HistoXGAN

HistoXGAN (<b>Histo</b>logy feature e<b>X</b>plainability <b>G</b>enerative <b>A</b>dversarial <b>N</b>etwork) is a tool to perform highly accurate reconstruction of histology from latent space features. This tool can be used to explain the predictions of deep learning models that rely on extracted image features from foundational encoders, or to translate genomics or radiographic images into histology to understand histologic reflections of genomics or perform a 'virtual tumor biopsy'.

<img src='https://github.com/fmhoward/HistoXGAN/blob/main/histoxgan_architecture.png?raw=true'>

Attribution

If you use this code in your work or find it helpful, please consider citing our paper in <a href='https://www.science.org/doi/10.1126/sciadv.adq0856'>Science Advances</a>.

@article{howard_generative_2024,
	title = {Generative adversarial networks accurately reconstruct pan-cancer histology from pathologic, genomic, and radiographic latent features},
	volume = {10},
	url = {https://www.science.org/doi/10.1126/sciadv.adq0856},
	doi = {10.1126/sciadv.adq0856},
	abstract = {Artificial intelligence models have been increasingly used in the analysis of tumor histology to perform tasks ranging from routine classification to identification of molecular features. These approaches distill cancer histologic images into high-level features, which are used in predictions, but understanding the biologic meaning of such features remains challenging. We present and validate a custom generative adversarial network—HistoXGAN—capable of reconstructing representative histology using feature vectors produced by common feature extractors. We evaluate HistoXGAN across 29 cancer subtypes and demonstrate that reconstructed images retain information regarding tumor grade, histologic subtype, and gene expression patterns. We leverage HistoXGAN to illustrate the underlying histologic features for deep learning models for actionable mutations, identify model reliance on histologic batch effect in predictions, and demonstrate accurate reconstruction of tumor histology from radiographic imaging for a “virtual biopsy.”},
	number = {46},
	urldate = {2024-11-18},
	journal = {Science Advances},
	author = {Howard, Frederick M. and Hieromnimon, Hanna M. and Ramesh, Siddhi and Dolezal, James and Kochanny, Sara and Zhang, Qianchen and Feiger, Brad and Peterson, Joseph and Fan, Cheng and Perou, Charles M. and Vickery, Jasmine and Sullivan, Megan and Cole, Kimberly and Khramtsova, Galina and Pearson, Alexander T.},
	month = nov,
	year = {2024},
	note = {Publisher: American Association for the Advancement of Science},
	pages = {eadq0856}}

Installation

This github repository should be downloaded to a project directory. Installation takes < 5 minutes on a standard desktop computer. Runtime for HistoXGAN training across the entire TCGA dataset requires approximately 72 hours to run for 25,000 kimg on 4 A100 GPUs. Subsequent generation of images with the trained HistoXGAN network occurs in < 1 second per image. All software was tested on CentOS 8 with an AMD EPYC 7302 16-Core Processor and 4x A100 SXM 40 GB GPUs.

Requirements:

• python 3.8
• pytorch 1.11
• opencv 4.6.0.66
• scipy 1.9.3
• scikit-image 0.19.3
• OpenSlide
• Libvips 8.9
• pandas 1.5.1
• numpy 1.21.6

For full environment used for model testing please see the environment.yml file

HistoXGAN Applications

Visualization of Histology Feature Space

Visualizing synthetic histology from a feature vector is easily performed with HistoXGAN; the included models allow for visualization of CTransPath and RetCCL feature vectors. Trained models used in this work are available at https://doi.org/10.5281/zenodo.15873924. The trained HistoXGAN models alone can be downloaded from the FINAL_MODELS.rar folder in this Zenodo repository; or the trained models in conjunction with other supplemental data used to evaluate HistoXGAN can be downloaded from the HistoXGAN.rar folder. We have trained additional HistoXGAN models with various foundation models (UNI, UNI2, HOPTIMUS0, CTRANSPATH, RETCCL) as feature extractors. Weights to these models can be found <a href='https://zenodo.org/records/17161283'>on Zenodo at https://zenodo.org/records/17161283</a>.

The following code illustrates reconstruction of an image from CTransPath feature vectors:

#Load the CTransPath HistoXGAN model
from slideflow.gan.stylegan3.stylegan3 import dnnlib, legacy, utils
#The link here should reference the HistoXGAN model location downloaded from Zenodo
with dnnlib.util.open_url('../FINAL_MODELS/CTransPath/snapshot.pkl') as f:
    G = legacy.load_network_pkl(f)['G_ema'].to(device)

#Select a feature vector to visualize
#The /PROJECTS/HistoXGAN/SAVED_FEATURES folder contains extracted CTransPath feature vectors for visualization
df = pd.read_csv('../PROJECTS/HistoXGAN/SAVED_FEATURES/brca_features_part.csv')
feat_cols = list(df_mod.columns.values)
feat_cols = [f for f in feat_cols if 'Feature_' in f]

#Select the first feature vector in the dataset
device = torch.device('cuda:0')
vector_base = torch.tensor([df[feat_cols].loc[0, :].values.tolist()]).to(device)
img_gen = G(vector_base, 0, noise_mode ='const

#Convert image to 0 - 255 scale and proper W X H X C order for visualization
import matplotlib.pyplot as plt
img_show = ((img_gen + 1)*127.5).permute(0, 2, 3, 1).clamp(0, 255).to(torch.uint8)[0].cpu().numpy()
fig, ax = plt.subplots()
plt.imshow(img_show)
plt.show()

Visualization of Transition from Low to High Grade

For a more complex example, we can identify the feature vector indicative of low / high grade and visualize transitions along that feature vector.

