HareMQ

A C++ version of the simplified message queue component is implemented based on RabbitMQ. In order to learn RabbitMQ, this project encompasses the essence and core functions of a high-performance messaging system, imitates the basic architecture of RabbitMQ, and focuses on the publish-subscribe mechanism.

<a href="https://github.com/ffengc"> <img src="https://img.shields.io/static/v1?label=Github&message=ffengc&color=blue" alt="ffengc.github"> </a> <a href="https://ffengc.github.io"> <img src="https://img.shields.io/static/v1?label=Page&message=ffengc.github.io&color=red" alt="ffengc.github.io"> </a> <a href="https://ffengc.github.io/gh-blog/"> <img src="https://img.shields.io/static/v1?label=Blog&message=Blog Page&color=brightgreen" alt="Mutable.ai Auto Wiki"> </a>

• 简体中文
• English

[!TIP] If you have any questions about the operation and implementation of this project, or if you have better optimization suggestions for this project, you can contact me directly or leave an issue in the repository.

About MQ Middleware

Message queuing (MQ) middleware is a software or service used to asynchronously pass messages between different applications, systems, or services. It allows various systems to communicate independently without having to connect directly to each other, thereby improving the scalability, flexibility, and maintainability of the system. Some typical uses of message queue middleware include decoupling service components, enhancing concurrent processing capabilities, and balancing loads.

RabbitMQ is a popular open source message queue system that supports multiple message protocols, mainly using AMQP (Advanced Message Queuing Protocol). RabbitMQ allows applications to send, receive, and store messages through a simple protocol until they are received. Here are some of its key features:

1. Flexible routing: RabbitMQ provides a variety of message routing methods, including direct, topic, header, and fan-out exchanges, which makes it very flexible in messaging.
2. Reliability: RabbitMQ supports message persistence to ensure that messages are not lost due to server failures.
3. High availability: RabbitMQ clusters can be configured to ensure high availability and failover of services.
4. Multiple client support: Supports client libraries in multiple programming languages, such as Python, Java, .NET, etc.

Message queue middleware such as RabbitMQ is widely used in various scenarios such as big data processing, microservice architecture, distributed systems, and real-time data processing.

This project will focus on RabbitMQ, learn and extract the essence of it, learn the basic principles of RabbitMQ, and perform a simple simulation implementation of it. By studying this project, you can deepen your understanding of message queue middleware, which will be of great help to subsequent development.

Effect Demonstration

<div align="center">

https://github.com/user-attachments/assets/61f75c44-926b-4938-b773-81f1ef1069da

</div>

As shown in the figure, after the server is turned on, log in to the client using two terminals, define the switch, queue and binding relationship, and then clientA sends a message to the switch group1. After clientB subscribes to the queue group1_q, it can receive the message sent by clientA. This is the most basic function demonstration. For other detailed functions, please refer to the detailed usage documentation.

• The Documentation Of HareMQ

Technology stack

• Serialization framework: Protobuf for binary serialization
• Network communication: Custom application layer protocol + muduo library: Encapsulation of TCP long connection, and use of epoll event-driven mode to achieve high-concurrency server and client•
• Source data information database: SQLite3
• Unit test framework: Gtest

Environment Configuration

<details> <summary><strong>Configuration and deployment</strong></summary>

Basic tools

First, you need the following basic tools:

gcc/g++ versions higher than 7, git, cmake, etc.

Install protobuf

It is a serialization and deserialization tool.

Installation dependencies:

# centos
sudo yum install autoconf automake libtool curl make gcc-c++ unzip
# ubuntu
sudo apt update
sudo apt install autoconf automake libtool curl make g++ unzip

Download the protobuf package:

wget https://github.com/protocolbuffers/protobuf/releases/download/v3.20.2/protobuf-all-3.20.2.tar.gz

Compile and install:

# unzip
tar -zxf protobuf-all-3.20.2.tar.gz
cd protobuf-3.20.2/
# Run the directory configuration script
./autogen.sh
# Run the configuration script
./configure
# Compile (takes longer)
make
# Install
sudo make install
# Confirm whether the installation is successful
protoc --version

The installation is successful as shown in the figure.

