.JSONResource:
  scope: [response]
  method: GET
  url: https://jsonplaceholder.typicode.com/users/1
  behavior: replace # replaces upstream http response
  allowedHeaders: ["Authorization"] # allow downstream req headers
  modifier:
    status.Verifier:
      statusCode: 200

JSONPatch

The body.JSONPatch patches the JSON request or response body using RFC6902: JSON Patch

body.JSONPatch:
  scope: [response]
  patch:
    - { op: move, from: /todos, path: /Todos }
    - { op: add, path: /foo, value: ":foo" } # substitution using values extracted from bff.URLFilter

JSONMapPatch

The body.JSONMapPatch is like body.JSONPatch except that it applies the patch over a collection.

body.JSONMapPatch:
  scope: [response]
  path: /array # optional, defaults to /
  patch:
    - { op: move, from: /todos, path: /Todos }
    - { op: add, path: /foo, value: ":foo" } # substitution using values extracted from bff.URLFilter

Method

The bff.MethodModifier will modify the HTTP method, supported options are listed here https://go.googlesource.com/go/+/go1.16.2/src/net/http/method.go#10

bff.MethodModifier:
  scope: [request]
  method: POST

Skip

The skip.RoundTrip skips the HTTP roundtrip to the upstream URL that was specified via the --url flag

skip.RoundTrip:
  scope: [request]

Cookie

The cookie.Modifier injects a cookie into a request or a response.

Example configuration that injects a Martian-Cookie cookie into responses:

cookie.Modifier:
  scope: [response]
  name: Martian-Cookie
  value: some value
  path: "/some/path"
  domain: example.com
  expires: "2025-04-12T23:20:50.52Z" # RFC 3339
  secure: true
  httpOnly: false
  maxAge: 86400

Header

The header.Modifier injects or modifies headers in a request or a response.

Example configuration that injects an X-Martian header with the value of true into requests:

header.Modifier:
  scope: [request]
  name: X-Martian
  value: "true"

Header Blacklist

The header.Blacklist deletes headers from a request or a response.

Example configuration that deletes response headers with the names X-Martian and Y-Martian:

header.Blacklist:
  scope: [response]
  names: [X-Martian, Y-Martian]

Query String

The querystring.Modifier adds or modifies query string parameters on a request. Any existing parameter values are replaced.

Example configuration that sets the query string parameter foo to the value of bar on requests and responses:

querystring.Modifier:
  scope: [request, response]
  name: foo
  value: bar

The additional bff.querystringModifier allows copying and renaming the parameters.

Example configuration that copies the value of foo to fuu and rename the field bar to baz:

bff.QueryStringModifier
  scope: [request]
  op: copy
  name: foo
  value: fuu

bff.QueryStringModifier
  scope: [request]
  op: move
  name: bar
  value: baz

Status

The status.Modifier modifies the HTTP status code on a response.

Example configuration that sets the HTTP status of responses to 200:

status.Modifier:
  scope: [response]
  statusCode: 200

URL

The url.Modifier modifies the URL on a request.

Example configuration that redirects requests to https://www.google.com/proxy?testing=true

url.Modifier:
  scope: [request]
  scheme: https
  host: www.google.com
  path: "/proxy"
  query: testing=true

Message Body

The body.Modifier modifies the body of a request or response. Additionally, it will modify the following headers to ensure proper transport: Content-Type, Content-Length, Content-Encoding. The body is expected to be uncompressed and Base64 encoded.

body.Modifier:
  scope: [request, response]
  contentType: text/plain; charset=utf-8
  body: TWFydGlhbiBpcyBhd2Vzb21lIQ==

Groups

Groups hold lists of modifiers (or filters, or groups) that are executed in a particular order.

MultiFetcher

A body.MultiFetcher holds a list o
