Effector

<p align="center"> <img src="https://raw.githubusercontent.com/givasile/effector/main/docs/docs/static/effector_logo.png" width="500"/> </p>

---

effector an eXplainable AI package for tabular data. It:

• creates global and regional effect plots
• has a simple API with smart defaults, but can become flexible if needed
• is model agnostic; can explain any underlying ML model
• integrates easily with popular ML libraries, like Scikit-Learn, Tensorflow and Pytorch
• is fast, for both global and regional methods
• provides a large collection of global and regional effects methods

---

📖 Documentation | 🔍 Intro to global and regional effects | 🔧 API | 🏗 Examples

---

Installation

Effector requires Python 3.10+:

pip install effector

Dependencies: numpy, scipy, matplotlib, tqdm, shap.

---

Quickstart

Train an ML model

import effector
import keras
import numpy as np
import tensorflow as tf

np.random.seed(42)
tf.random.set_seed(42)

# Load dataset
bike_sharing = effector.datasets.BikeSharing(pcg_train=0.8)
X_train, Y_train = bike_sharing.x_train, bike_sharing.y_train
X_test, Y_test = bike_sharing.x_test, bike_sharing.y_test

# Define and train a neural network
model = keras.Sequential([
    keras.layers.Dense(1024, activation="relu"),
    keras.layers.Dense(512, activation="relu"),
    keras.layers.Dense(256, activation="relu"),
    keras.layers.Dense(1)
])
model.compile(optimizer="adam", loss="mse", metrics=["mae", keras.metrics.RootMeanSquaredError()])
model.fit(X_train, Y_train, batch_size=512, epochs=20, verbose=1)
model.evaluate(X_test, Y_test, verbose=1)

Wrap it in a callable

def predict(x):
    return model(x).numpy().squeeze()

Explain it with global effect plots

# Initialize the Partial Dependence Plot (PDP) object
pdp = effector.PDP(
    X_test,  # Use the test set as background data
    predict,  # Prediction function
    feature_names=bike_sharing.feature_names,  # (optional) Feature names
    target_name=bike_sharing.target_name  # (optional) Target variable name
)

# Plot the effect of a feature
pdp.plot(
    feature=3,  # Select the 3rd feature (feature: hour)
    nof_ice=200,  # (optional) Number of Individual Conditional Expectation (ICE) curves to plot
    scale_x={"mean": bike_sharing.x_test_mu[3], "std": bike_sharing.x_test_std[3]},  # (optional) Scale x-axis
    scale_y={"mean": bike_sharing.y_test_mu, "std": bike_sharing.y_test_std},  # (optional) Scale y-axis
    centering=True,  # (optional) Center PDP and ICE curves
    show_avg_output=True,  # (optional) Display the average prediction
    y_limits=[-200, 1000]  # (optional) Set y-axis limits
)

Explain it with regional effect plots

# Initialize the Regional Partial Dependence Plot (RegionalPDP)
r_pdp = effector.RegionalPDP(
    X_test,  # Test set data
    predict,  # Prediction function
    feature_names=bike_sharing.feature_names,  # Feature names
    target_name=bike_sharing.target_name  # Target variable name
)

# Summarize the subregions of the 3rd feature (temperature)
r_pdp.summary(
    features=3,  # Select the 3rd feature for the summary
    scale_x_list=[  # scale each feature with mean and std
        {"mean": bike_sharing.x_test_mu[i], "std": bike_sharing.x_test_std[i]}
        for i in range(X_test.shape[1])
    ]
)

Feature 3 - Full partition tree:
🌳 Full Tree Structure:
───────────────────────
hr 🔹 [id: 0 | heter: 0.43 | inst: 3476 | w: 1.00]
    workingday = 0.00 🔹 [id: 1 | heter: 0.36 | inst: 1129 | w: 0.32]
        temp ≤ 6.50 🔹 [id: 3 | heter: 0.17 | inst: 568 | w: 0.16]
        temp > 6.50 🔹 [id: 4 | heter: 0.21 | inst: 561 | w: 0.16]
    workingday ≠ 0.00 🔹 [id: 2 | heter: 0.28 | inst: 2347 | w: 0.68]
        temp ≤ 6.50 🔹 [id: 5 | heter: 0.19 | inst: 953 | w: 0.27]
        temp > 6.50 🔹 [id: 6 | heter: 0.20 | inst: 1394 | w: 0.40]
--------------------------------------------------
Feature 3 - Statistics per tree level:
🌳 Tree Summary:
─────────────────
Level 0🔹heter: 0.43
    Level 1🔹heter: 0.31 | 🔻0.12 (28.15%)
        Level 2🔹heter: 0.19 | 🔻0.11 (37.10%)

The summary of feature hr (hour) says that its effect on the output is highly dependent on the value of features:

• workingday, wheteher it is a workingday or not
• temp, what is the temperature the specific hour

Let's see how the effect changes on these subregions!