Install the muduo lib

Download the code.

git clone https://github.com/chenshuo/muduo.git

Installation dependencies:

# centos
sudo yum install gcc-c++ cmake make zlib zlib-devel boost-devel
# ubuntu
sudo apt update
sudo apt install g++ cmake make zlib1g zlib1g-dev libboost-all-dev

‼️ Here I want to explain that if the compilation process prompts that the protoc related library cannot be found, it is because the installation path of protobuf at that time is different from that required by muduo. You need to link the related library to the specified location (depending on the error message). Another possible problem is the error related to the boost library (python conda is installed on the machine). It may appear that when muduo looks for boost, it finds the boost in conda. The solution is to temporarily hide annaconda3, and then the compilation will be successful.

Verify that muduo is installed successfully

Tips: The compiled muduo executable is in the build directory of the parent directory, not in the muduo directory. It is in the build directory at the same level as muduo.

Enter the directory where muduo tests can be executed: build/release-cpp11/bin

run the demo server:

./protobuf_server 9091

Similarly, if a link error occurs, just link the corresponding library to the corresponding place.

run the demo client:

./protobuf_client 0.0.0.0 9091

The test is passed as shown in the figure.

Install SQLite3

This is a lightweight database.

# centos
sudo yum install sqlite-devel
# ubuntu
sudo apt install sqlite3
# Verify installation
sqlite3 --version

Install the gtest testing framework

# centos
sudo yum install epel-release
sudo yum install dnf
sudo dnf install dnf-plugins-core
sudo dnf install gtest gtest-devel
# ubuntu
sudo apt update
sudo apt install libgtest-dev

Test whether gtest is installed successfully:

Run the env/test.cc code. If the output is normal, the installation is successful.

</details>

Introduction and learning of project related frameworks

These are the documents and codes I compiled while learning some third-party frameworks I needed to use during this project.

If you are not interested in this part or have already mastered the use of these frameworks, you can skip it directly.

• doc: protobuf.md, code: HareMQ/demo/protobuf
• doc: muduo.md, code: HareMQ/demo/muduo
• doc: sqlite.md, code: HareMQ/demo/sqlite
• doc: gtest.md, code: HareMQ/demo/gtest
• doc: asynchronous in C++11, code: HareMQ/demo/asynchronous
• doc: Thread pool component based on C++ asynchronous operation, code: HareMQ/demo/thread_pool

Project Framework

Basic Framework

Among them, Broker Server is the core part, responsible for the storage and forwarding of messages

In the AMQP (Advanced Message Queuing Protocol, an application layer standard advanced message queue protocol that provides unified message services, designed for message-oriented middleware, making full-function interoperability between client applications and message middleware servers that comply with this specification possible) model, that is, in the message middleware server Broker, there are the following concepts:

• Virtual Machine (VirtualHost): Similar to MySQL's "database", it is a logical collection. There can be multiple VirtualHosts on a BrokerServer.
• Exchange (Exchange): The producer first sends the message to the Broker's Exchange, and then forwards the message to different Queues according to different rules.
• Queue: The part that actually stores messages. Each consumer decides which queue to read messages from.
• Binding: The relationship between Exchange and Queue. Exchange and Queue can be understood as a "many-to-many relationship. A relationship table can be used to link these two concepts.
• Message: The content of the transmission

[!NOTE] The data structure shown in the structure diagram needs to be stored in both memory and hard disk.

• Memory storage: convenient and practical
• Hard disk storage: data is not lost after restart

Core API

For Broker, the following core APIs need to be implemented to implement the basic functions of the message queue.

1. Create an exchange exchangeDeclare
2. Destroy an exchange exchangeDelete
3. Create a queue queueDeclare
4. Destroy a queue queueDelete
5. Create a binding queueBind
6. Unbind queueUnbind
7. Publish a message basicPublish
8. Subscribe to a message basicConsume
9. Confirm a message basicAck
10. Unsubscribe basicCancel

On the other hand, producers and consumers remotely call these APIs through the network to implement the producer-consumer model.
