eRaft: A Distributed Sharded KV Storage System

eRaft is a high-performance distributed key-value storage system implemented in Go. It features:

• Consensus: Raft algorithm for consistency and high availability.
• Transport: gRPC for efficient inter-node and client-server communication.
• Storage: RocksDB as the persistent storage engine.
• Sharding: Dynamic sharding with a dedicated configuration cluster.

Installation

See INSTALL.md for detailed installation and build instructions for macOS and Linux.

Documentation (Wiki)

Detailed information about the system design and implementation can be found in our project Wiki:

• Architecture Overview
• Raft Consensus Implementation
• Sharding & Migration Mechanism
• Storage & RPC Layer
• Benchmark & Performance

AI-Powered Development

This project was built with the assistance of AI, representing a paradigm shift in software engineering efficiency:

graph LR
    A[Traditional Coding] --> B[Horse Carriage Era]
    B --> C[Manual Boilerplate]
    B --> D[Painful Debugging]

    E[AI-Assisted Coding] --> F[Steam Engine Era]
    F --> G[Intelligent Generation]
    F --> H[Automated Testing]

    C -.-> I[Low Efficiency]
    D -.-> I
    G -.-> J[High Efficiency]
    H -.-> J

Build

For detailed installation instructions, see INSTALL.md.

To build all components, run:

make build

Binaries will be generated in the output/ directory.

Note: eRaft uses RocksDB as the storage engine. Please ensure RocksDB is installed on your system before building. See INSTALL.md for platform-specific instructions.

Quick Start Guide

Step 1: Start the Configuration Cluster (ShardCtrler)

The configuration cluster manages shard assignments. Start 3 nodes:

# Terminal 1
./output/shardctrlerserver -id 0 -cluster "localhost:50051,localhost:50052,localhost:50053" -db "data/sc0"

# Terminal 2
./output/shardctrlerserver -id 1 -cluster "localhost:50051,localhost:50052,localhost:50053" -db "data/sc1"

# Terminal 3
./output/shardctrlerserver -id 2 -cluster "localhost:50051,localhost:50052,localhost:50053" -db "data/sc2"

Step 2: Start ShardKV Groups

A ShardKV group stores the actual data. We will start two groups (GID 100 and GID 101) to demonstrate sharding.

Group 100 (3 nodes):

# Terminal 4, 5, 6
./output/shardkvserver -id 0 -gid 100 -cluster "localhost:6001,localhost:6002,localhost:6003" -ctrlers "localhost:50051,localhost:50052,localhost:50053" -db "data/skv100_0"
./output/shardkvserver -id 1 -gid 100 -cluster "localhost:6001,localhost:6002,localhost:6003" -ctrlers "localhost:50051,localhost:50052,localhost:50053" -db "data/skv100_1"
./output/shardkvserver -id 2 -gid 100 -cluster "localhost:6001,localhost:6002,localhost:6003" -ctrlers "localhost:50051,localhost:50052,localhost:50053" -db "data/skv100_2"

Group 101 (3 nodes):

# Terminal 7, 8, 9
./output/shardkvserver -id 0 -gid 101 -cluster "localhost:7001,localhost:7002,localhost:7003" -ctrlers "localhost:50051,localhost:50052,localhost:50053" -db "data/skv101_0"
./output/shardkvserver -id 1 -gid 101 -cluster "localhost:7001,localhost:7002,localhost:7003" -ctrlers "localhost:50051,localhost:50052,localhost:50053" -db "data/skv101_1"
./output/shardkvserver -id 2 -gid 101 -cluster "localhost:7001,localhost:7002,localhost:7003" -ctrlers "localhost:50051,localhost:50052,localhost:50053" -db "data/skv101_2"

Step 3: Register the ShardKV Groups

Use the shardctrlerclient to register both groups to the configuration cluster:

# Register Group 100
./output/shardctrlerclient join 100=localhost:6001,localhost:6002,localhost:6003

# Register Group 101
./output/shardctrlerclient join 101=localhost:7001,localhost:7002,localhost:7003

Step 4: Data Operations

Now you can read and write data using the shardkvclient:

# Write data
./output/shardkvclient put mykey myvalue

# Read data
./output/shardkvclient get mykey

# Append data
./output/shardkvclient append mykey " extra"

# Run benchmark
./output/shardkvclient bench 1000

Cluster Monitoring

Check the status of all nodes in the cluster:

# ShardKV status
./output/shardkvclient status

# ShardCtrler status
./output/shardctrlerclient status

Dashboard Visualization

The Dashboard provides a web interface for real-time monitoring of cluster status, topology, and performance metrics.

Building the Dashboard

# Build backend server
make builddashboard

# Build frontend (first time requires dependency installation)
cd dashboard/frontend
npm install  # Pre-configured with Taobao mirror for users in China
npm run build

Starting the Dashboard

# Start the Dashboard server (run after completing Steps 1-3)
./output/dashboard-server \
  -port=8080 \
  -config-addrs="localhost:50051,localhost:50052,localhost:50053" \
  -update-interval=5s

Then access in your browser: http://localhost:8080

The Dashboard provides the following features:

• Cluster Topology: Visualize config cluster and shard group node status, roles (Leader/Follower)
• Shard Status: Real-time display of each shard's health status, assigned group, and key count
• Performance Metrics: Monitor total nodes, healthy nodes, storage capacity, average load, and other key metrics
• Auto Refresh: Automatically updates cluster status every 5 seconds
• Dynamic Discovery: Automatically queries the latest configuration from ShardCtrler, no manual shard group specification needed

Shard Migration Process

When you use the move command or when the configuration changes (due to join/leave), the system performs an automatic data migration:

1. Config Update: The shardctrler updates the shard-to-group mapping.
2. Detection: Each shardkv group leader periodically polls the controller for configuration changes.
3. Pulling: If a group finds it is now responsible for a shard it didn't own before, it switches that shard's status to Pulling and starts fetching data from the previous owner.
4. Integration: Once the data is received, it is appended to the new group's Raft log and applied to its LevelDB storage.
5. Garbage Collection: After the migration is confirmed, the new owner notifies the previous owner to delete the stale data (GC), ensuring data consistency and freeing up space.