---

Is it workingday or not?

# Plot regional effects after the first-level split (workingday vs non-workingday)
for node_idx in [1, 2]:  # Iterate over the nodes of the first-level split
    r_pdp.plot(
        feature=3,  # Feature 3 (temperature)
        node_idx=node_idx,  # Node index (1: workingday, 2: non-workingday)
        nof_ice=200,  # Number of ICE curves
        scale_x_list=[  # Scale features by mean and std
            {"mean": bike_sharing.x_test_mu[i], "std": bike_sharing.x_test_std[i]}
            for i in range(X_test.shape[1])
        ],
        scale_y={"mean": bike_sharing.y_test_mu, "std": bike_sharing.y_test_std},  # Scale the target
        y_limits=[-200, 1000]  # Set y-axis limits
    )

<table> <tr> <td><img src="https://raw.githubusercontent.com/givasile/effector/main/docs/docs/notebooks/quickstart/readme_example_files/readme_example_5_0.png" alt="Feature effect plot"></td> <td><img src="https://raw.githubusercontent.com/givasile/effector/main/docs/docs/notebooks/quickstart/readme_example_files/readme_example_5_1.png" alt="Feature effect plot"></td> </tr> </table>

Is it hot or cold?

# Plot regional effects after second-level splits (workingday vs non-workingday and hot vs cold temperature)
for node_idx in [3, 4, 5, 6]:  # Iterate over the nodes of the second-level splits
    r_pdp.plot(
        feature=3,  # Feature 3 (temperature)
        node_idx=node_idx,  # Node index (hot/cold temperature and workingday/non-workingday)
        nof_ice=200,  # Number of ICE curves
        scale_x_list=[  # Scale features by mean and std
            {"mean": bike_sharing.x_test_mu[i], "std": bike_sharing.x_test_std[i]}
            for i in range(X_test.shape[1])
        ],
        scale_y={"mean": bike_sharing.y_test_mu, "std": bike_sharing.y_test_std},  # Scale target
        y_limits=[-200, 1000]  # Set y-axis limits
    )

<table> <tr> <td><img src="https://raw.githubusercontent.com/givasile/effector/main/docs/docs/notebooks/quickstart/readme_example_files/readme_example_6_0.png" alt="Feature effect plot"></td> <td><img src="https://raw.githubusercontent.com/givasile/effector/main/docs/docs/notebooks/quickstart/readme_example_files/readme_example_6_1.png" alt="Feature effect plot"></td> </tr> <tr> <td><img src="https://raw.githubusercontent.com/givasile/effector/main/docs/docs/notebooks/quickstart/readme_example_files/readme_example_6_2.png" alt="Feature effect plot"></td> <td><img src="https://raw.githubusercontent.com/givasile/effector/main/docs/docs/notebooks/quickstart/readme_example_files/readme_example_6_3.png" alt="Feature effect plot"></td> </tr> </table>

---

Supported Methods

effector implements global and regional effect methods:

| Method | Global Effect | Regional Effect | Reference | ML model | Speed | |---------|----------------|-----------------|-----------|-------------------|----------------------------------------------| | PDP | PDP | RegionalPDP | PDP | any | Fast for a small dataset | | d-PDP | DerPDP | RegionalDerPDP| d-PDP | differentiable | Fast for a small dataset | | ALE | ALE | RegionalALE | ALE | any | Fast | | RHALE | RHALE | RegionalRHALE | RHALE | differentiable | Very fast | | SHAP-DP | ShapDP | RegionalShapDP| SHAP | any | Fast for a small dataset and a light ML model |

---

Method Selection Guide

From the runtime persepective there are three criterias:

• is the dataset small (N<10K) or large (N>10K instanc
