wrk2

a HTTP benchmarking tool based mostly on wrk

wrk2 is wrk modifed to produce a constant throughput load, and accurate latency details to the high 9s (i.e. can produce accurate 99.9999%'ile when run long enough). In addition to wrk's arguments, wrk2 takes a throughput argument (in total requests per second) via either the --rate or -R parameters (default is 1000).

CRITICAL NOTE: Before going farther, I'd like to make it clear that this work is in no way intended to be an attack on or a disparagement of the great work that Will Glozer has done with wrk. I enjoyed working with his code, and I sincerely hope that some of the changes I had made might be considered for inclusion back into wrk. As those of you who may be familiar with my latency related talks and rants, the latency measurement issues that I focused on fixing with wrk2 are extremely common in load generators and in monitoring code. I do not ascribe any lack of skill or intelligence to people who's creations repeat them. I was once (as recently as 2-3 years ago) just as oblivious to the effects of Coordinated Omission as the rest of the world still is.

wrk2 replaces wrk's individual request sample buffers with HdrHistograms. wrk2 maintains wrk's Lua API, including it's presentation of the stats objects (latency and requests). The stats objects are "emulated" using HdrHistograms. E.g. a request for a raw sample value at index i (see latency[i] below) will return the value at the associated percentile (100.0 * i / __len).

As a result of using HdrHistograms for full (lossless) recording, constant throughput load generation, and accurate tracking of response latency (from the point in time where a request was supposed to be sent per the "plan" to the time that it actually arrived), wrk2's latency reporting is significantly more accurate (as in "correct") than that of wrk's current (Nov. 2014) execution model.

It is important to note that in wrk2's current constant-throughput implementation, measured latencies are [only] accurate to a +/- ~1 msec granularity, due to OS sleep time behavior.

wrk2 is currently in experimental/development mode, and may well be merged into wrk in the future if others see fit to adopt it's changes.

The remaining part of the README is wrk's, with minor changes to reflect additional parameter and output. There is an important and detailed note at the end about about wrk2's latency measurement technique, including a discussion of Coordinated Omission, how wrk2 avoids it, and detailed output that demonstrates it.

wrk2 (as is wrk) is a modern HTTP benchmarking tool capable of generating significant load when run on a single multi-core CPU. It combines a multithreaded design with scalable event notification systems such as epoll and kqueue.

An optional LuaJIT script can perform HTTP request generation, response processing, and custom reporting. Several example scripts are located in scripts/

Basic Usage

wrk -t2 -c100 -d30s -R2000 http://127.0.0.1:8080/index.html

This runs a benchmark for 30 seconds, using 2 threads, keeping 100 HTTP connections open, and a constant throughput of 2000 requests per second (total, across all connections combined).

[It's important to note that wrk2 extends the initial calibration period to 10 seconds (from wrk's 0.5 second), so runs shorter than 10-20 seconds may not present useful information]

Output:

Running 30s test @ http://127.0.0.1:80/index.html
  2 threads and 100 connections
  Thread calibration: mean lat.: 9747 usec, rate sampling interval: 21 msec
  Thread calibration: mean lat.: 9631 usec, rate sampling interval: 21 msec
  Thread Stats   Avg      Stdev     Max   +/- Stdev
    Latency     6.46ms    1.93ms  12.34ms   67.66%
    Req/Sec     1.05k     1.12k    2.50k    64.84%
  60017 requests in 30.01s, 19.81MB read
Requests/sec:   2000.15
Transfer/sec:    676.14KB

However, wrk2 will usually be run with the --latency flag, which provides detailed latency percentile information (in a format that can be easily imported to spreadsheets or gnuplot scripts and plotted per examples provided at http://hdrhistogram.org):

wrk -t2 -c100 -d30s -R2000 --latency http://127.0.0.1:80/index.html

Output:

Running 30s test @ http://127.0.0.1:80/index.html
  2 threads and 100 connections
  Thread calibration: mean lat.: 10087 usec, rate sampling interval: 22 msec
  Thread calibration: mean lat.: 10139 usec, rate sampling interval: 21 msec
  Thread Stats   Avg      Stdev     Max   +/- Stdev
    Latency     6.60ms    1.92ms  12.50ms   68.46%
    Req/Sec     1.04k     1.08k    2.50k    72.79%
  Latency Distribution (HdrHistogram - Recorded Latency)
 50.000%    6.67ms
 75.000%    7.78ms
 90.000%    9.14ms
 99.000%   11.18ms
 99.900%   12.30ms
 99.990%   12.45ms
 99.999%   12.50ms
100.000%   12.50ms

