Poisson intensity of limit order execution, calibration of parameters A and k using level 1 tick data
Description
A limit order placed at a price S<sub>t</sub> ± δ, has the instantaneous probability of execution λ(δ)dt where the intensity λ(δ) is given by:
λ(δ) = A e<sup> -kδ</sup>
λ - Poisson order execution intensity
δ - spread (distance from mid price S<sub>t</sub>)
A - parameter, positively related to trading intensity
k - parameter, positively related to market depth
Package Execution Intensity Estimator (EIE) contains single and multi threaded calibration procedure of A and k parameters.
Methods that calculate intensity λ(δ, A, k) and spread δ(λ, A, k) are provided as well.
Algorithm operates on level 1 tick data, therefore it is suitable in a setting where liquidity is not fully observable (i.e. dark pools).
Calibration is two step procedure performed separately for buy and sell limit orders.
<br>Steps:
- For each spread δ<sub>k</sub> of N predefined spreads (δ<sub>0</sub> , δ<sub>1</sub> , δ<sub>2</sub> , ... δ<sub>N-1</sub>) estimate execution intensity λ(δ<sub>k</sub>) using "waiting time" approach described in [1] 4.4.2.. Result of this step is set of N points (δ<sub>k</sub> , λ(δ<sub>k</sub>)) on empirical Spread Intensity Curve (SIC)
- Estimate A and k based on N points from previous step. This can be achieved by various approaches.
Code implements two approaches described in [2] 3.2:
- LOG_REGRESSION performs OLS regression of log(λ<sub>k</sub>) on δ<sub>k</sub>. Finally k = -slope and A = e<sup> intercept</sup>
- MULTI_CURVE from set of N points creates N<sub>s</sub> = (N*(N-1))/2 unique pairs fo points ((δ<sub>x</sub> , λ<sub>x</sub>) , (δ<sub>y</sub> , λ<sub>y</sub>)).
For each set of points solves the following set of equations for A' and k' :
λ<sub>x</sub> = A' e<sup> -k'δ<sub>x</sub></sup>
λ<sub>y</sub> = A' e<sup> -k'δ<sub>y</sub></sup>
Final estimates are A = mean(A'<sub>1</sub> , A'<sub>2</sub> , ... A'<sub>N<sub>s</sub></sub>) and k = mean(k'<sub>1</sub> , k'<sub>2</sub> , ... k'<sub>N<sub>s</sub></sub>)
Once A and k are calibrated, depending on context of usage, user can specify:
- spread δ to obtain corresponding intensity λ(δ)
- intensity λ to obtain corresponding spread δ(λ)
<br><br>
Usage
- Configuration parameters
double spreadStep = 0.00001; // increment of spread, greater than or equal to tick size
int nSpreads = 10; // number of spread increments, greater than 2
long w = 3600000; // 60 min, width of estimators sliding window
long dt = 10000 // 10 seconds, time scaling
- Create an instance of AkSolverFactory and specify SolverType
- Create an instance of FillRateEstimator
AkSolverFactory sf = new AkSolverFactory(SolverType.MULTI_CURVE);
IntensityEstimator ie = new IntensityEstimator(spreadStep, nSpreads, w, dt, sf);
- Pass an instance of ExecutorService to EstimationExecutor. Ensure minimum number of 5 threads is available. This step is required only for multithreaded estimation.
EstimationExecutor.setExecutor(executorService);
- Pass data (bid, ask, timestamp) to the instance of FillRateEstimator with onTick/onTickAsync call
- Run parameter estimates with estimate/estimateAsync call
while(loop){
...
// pass tick data to estimator
Future<Boolean> tickResult = ie.onTickAsync(bid, ask, timeStamp);
...
if (tickResult.get()) { // check if estimator can be called
Future<IntensityInfo> result = ie.estimateAsync(timeStamp);
...
IntensityInfo intensityInfo =result.get();
...
- Returned IntensityInfo instance gives access to parameters A and k for both buy and sell orders. Intensities λ(δ) and Spreads δ(λ) are returned by corresponding public methods.
Note:
- More details on usage and configuration can be found in IntensityEstimatorTest and javadoc comments
- Detailed test output is saved to target/intensity-log/ folder
- Single threaded outperforms multithreaded execution when less complex configurations are used
