Mathematics in Forth

In the examples below the top stack item is shown right-most, following Forth convention.

Primes

The file math/prime.fth defines words related to prime numbers.

The word primes gives a number of primes on the data stack. For example, 9 primes gives 23 19 17 13 11 7 5 3 2. Using traverse-primes one can for example compute the nth prime number p_n by defining prime as:

: prime' ( n n -- n ) nip true ; ( True to obtain next prime number. )
: prime  ( n -- n ) 0 swap ['] prime' traverse-primes ;

Thus 9 prime gives 23 corresponding to p₉. Computing the prime can be slow especially for large indices. The words prime-lower and prime-upper give quick estimates of lower and upper bounds. The inequalities prime-lower ≤ prime ≤ prime-upper hold for any number.

The prime-counting function denoted by π(n) is defined by the word prime-count. For example, 23 prime-count gives 9 because there are 9 primes below or equal to 23. Since this computation can be slow there are words for quick estimates of lower and upper bounds, where the inequalities prime-count-lower ≤ prime-count ≤ prime-count-upper hold for any number.

The word primes-preceding gives on the data stack all primes below or equal to a certain number. Thus 23 primes-preceding gives 23 19 17 13 11 7 5 3 2 9 where the top integer 9 is the number of primes below or equal to 23. The word traverse-primes-preceding can be used to traverse all primes below or equal to a given number.

Prime decomposition

The file math/factor.fth defines words related to integer factorisation.

The word factors factorises a given integer into primes. For example, 12857=13·23·43 and so 12857 factors gives 43 23 13 3 on the data stack, where the top integer 3 indicates the number of prime factors and then the factors 13, 23 and 43 follow from smallest to largest.

Using traverse-factors one can for example define words for finding the smallest or largest prime factor of a given integer:

: min-factor' ( n n -- n) nip false ; ( False to ignore further prime factors. )
: min-factor  ( n -- n ) 0 swap ['] min-factor' traverse-factors ;

: max-factor' ( n n -- n) nip true ; ( True to obtain next prime factor. )
: max-factor  ( n -- n ) 0 swap ['] max-factor' traverse-factors ;

Thus 12857 min-factor gives 13 and 12857 max-factor gives 43.

The words prime? and composite? test whether a number is prime or composite. Thus 17 prime? gives true since 17 is a prime number but 18 prime? gives false since 18 is not a prime number. Numbers below 2 are neither prime nor composite.

Some integers such as 22477=7·13·13·19 have repeating primes so that 22477 factors gives 19 13 13 7 4 where 13 is repeated twice. The word factor-exponents factorises into distinct primes with corresponding exponents. Thus 22477 factor-exponents gives 19 1 13 2 7 1 3 where the top integer 3 indicates the number of distinct primes, followed by the pairs of primes and exponents corresponding to 7¹·13²·19¹.

The Pollard Monte Carlo factorisation method is potentially very fast, but since it is a probabalistic method it can be slow and even fail to find factors of composite numbers. For example, pollard-rho-factors 4267640728818788929 gives the two factors 3456789019 and 1234567891 within a fraction of a second on a 64 bit Forth system.

Divisors

The files math/divisor.fth and math/gcd.fth define words related to divisor functions.

The word divisors gives the divisors of a number. For example, 52 divisors gives 52 26 13 4 2 1 6 where the top integer 6 indicates the divisor count and then the divisors follow from smallest to largest. traverse-divisors can be used to iterate over all divisors.

The sum of positive divisors function denoted by σ_x(n) is defined by divisor-sum. With x = 0 the function corresponds to divisor-count.

The word gcd gives the greatest common divisor. For example, 12 18 gcd gives 6. The word lcm gives the corresponding least common multiple. For example, 6 21 lcm gives 42. The word extended-gcd implements the extended Euclidean algorithm that gives two addional integers related to Bézout’s identity. For example, 240 46 extended-gcd gives -9 47 2 where 2 is the greatest common divisor and the identity holds as -9·240 + 47·46 = 2 = gcd(240, 46).

Rational numbers

The file math/rational.fth defines words related to rational numbers.

Rationals are represented as two numbers on the stack with the denominator above the cell containing the numerator. The words q+, q-, q* and q/ define rational arithmetic in a natural way. For example, 2 3 5 7 q+ gives 29 21 which corresponds to 2/3 + 5/7 = 29/21. Rational arithmetics overflow easily, especially intermediate calculations.

Exponents

The file math/exponent.fth defines words related to exponentiation.

The word ** computes integer exponentiation using efficient exponentiation by squaring. For example, 3 4 ** gives 81 which corresponds to 3⁴ = 81.

Logarithms

The file math/log.fth defines words related to logarithms.

The words log2-floor and log2-ceiling compute log₂ using integer arithmetics only, where the inequalities log2-floor ≤ log₂ ≤ log2-ceiling hold for any number. Similarly, ln-lower and ln-upper give quick estimates with the inequalities ln-lower ≤ ln ≤ ln-upper.

Modular arithmetic

The file math/modulo.fth defines words related to modular arithmetic.

The words +mod, -mod, *mod and **mod define modular arithmetic in a natural way. For example, the word **mod computes modular exponentiation and so 5 3 13 **mod gives 8 which corresponds to 5³ = 125 = 8 (mod 13).

Matrices

The file math/matrix.fth defines words related to matrices.

Matrices are laid out in the following way on the stack: a 2×3 matrix having dimensions 2 rows and 3 columns with elements a, b and c in the first row and d, e and f in the second row is represented on the stack as a b c d e f 3 2, or stated with a different identation:

a b c
d e f  3 2

In data-space this matrix has the following layout:

Cell | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 --- | --- | --- | --- | --- | --- | --- | --- | --- Value | 2 | 3 | a | b | c | d | e | f

Adding, subtracting, negating and multiplying matrices on the stack are defined by the words matrix+, matrix-, matrix-negate and matrix*. The word matrix** defines matrix exponentiation, and the words matrix0 and matrix1 give the zero and identity matrices. The word matrix-drop drops a matrix from the stack and matrix-element gives the element of particular row and column indices. The words matrix-dimensions, matrix-rows and matrix-cols give matrix dimensions. For example, multiplying a 2×3 matrix by a 3×2 matrix

     2   3   5
     7  11  13  3 2

    17  19
    23  29
    31  37  2 3

    matrix*

gives a 2×2 matrix:

   258 310
   775 933  2 2

Matrices can be moved and copied between the stack and data-space in several ways. The word matrix>allot moves a matrix off the stack to data-space appropriately reserved for by allot. The word allot>matrix is the inverse. The word allot+matrix copies a matrix from data-space to the stack, and the word matrix-allot removes a matrix from data-space by adjusting the here data-space pointer accordingly. The words matrix0allot and matrix1allot create the zero and identity matrices in data-space.

Special numbers

The files math/binomial.fth, math/bernoulli.fth and math/faulhaber.fth define words related to special numbers.

The word binomial corresponds to binomial numbers. For example, 7 3 binomial gives 35. The word bernoulli corresponds to Bernoulli numbers. For example, 12 bernoulli gives the rational number -691 2730. The word faulhaber corresponds to Faulhaber’s formula. For example, 7 2 faulhaber gives 91 which corresponds to 1²+ 2²+ 3²+ 4²+ 5²+ 6²=91. In general 1 faulhaber corresponds to the triangular numbers, 2 faulhaber to the square pyramidal numbers, 3 faulhaber to the [squared triangular numbers](https://en.wikipedia.org/wiki/Squared
