Wave function collapse

Java implementation of the WFC-algorithm

What does it do:

In short, it takes in a 2D array of integer values (Could be colors, tiles or whatever you want), goes over every possible 3x3 patterns of values represented in the input array and stores the possibilities in a collection of unique patterns.

Then from that collection, outputs a new 2D array of integers that adheres to the same rules of patterns. That's it. A relatively simple input can generate complex outputs. There are many use cases for WFC in procedural generation.

How does it work

I am not going to go over the details, as there are many excellent sources that explains it better than I could. And some of my favorites are linked below

How this might differ from other implementations

(Read when you have a fair understanding, also the code is commented)

A "Cells" remaining options are stored as bits (BitSet) instead of objects or integers. Propagation and finding valid adjacent patterns etc. is done through simple logical operators. (and/or) You don't have to look through a list and remove items or anything like that. I.e. If a cell propagates to the next, simply Cell_A && Cell_B.

The priority queue used to sort Cells by entropy (Which to collapse next) is specialized on updating the priority of its items.

Propagation is done "depth first" (Stack, not a Queue) but adjacent target cells are sorted by entropy before they are pushed onto the propagation stack.

Cells do not propagate back in the direction they were propagated from.

A small amount of noise is introduced to cells' entropy (possibly better rng)

Test Example

The Example comes with visuals you can play around with:

• Download or clone.
• Run Example main (chose input image, adjust some values and play around)

But the main code is in the wfc package. WFC.java is what you are looking for

Sources

• Great explanation and implementation (Rust) (My main source)
• mxgmn's original Wave Function Collapse github repository (C#)
• Wave function collapse and Model Synthesis (video)
• Superpositions, Sudoku, the Wave Function Collapse algorithm (video)
