rein

| English | 中文 |

| Commit Log |

Introduction

This program is used to efficiently redirect connections from one IP address/port combination to another.

It is useful when operating virtual servers, dockers, firewalls and so on.

It creates a tunnel from a public endpoint to a locally running service (version >= 1.0.5). It was developed by golang.

• rein support mode:

| mode | tip | | ----------- | ------------------------------------------------------------ | | upstream | It is used to efficiently redirect connections from one IP address/port combination to another. | | fileshare | local files publishing. | | inps | It creates a tunnel from a public endpoint to a locally running service. Put inps onto your server with public IP. (version >= 1.0.5) | | inpc | It creates a tunnel from a public endpoint to a locally running service. Put inpc onto your server in LAN (that can't be connected from public Internet). (version >= 1.0.5) |

• inps and inpc mode illustration:

---

1. Download by your OS

All release download: https://github.com/firstboot/rein/releases

1.1 Download

• 1.1.1 Download by CentOS/RHEL/Ubuntu （amd64）

cd ~
wget \
https://github.com/firstboot/rein/releases/download/v1.0.6-bin/rein-1.0.6-amd64-linux.zip
unzip rein-1.0.6-amd64-linux.zip
mv rein-1.0.6-amd64-linux rein
chmod +x rein

• 1.1.2 Download by Windows (amd64)

  • download file

    https://github.com/firstboot/rein/releases/download/v1.0.6-bin/rein-1.0.6-amd64-win.exe.zip

  • decompress rein-x.x.x-amd64-windows.zip

---

2. Simple deployment

2.1 Specify required functions

• Which mode do you want to use ?

| mode | tip | | ----------- | ------------------------------------------------------------ | | upstream | It is used to efficiently redirect connections from one IP address/port combination to another. | | fileshare | local files publishing. | | inps/inpc | It creates a tunnel from a public endpoint to a locally running service. (server/client endpoint) (version >= 1.0.5) |

2.2 Function mode tip

Tip: OS description of operating differences, CentOS/RHEL/Ubuntu will be used by default in subsequent instructions. 2.2.1 will still introduce them separately.

# show all mode, CentOS/RHEL/Ubuntu, eg: upstream
./rein -e-detail
./rein -e-detail-upstream

# generate config file, CentOS/RHEL/Ubuntu, eg: upstream
./rein -e-detail-upstream > rein.json

#####################################################

# show all mode, Windows, eg: upstream
./rein.exe -e-detail
./rein.exe -e-detail-upstream

# generate a mode conf file, eg: upstream
# Windows cmd
./rein.exe -e-detail-upstream > rein.json

# Windows powershell, eg: upstream
./rein.exe -e-detail-upstream | out-file -encoding ascii rein.json

• 2.2.1 How to use mode upstream?

  Use -e-detail-xxx option, generate config and running.

  • CentOS/RHEL/Ubuntu

    • # show all mode
      ./rein -e-detail
      Enter a mode, show specific example, as follow:
      -e-detail-upstream
      -e-detail-inps
      -e-detail-inpc
      -e-detail-fileshare

      # generate a mode conf file, eg: upstream
      ./rein -e-detail-upstream > rein.json

      # rein.json, modify rein.json for you
      {
      	"upstream": [
      		{"source": "0.0.0.0:8150", "target": "127.0.0.1:9990"}
      	]
      }

      # running
      ./rein -c rein.json


  • Windows

    • # show all mode
      ./rein.exe -e-detail
      Enter a mode, show specific example, as follow:
      -e-detail-upstream
      -e-detail-inps
      -e-detail-inpc
      -e-detail-fileshare

      # generate a mode conf file, eg: upstream
      # windows cmd
      ./rein.exe -e-detail-upstream > rein.json

      # windows powershell
      ./rein.exe -e-detail-upstream | out-file -encoding ascii rein.json

      # rein.json, modify rein.json for you
      {
      	"upstream": [
      		{"source": "0.0.0.0:8150", "target": "127.0.0.1:9990"}
      	]
      }

      # running
      ./rein.exe -c rein.json


• 2.2.2 How to use mode fileshare?

  # show default config
  ./rein -e-detail-fileshare
  {
  	"fileshare": [
  		{"port": "9990", "path": "."}
  	]
  }

  # generate a mode conf file
  ./rein -e-detail-fileshare > rein.json

  # rein.json, modify rein.json for you
  {
  	"fileshare": [
  		{"port": "9990", "path": "."}
  	]
  }

  # running
  ./rein -c rein.json


• 2.2.3 How to use mode inps/inpc?

  If you have a server(A) public IP is 52.74.223.119 , and you have a server(B) private IP is 192.168.1.122.

  Put inps onto your server A with public IP. Put inpc onto your server B in LAN (that can't be connected from public Internet).

  illustration:



  deploy: inps

  Put inps onto your server A with public IP.

  # generate a mode conf file
  ./rein -e-detail-inps > rein.json

  # rein.json, modify rein.json for you
  {
  	"inps": [
  		{"ctrl": "0.0.0.0:17500"}
  	]
  }

  # running
  ./rein -c rein.json


  deploy: inpc

  Put inpc onto your server B in LAN (that can't be connected from public Internet).

  # generate a mode conf file
  ./rein -e-detail-inpc > rein.json

  # rein.json, modify rein.json for you
  # port 17500 is 'inps' server port
  # port 22 is local host service port, this port is ssh
  # port 9800 is 'inps' server open port
  {
  	"inpc": [
  		{
  			"ctrl": "52.74.223.119:17500",
  			"source": "0.0.0.0:9800",
  			"target": "127.0.0.1:22"
  		}
  	]
  }

  # running
  ./rein -c rein.json


  query: inpq (verion 1.0.6+)

  Get current inps link status.

  # get inps link status, x.x.x.x:17500 is inps ip addr.
  ./rein -inpq x.x.x.x:17500
  0.0.0.0:9800/127.0.0.1:22, online