#The following code generates images along the transition for high / low grade

import pandas as pd
import numpy as np
import pickle
import os
import torch
from sklearn.linear_model import LogisticRegression, LinearRegression
from slideflow.gan.stylegan3.stylegan3 import dnnlib, legacy, utils
import matplotlib
%matplotlib inline
import matplotlib.pyplot as plt

PROJECT_DIR = os.getcwd()
device = torch.device('cuda:3')

with dnnlib.util.open_url(PROJECT_DIR + '/FINAL_MODELS/CTransPath/snapshot.pkl') as f:
    G = legacy.load_network_pkl(f)['G_ema'].to(device)

def vector_interpolate(
    G: torch.nn.Module,
    z: torch.tensor,
    z2: torch.tensor,
    device: torch.device,
    steps: int = 100
):
    for interp_idx in range(steps):
        torch_interp = torch.tensor(z - z2 + 2*interp_idx/steps*z2).to(device)
        img = G(torch_interp, 0, noise_mode ='const')
        img = (img + 1) * (255/2)
        img = img.permute(0, 2, 3, 1).clamp(0, 255).to(torch.uint8)[0].cpu().numpy()
        yield img

def generate_images(vector_z, vector_z2, prefix = 'test'):
    z = torch.tensor(vector_z).to(device)
    z2 = torch.tensor(vector_z2).to(device)
    img_array = []
    generator = vector_interpolate(G, z, z2, device = device)
    for interp_idx, img in enumerate(generator):
        img_array += [img]
    return img_array

def get_log_features(df, col, name):
    y = df[[col]].values
    feat_cols = list(df.columns.values)
    feat_cols = [f for f in feat_cols if 'Feature_' in f]
    #print(feat_cols)
    X = df[feat_cols]
    vector_list = X.loc[0, :].values.tolist()
    clf = LogisticRegression().fit(X, y)
    return vector_list, clf.coef_


def GRADE_DATASET(dataset, ind, grade_col):
    df = pd.read_csv(PROJECT_DIR + "/PROJECTS/HistoXGAN/SAVED_FEATURES/" +  dataset.lower() + "_features_slide.csv")
    df2 = pd.read_csv(PROJECT_DIR + "/PROJECTS/HistoXGAN/tcga_all_annotations.csv")
    df_mod = pd.read_csv(PROJECT_DIR + "/PROJECTS/HistoXGAN/SAVED_FEATURES/" +  dataset.lower() + "_features_part.csv")
    feat_cols = list(df.columns.values)
    feat_cols = [f for f in feat_cols if 'Feature_' in f]
    vector_base = df_mod[feat_cols].loc[ind, :].values.tolist()
    df['patient'] = df['Slide'].str[0:12]
    df = df.merge(df2, left_on='patient', right_on='patient', how = 'left')
    df=df.dropna(subset=['high_grade'])
    df['Grade_Class'] = 0
    df.loc[df.high_grade == 'Y', 'Grade_Class'] = 1
    vector_z, vector_z2 = get_log_features(df, 'Grade_Class', 'Grade_' + dataset)
    vector_z = vector_base
    return generate_images(vector_z, vector_z2, prefix = 'Grade_' + dataset)

img_dict = {}
img_dict['BRCA'] = GRADE_DATASET('BRCA', 100, 'Grade')
img_dict['PAAD'] = GRADE_DATASET('PAAD', 100, 'histological_grade')
img_dict['HNSC'] = GRADE_DATASET('HNSC', 200, 'neoplasm_histologic_grade')
img_dict['PRAD'] = GRADE_DATASET('PRAD', 200, 'Clinical_Gleason_sum')

img_include = 7
fig, axs2 = plt.subplots(len(img_dict), img_include, figsize = (2*img_include, 2*len(img_dict)))

row_loc = {
    'BRCA':[20,30,40,50,60,70,80],
    'HNSC':[20,30,40,50,60,70,80],
    'PAAD':[20,30,40,50,60,70,80],
    'PRAD':[20,30,40,50,60,70,80],
}
img_include = 7
col = 0
for img_name in img_dict:
    row = 0
    for row_item in row_loc[img_name]:
        axs2[col][row].imshow(img_dict[img_name][row_item])
        axs2[col][row].set_xticks([])
        axs2[col][row].set_yticks([])
        axs2[col][row].xaxis.set_label_position('top')
        row = row + 1
    str_name = img_name
    axs2[col][0].set_ylabel(str_name, size = 18)
    col = col + 1
fig.subplots_adjust(left = 0, top = 1, right = 1, bottom = 0, wspace=0, hspace=0)
axs2[0][0].annotate(text="", xy=(1.00, 1.032), xytext=(0.535,1.032), xycoords="figure fraction",  arrowprops=dict(facecolor='C1'))
axs2[0][0].annotate(text="", xy=(0.05, 1.032), xytext=(0.525,1.032), xycoords="figure fraction",  arrowprops=dict(facecolor='C0'))
axs2[0][0].annotate(text="Grade", xy = (0.53,1.05), xycoords="figure fraction", ha="center", size = 18)
axs2[0][0].annotate(text="Low", xy = (0.05, 1.05), xycoords="figure fraction", ha="center", size = 16)
axs2[0][0].annotate(text="High", xy = (1.00, 1.05), xycoords="figure fraction", ha="center", size = 16)

plt.show()

Example output: <img src='https://github.com/fmhoward/Hist
