Human3D 🧑‍🤝‍🧑

3D Segmentation of Humans in Point Clouds with Synthetic Data

<div align="center"> <a href="https://aycatakmaz.github.io/">Ay&#231;a Takmaz</a>^1,*, <a href="https://jonasschult.github.io/">Jonas Schult</a>^2,*, <a href="https://ikaftan.github.io/">Irem Kaftan</a>^1,†, <a href="https://cmakcay.github.io/">Cafer Mertcan Ak&#231;ay</a>^1,†, <a href="https://www.vision.rwth-aachen.de/person/1/">Bastian Leibe</a>¹, <a href="https://people.inf.ethz.ch/~sumnerb/">Robert Sumner</a>¹, <br /> <a href="https://francisengelmann.github.io/">Francis Engelmann</a>¹, <a href="https://inf.ethz.ch/people/person-detail.MjYyNzgw.TGlzdC8zMDQsLTg3NDc3NjI0MQ==.html">Siyu Tang</a>¹

¹ETH Zurich ²RWTH Aachen University ^*,†equal contribution

We propose the first multi-human body-part segmentation model, called Human3D 🧑‍🤝‍🧑, that directly operates on 3D scenes. In an extensive analysis, we validate the benefits of training on synthetic data on multiple baselines and tasks.

<a href="https://pytorch.org/get-started/locally/"><img alt="PyTorch" src="https://img.shields.io/badge/PyTorch-ee4c2c?logo=pytorch&logoColor=white"></a> <a href="https://pytorchlightning.ai/"><img alt="Lightning" src="https://img.shields.io/badge/-Lightning-792ee5?logo=pytorchlightning&logoColor=white"></a> <a href="https://hydra.cc/"><img alt="Config: Hydra" src="https://img.shields.io/badge/Config-Hydra-89b8cd"></a> <a href="https://github.com/psf/black"><img alt="Code style: black" src="https://img.shields.io/badge/code%20style-black-000000.svg"></a>

</div> <br><br>

[Project Webpage] [Paper]

Code structure

We adapt the codebase of Mix3D and Mask3D which provides a highly modularized framework for 3D scene understanding tasks based on the MinkowskiEngine.

├── mix3d
│   ├── main_instance_segmentation.py <- the main file
│   ├── conf                          <- hydra configuration files
│   ├── datasets
│   │   ├── preprocessing             <- folder with preprocessing scripts
│   │   ├── semseg.py                 <- indoor dataset
│   │   └── utils.py
│   ├── models                        <- Human3D modules
│   ├── trainer
│   │   ├── __init__.py
│   │   └── trainer.py                <- train loop
│   └── utils
├── data
│   ├── processed                     <- folder for preprocessed datasets
│   └── raw                           <- folder for raw datasets
├── scripts                           <- train scripts
├── docs
├── README.md
└── saved                             <- folder that stores models and logs

Dependencies :memo:

The main dependencies of the project are the following:

python: 3.10.9
cuda: 11.3

You can set up a conda environment as follows

# Some users experienced issues on Ubuntu with an AMD CPU
# Install libopenblas-dev (issue #115, thanks WindWing)
# sudo apt-get install libopenblas-dev

export TORCH_CUDA_ARCH_LIST="6.0 6.1 6.2 7.0 7.2 7.5 8.0 8.6"

conda env create -f environment.yaml

conda activate human3d_cuda113

pip3 install torch==1.12.1+cu113 torchvision==0.13.1+cu113 --extra-index-url https://download.pytorch.org/whl/cu113
pip3 install torch-scatter -f https://data.pyg.org/whl/torch-1.12.1+cu113.html
pip3 install 'git+https://github.com/facebookresearch/detectron2.git@710e7795d0eeadf9def0e7ef957eea13532e34cf' --no-deps

cd third_party

git clone --recursive "https://github.com/NVIDIA/MinkowskiEngine"
cd MinkowskiEngine
git checkout 02fc608bea4c0549b0a7b00ca1bf15dee4a0b228
python setup.py install --force_cuda --blas=openblas

cd ../../pointnet2
python setup.py install

cd ../../
pip3 install pytorch-lightning==1.7.2

Data preprocessing :hammer:

After installing the dependencies, we preprocess the datasets. Please refer to the instructions to obtain the synthetic dataset and the dataset based on Egobody. Put the datasets in data/raw/.

EgoBody

python datasets/preprocessing/humanseg_preprocessing.py preprocess \
--data_dir="../../data/raw/egobody" \
--save_dir="../../data/processed/egobody" \
--dataset="egobody"

Synthetic Data

python datasets/preprocessing/humanseg_preprocessing.py preprocess \
--data_dir="../../data/raw/synthetic_humans" \
--save_dir="../../data/processed/synthetic_humans" \
--dataset="synthetic_humans" \
--min_points=20000 \
--min_instances=1

Training and testing :train2:

Training and evaluation scripts are located in the scripts/ folder.

Trained checkpoints :floppy_disk:

We provide detailed scores and network configurations with trained checkpoints. We pre-trained with synthetic data and fine-tuned on EgoBody. Both checkpoints can be conveniently downloaded into the checkpoint/ folder with ./download_checkpoints.sh.

| Method | Task | Config | Checkpoint :floppy_disk: | Visualizations :telescope: |:-:|:-:|:-:|:-:|:-:| | Mask3D | Human Instance | config | checkpoint | visualizations | Human3D | MHBPS | config | checkpoint | visualizations

Tip: Setting data.save_visualizations=true saves the MHBPS predictions using PyViz3D.

BibTeX :pray:

@inproceedings{takmaz23iccv,
    title     = {{3D Segmentation of Humans in Point Clouds with Synthetic Data}},
    author    = {Takmaz, Ay\c{c}a and Schult, Jonas and Kaftan, Irem and Ak\c{c}ay, Mertcan
                  and Leibe, Bastian and Sumner, Robert and Engelmann, Francis and Tang, Siyu},
    booktitle = {{International Conference on Computer Vision}},
    year      = {2023}
  }

🗣️ Acknowledgements

This repository is based on the Mix3D and Mask3D code base. Mask Transformer implementations largely follow Mask2Former.
