Fisheye

A 360-degree panorama video player library for iOS.

Features

• Play 360-degree panoramic videos
• Touch-based rotation for immersive viewing
• Easy-to-use FisheyeView API with SwiftUI support
• Configurable field of view, frame rate, and touch sensitivity
• Metal-based rendering for modern iOS devices
• Pure Swift implementation

Requirements

• iOS 15.0+
• Swift 5.0+
• Xcode 14.0+

Installation

Swift Package Manager

Add Fisheye to your project using Swift Package Manager:

1. In Xcode, go to File > Add Package Dependencies...
2. Enter the repository URL: https://github.com/user/Fisheye
3. Select the version you want to use
4. Click Add Package

Or add it to your Package.swift:

dependencies: [
    .package(url: "https://github.com/user/Fisheye", from: "2.1.2")
]

Usage

SwiftUI

Fisheye provides first-class SwiftUI support with FisheyeSwiftUIView:

Basic Usage

import SwiftUI
import Fisheye

struct ContentView: View {
    var body: some View {
        if let videoURL = Bundle.main.url(forResource: "video", withExtension: "mp4") {
            FisheyeSwiftUIView(videoURL: videoURL)
                .ignoresSafeArea()
        }
    }
}

With Playback Control

struct ContentView: View {
    @State private var isPlaying = true

    var body: some View {
        VStack {
            FisheyeSwiftUIView(videoURL: videoURL, isPlaying: $isPlaying)
                .frame(height: 400)

            Button(isPlaying ? "Pause" : "Play") {
                isPlaying.toggle()
            }
        }
    }
}

Using ViewModifiers

struct ContentView: View {
    var body: some View {
        FisheyeSwiftUIView(videoURL: videoURL)
            .fieldOfView(75)
            .touchSensitivity(0.01)
            .sphereQuality(.high)
            .loopPlayback(true)
            .framesPerSecond(60)
            .ignoresSafeArea()
    }
}

Available sphere quality presets:

• .low (50 slices)
• .medium (100 slices)
• .high (200 slices) - default
• .ultra (400 slices)

UIKit

Basic Usage

import Fisheye
import UIKit

class VideoViewController: UIViewController {
    private var fisheyeView: FisheyeView!

    override func viewDidLoad() {
        super.viewDidLoad()

        // Create FisheyeView
        fisheyeView = FisheyeView(frame: view.bounds)
        fisheyeView.autoresizingMask = [.flexibleWidth, .flexibleHeight]
        view.addSubview(fisheyeView)

        // Load and play a video
        if let videoURL = Bundle.main.url(forResource: "video", withExtension: "mp4") {
            fisheyeView.loadVideo(url: videoURL)
            fisheyeView.play()
        }
    }
}

Custom Configuration

let config = FisheyeConfiguration(
    fieldOfView: 90.0,        // Field of view in degrees
    framesPerSecond: 30,      // Target frame rate
    sphereSlices: 100,        // Sphere geometry detail
    touchSensitivity: 0.01,   // Touch rotation sensitivity
    loopPlayback: true        // Loop video playback
)

let fisheyeView = FisheyeView(frame: view.bounds, configuration: config)

Playback Control

fisheyeView.play()     // Start playback
fisheyeView.pause()    // Pause playback
fisheyeView.stop()     // Stop and release resources
fisheyeView.isPlaying  // Check playback state

Example Apps

The Example directory contains two complete example applications:

SwiftUI Example

See Example/FisheyeSwiftUIExample for a SwiftUI-based example demonstrating FisheyeSwiftUIView with playback controls and view modifiers.

1. Open Example/FisheyeSwiftUIExample/FisheyeSwiftUIExample.xcodeproj in Xcode
2. Build and run on an iOS simulator or device

UIKit Example

See Example/FisheyeExample for a UIKit-based example demonstrating FisheyeView integration.

1. Open Example/FisheyeExample/FisheyeExample.xcodeproj in Xcode
2. Build and run on an iOS simulator or device

Architecture

The library is structured as follows:

Sources/Fisheye/
├── Fisheye.swift              # Library entry point and version
├── Core/
│   ├── FisheyeView.swift      # High-level MTKView wrapper
│   └── FisheyeConfiguration.swift
├── SwiftUI/
│   ├── FisheyeSwiftUIView.swift    # SwiftUI wrapper with bindings
│   └── FisheyeViewModifiers.swift  # SwiftUI-idiomatic ViewModifiers
├── Rendering/
│   └── MetalRenderer.swift    # Metal-based rendering with YUV conversion
├── Geometry/
│   ├── Sphere.swift           # Sphere model
│   └── SphereGenerator.swift  # Pure Swift sphere generation
├── Video/
│   └── VideoPlayer.swift      # AVFoundation video playback
├── Utilities/
│   └── simd+Extensions.swift  # Matrix math helpers
└── Resources/
    └── Shaders.metal          # Metal shading language

Tutorial

For a detailed explanation of how the 360-degree video rendering works, see: How to Create a 360 Video Player with OpenGL ES 3.0 and GLKit in iOS

Note: This tutorial describes the OpenGL ES version (v1.x). Version 2.0+ uses Metal rendering but follows similar principles.

Contributing

1. Fork it
2. Create your feature branch (git checkout -b my-new-feature)
3. Commit your changes (git commit -am 'Add awesome feature')
4. Push to the branch (git push origin my-new-feature)
5. Create a new Pull Request

License

Fisheye is available under the MIT license. See the LICENSE file for more info.

Third-Party Licenses

The sphere generation algorithm is based on code from the OpenGL ES 3.0 Programming Guide:

• Copyright (c) 2013 Dan Ginsburg, Budirijanto Purnomo
• Licensed under the MIT License
