LSTNet

This repository is a Tensorflow / Keras implementation of Modeling Long- and Short-Term Temporal Patterns with Deep Neural Networks paper https://arxiv.org/pdf/1703.07015.pdf

This implementation has been inspired by the following Pytorch implementation https://github.com/laiguokun/LSTNet

Installation

Clone this prerequisite repository:

git clone https://github.com/fbadine/util.git

Clone this repository:

git clone https://github.com/fbadine/LSTNet.git
cd LSTNet
mkdir log/ save/ data/

Download the dataset from https://github.com/laiguokun/multivariate-time-series-data and copy the text files into LSTNet/data/

Usage

Training

There are 4 different script samples to train, validate and test the model on the different datasets:

• electricity.sh
• exchange_rate.sh
• solar.sh
• traffic.sh

Predict

In order to predict and plot traffic you will need to run main.py as follows (example for the electricity traffic)

python main.py --data="data/electricity.txt" --no-train --load="save/electricity/electricity" --predict=all --plot --series-to-plot=0

Running Options

The following are the parameters that the python script takes along with their description:

| Input Parameters | Default | Description | | :-----------------| :------------------| :-----------| | --data | |Full Path of the data file. (REQUIRED)| | --normalize |2 |Type of data normalisation:<br> - 0: No Normalisation<br> - 1: Normalise all timeseries together<br> - 2: Normalise each timeseries alone| | --trainpercent |0.6 |Percentage of the given data to use for training| | --validpercent |0.2 |Percentage of the given data to use for validation| | --window |24 * 7 |Number of time values to consider in each input X| | --horizon |12 |How far is the predicted value Y. It is horizon values away from the last value of X (into the future)| | --CNNFilters |100 |Number of output filters in the CNN layer<br>A value of 0 will remove this layer| | --CNNKernel |6 |CNN filter size that will be (CNNKernel, number of multivariate timeseries)<br>A value of 0 will remove this layer| | --GRUUnits |100 |Number of hidden states in the GRU layer| | --SkipGRUUnits |5 |Number of hidden states in the SkipGRU layer| | --skip |24 |Number of timeslots to skip.<br>A value of 0 will remove this layer| | --dropout |0.2 |Dropout frequency| | --highway |24 |Number of timeslots values to consider for the linear layer (AR layer)| | --initializer |glorot_uniform |The weights initialiser to use| | --loss |mean_absolute_error |The loss function to use for optimisation| | --optimizer |Adam |The optimiser to use<br>Accepted values:<br> - SGD<br> - RMSprop<br> - Adam| | --lr |0.001 |Learning rate| | --batchsize |128 |Training batchsize| | --epochs |100 |Number of training epochs| | --tensorboard |None |Set to the folder where to put the tensorboard file<br>If set to None => no tensorboard| | --no-train | |Do not train the model| | --no-validation | |Do not validate the model| | --test | |Evaluate the model on the test data| | --load |None |Location and Name of the file to load a pre-trained model from as follows:<br> - Model in filename.json<br> - Weights in filename.h5| | --save |None |Full path of the file to save the model in as follows:<br> - Model in filename.json<br> - Weights in filename.h5<br>This location is also used to save results and history as follows:<br> - Results in filename.txt<br> - History in filename_history.csv if --savehistory is passed| | --no-saveresults | |Do not save results| | --savehistory | |Save training / validation history in file as described in parameter --save above| | --predict |None |Predict timeseries using the trained model<br>It takes one of the following values:<br> - trainingdata: predict the training data only<br> - validationdata: predict the validation data only<br> - testingdata: predict the testing data only<br> - all: all of the above<br> - None: none of the above| | --plot | |Generate plots| | --series-to-plot |0 |Series to plot<br>Format: series,start,end<br> - series: the number of the series you wish to plot<br> - start: start timeslot (default is the start of the timeseries)<br> - end: end timeslot (default is the end of the timeseries)| | --autocorrelation |None |Autocorrelation plotting <br>Format: series,start,end<br> - series: the number of random timeseries you wish to plot the autocorrelation for<br> - start: start timeslot (default is the start of the timeseries)<br> - end: end timeslot (default is the end of the timeseries)| | --save-plot | None | Location and name of the file to save the plotted images to<br> - Autocorrelation in filename_autocorrelation.png<br> - Training history in filename_training.png<br> - Prediction in filename_prediction.png| | --no-log | |Do not create logfiles<br>However error and critical messages will still appear| | --logfilename |log/lstnet |Full path of the logging file| | --debuglevel |20 |Logging debug level|

Results

The followinng are the results that were obtained:

| Dataset | Width | Horizon | Correlation | RSE | | :-------------| :-----------| :-----------| :-----------| :-----------| | Solar | 28 hours | 2 hours | 0.9548 | 0.3060 | | Traffic | 7 days | 12 hours | 0.8932 | 0.4089 | | Electricity | 7 days | 24 hours | 0.8856 | 0.3746 | | Exchange Rate | 168 days | 12 days | 0.9731 | 0.1540 |

Dataset

As described in the paper the data is composed of 4 publicly available datasets downloadable from https://github.com/laiguokun/multivariate-time-series-data:

• Traffic: A collection of 48 months (2015-2016) hourly data from the California Department of Transportation
• Solar Energy: The solar power production records in 2006, sampled every 10 minutes from 137 PV plants in the state of Alabama
• Electricity: Electricity consumption for 321 clients recorded every 15 minutes from 2012 to 2014
• Exchange Rate: A collection of daily average rates of 8 currencies from 1990 to 2016

Environment

Primary environment

The results were obtained on a system with the following versions:

• Python 3.6.8
• Tensorflow 1.11.0
• Keras 2.1.6-tf

TensorFlow 2.0 Ready

The model has also been tested on TF 2.0 alpha version:

• Python 3.6.7
• Tensorflow 2.0.0-alpha0
• Keras 2.2.4-tf