Detailed Percentile spectrum:
     Value   Percentile   TotalCount 1/(1-Percentile)

     0.921     0.000000            1         1.00
     4.053     0.100000         3951         1.11
     4.935     0.200000         7921         1.25
     5.627     0.300000        11858         1.43
     6.179     0.400000        15803         1.67
     6.671     0.500000        19783         2.00
     6.867     0.550000        21737         2.22
     7.079     0.600000        23733         2.50
     7.287     0.650000        25698         2.86
     7.519     0.700000        27659         3.33
     7.783     0.750000        29644         4.00
     7.939     0.775000        30615         4.44
     8.103     0.800000        31604         5.00
     8.271     0.825000        32597         5.71
     8.503     0.850000        33596         6.67
     8.839     0.875000        34571         8.00
     9.015     0.887500        35070         8.89
     9.143     0.900000        35570        10.00
     9.335     0.912500        36046        11.43
     9.575     0.925000        36545        13.33
     9.791     0.937500        37032        16.00
     9.903     0.943750        37280        17.78
    10.015     0.950000        37543        20.00
    10.087     0.956250        37795        22.86
    10.167     0.962500        38034        26.67
    10.279     0.968750        38268        32.00
    10.343     0.971875        38390        35.56
    10.439     0.975000        38516        40.00
    10.535     0.978125        38636        45.71
    10.647     0.981250        38763        53.33
    10.775     0.984375        38884        64.00
    10.887     0.985938        38951        71.11
    11.007     0.987500        39007        80.00
    11.135     0.989062        39070        91.43
    11.207     0.990625        39135       106.67
    11.263     0.992188        39193       128.00
    11.303     0.992969        39226       142.22
    11.335     0.993750        39255       160.00
    11.367     0.994531        39285       182.86
    11.399     0.995313        39319       213.33
    11.431     0.996094        39346       256.00
    11.455     0.996484        39365       284.44
    11.471     0.996875        39379       320.00
    11.495     0.997266        39395       365.71
    11.535     0.997656        39408       426.67
    11.663     0.998047        39423       512.00
    11.703     0.998242        39431       568.89
    11.743     0.998437        39439       640.00
    11.807     0.998633        39447       731.43
    12.271     0.998828        39454       853.33
    12.311     0.999023        39463      1024.00
    12.327     0.999121        39467      1137.78
    12.343     0.999219        39470      1280.00
    12.359     0.999316        39473      1462.86
    12.375     0.999414        39478      1706.67
    12.391     0.999512        39482      2048.00
    12.399     0.999561        39484      2275.56
    12.407     0.999609        39486      2560.00
    12.415     0.999658        39489      2925.71
    12.415     0.999707        39489      3413.33
    12.423     0.999756        39491      4096.00
    12.431     0.999780        39493      4551.11
    12.431     0.999805        39493      5120.00
    12.439     0.999829        39495      5851.43
    12.439     0.999854        39495      6826.67
    12.447     0.999878        39496      8192.00
    12.447     0.999890        39496      9102.22
    12.455     0.999902        39497     10240.00
    12.455     0.999915        39497     11702.86
    12.463     0.999927        39498     13653.33
    12.463     0.999939        39498     16384.00
    12.463     0.999945        39498     18204.44
    12.479     0.999951        39499     20480.00
    12.479     0.999957        39499     23405.71
    12.479     0.999963        39499     27306.67
    12.479     0.999969        39499     32768.00
    12.479     0.999973        39499     36408.89
    12.503     0.999976        39500     40960.00
    12.503     1.000000        39500          inf
#[Mean    =        6.602, StdDeviation   =        1.919]
#[Max     =       12.496, Total count    =        39500]
#[Buckets =           27, SubBuckets     =         2048]
----------------------------------------------------------
60018 requests in 30.00s, 19.81MB read
Requests/sec:   2000.28
