Deucalion

High-performance Windows library for capturing decoded FFXIV packets. This library is fairly limited in scope and it is intended to be used in conjunction with other packet handling applications.

Compatibility

Deucalion only supports 64-bit versions of FFXIV using DX11.

The following is the compatibility matrix for Deucalion:

| FFXIV Version | Deucalion Version | | ------------- | ------------------ | | 6.x | 0.9.x | | 7.0-7.1x | 1.1.x | | 7.2x | 1.2.x | | 7.3x-7.40 | 1.4.0 (deprecated) | | 7.3+ | 1.5.x |

Features

• This library can be used as a sniffer on the FFXIV packet protocol layer without concern for the lower-level TCP layer.
• Deucalion runs as an injected DLL and hooks the function responsible for reading decoded packets. Therefore, this method of capture is not susceptible to the limitations of libpcap-based capture.
• Deucalion functions as a broadcast server that streams captured packets to one or many subscribers.

Building

1. Install the nightly version of Rust for Windows.

2. git clone this repo.

3. cd into deucalion and run cargo build. The DLL will be located in target/debug/deucalion.dll.

:information_source: A console window will appear when the DLL is running if the DLL is compiled in the debug profile. To hide the console window, compile the DLL in the release profile by supplying --release to the cargo build command.

Basic Usage

On initialization, Deucalion exposes a Named Pipe server that follows a length-delimited protocol for capturing packets or for subscriber requests.

1. Inject deucalion.dll into ffxiv_dx11.exe with any method you choose. If built in debug mode, a console window will appear after attaching.
2. Initiate a Named pipe session with Deucalion by connecting to \\.\pipe\deucalion-{FFXIV PID}. For example, if the PID of a running FFXIV process is 9000, then the name of the pipe is \\.\pipe\deucalion-9000.
3. Deucalion will begin broadcasting received Zone packets to all subscribers. See Data Format for information on the format of the broadcasted packets.
4. Deucalion will close and unload itself once all subscribers are disconnected.

:information_source: By default, Deucalion's will not send you packets for anything other than received Zone packets. To allow other packet types, please see the Option OP section.

Payload Format

All communication with Deucalion follows this length-delimited protocol (ranges are inclusive):

| bytes [0, 3] | byte 4 | bytes [5, 8] | bytes [9, N] | | ------------ | ------ | ------------ | ------------ | | LENGTH (u32) | OP | CHANNEL | DATA |

Length

This is the total length of the entire payload, including the length bytes.

OP Types

| OP | Name | Description | | --- | --------- | --------------------------------------------------------------------------------------------------------------------------------- | | 0 | Debug | Used for passing debug text messages. | | 1 | Ping | Used to maintain a connection between the subscriber and Deucalion. Deucalion will echo the same payload when it receives a ping. | | 2 | Exit | Used to signal Deucalion to unload itself from the host process. In most use cases, you will not need to send this OP at all. | | 3 | Recv | When sent from Deucalion, contains the FFXIV IPC packet received by the host process. | | 4 | Send | When sent from Deucalion, contains the FFXIV IPC packet sent by the host process. | | 5 | Option | Used to configure per-subscriber filtering for packets. | | 6 | RecvOther | When sent from Deucalion, contains the FFXIV non-IPC segment received by the host process. | | 7 | SendOther | When sent from Deucalion, contains the FFXIV non-IPC segment sent by the host process. |

Channel

This is an identifier for the channel used for the payload. It is used to distinguish between streams of data (e.g., Zone packets vs Chat packets).

For Recv and Send OPs, the following CHANNELs correspond to these packet types:

| CHANNEL | Name | | ------- | ----- | | 0 | Lobby | | 1 | Zone | | 2 | Chat |

For the Debug OP, the CHANNEL 9000 indicates the HELLO CHANNEL.

Data

For payloads with OP Debug, the payload is simply debug-logged.

For payloads with OP Recv or Send, the data is the FFXIV IPC packet captured from the host process. The packets are already in the correct order, but they still need to be decoded by your application. See Data Format for more information on how to handle this data.

Payloads with OP RecvOther or SendOther will contain FFXIV non-IPC segments captured from the host process. This is also discussed in Data Format.

Subscriber Protocol

The Deucalion server is capable of receiving and handling requests from the subscriber. The CHANNEL field is used to send request context, and Deucalion will reply to the requesting subscriber with a Debug-OP payload with the same CHANNEL.

Debug OP

Any payload sent with the Debug OP with a CHANNEL other than HELLO will be simply be debug-logged and an OK response will be sent back to the requesting subscriber.

For payloads with the Debug OP and the HELLO channel, the DATA sent will be set as the nickname for the current subscriber.

These are the restrictions on the values of nickname that are accepted:

• The bytes in DATA must be valid UTF-8.
• Must contain only ASCII alphanumeric characters or underscores (^[A-Za-z0-9_]+$)
• Must be 30 characters or less
• Names are allowed to be the same as other subscribers.

For example:

Payload { OP: OP.Debug, CHANNEL: 9000, DATA: u8"TEST_CLIENT" }
// Deucalion: Nickname set response
Payload { OP: OP.Debug, CHANNEL: 9000, DATA: u8"CHANGED NICKNAME: TEST_CLIENT (subscriber 0)" }

Ping OP

Any Ping-OP payload sent to Deucalion will be echoed back to the requesting subscriber.

Exit OP

Deucalion will immediately begin unloading all hooks and cleaning itself from the host process without sending a response back to the subscriber.

:warning: It is not required to send this OP to Deucalion! Deucalion will safely exit on its own once all subscribers are disconnected. Causing Deucalion to exit early may cause undefined behavior in subscribers that are still connected.

Recv OP

In most cases, subscribers do not need to send a Recv OP payload to initialize the hook. However if the hook has not been automatically initialized, then subscribers may send a pattern signature as a UTF-8-encoded string in a Recv OP payload in order to manually initialize the hook.

See Example for this scenario. For information on the signature format, please see https://docs.rs/pelite/latest/pelite/pattern/fn.parse.html.

:warning: Once the Recv hook is initialized, all subscribers will receive the packet stream regardless of whether or not their own initialization succeeded. As such, it is wise to begin handling data as soon as the named pipe connection is established and handle initialization asynchronously.

Send OP

What applies to Recv OP payloads sent from subscribers also applies to Send OP payloads sent from subscribers.

However, payloads with CHANNEL set to 0 will initialize the SendLobbyPacket hook. Payloads with any other CHANNEL value will initialize the SendPacket hook (handles Chat and Zone.)

Option OP

By default, Deucalion sets a per-subscriber filter that allows only Recv Zone payloads to be sent to the subscriber.

Each subscriber can customize their own filter for what Recv or Send packets are sent by Deucalion. Other payload OPs such as Debug are not affected by this filter.

Filters can be set by sending an Option OP with bitflags as the CHANNEL.

| Flag | Description | | ------ | -------------------------------------- | | 1 << 0 | Allows received Lobby packets. | | 1 << 1 | Allows received Zone packets. | | 1 << 2 | Allows received Chat packets. | | 1 << 3 | Allows sent Lobby packets. | | 1 << 4 | Allows sent Zone packets. | | 1 << 5 | Allows sent Chat packets. | | 1 << 6 | Allows other packet types or channels. |

For example, to allow received Zone, received Chat, sent Zone, and sent Chat packets, you can compute the filter value:

54 == (1 << 1 | 1 << 2 | 1 << 4 | 1 << 5)

and send the payload:

Payload { OP: OP.Option, CHANNEL: 54, DATA:
