GrowBox
Model: <a target="_blank" href="https://amzn.to/3x9uhFN">MARS HYDRO TS1000 Growbox Kit</a>
This project aims to Automate GrowBoxes in order to make the freshes and biggest fruits / flowers of your plants.
Working Features
- WebClient on ESP.
- Inline Fan Control for the analog fan.
- Humidity / Temperature / Pressure <a target="_blank" href="https://amzn.to/3TYbDtB">GY-BME280</a>.
Planned Features
- Plant height, Supersonic.
- Pump control for fertilizer, water.
- Water warning, via soil moisture? Unclear if this can't be just calculated way better than probed.
- EC / PH, as the sensors are quite expensive i might skip this try or push it way back the road.
Features
WebClient
<img src="./res/client.png" width="200" />WebClient control fan speed and read current or retained conditions obtained by the <a target="_blank" href="https://amzn.to/3TYbDtB">GY-BME280</a>.
API
API definition of the GrowBox, API is using JSON for data and plain text for errors.
<hr/>Get
Returns the current context. |Context|| |-|-| |me|hostname| |fsMounted|file system mounted 1 / 0| |fanSpeed|the fan speed, 255 = OFF, 0 = MAX| |bme|current bme data| |bmeRetained|retained bme readings|
http://growbox01/get
Response
{
"me": "GrowBox01",
"fsMounted": "1",
"fanSpeed": 255,
"bme": {
"temperature": 20.80,
"humidity": 45.48,
"pressure": 99961.20,
"timestamp": 1712060127
},
"bmeRetained": [
{
"temperature": 20.83,
"humidity": 44.85,
"pressure": 99960.22,
"timestamp": 1712057103
},
{
"temperature": 20.85,
"humidity": 45.49,
"pressure": 99970.94,
"timestamp": 1712053501
},
{
"temperature": 20.90,
"humidity": 47.11,
"pressure": 99957.71,
"timestamp": 1712049899
}
]
}
Fan Set
Sets the fan speed, 255 = OFF, 0 = MAX. Fanspeed is stored in EEPROM / Context.
http://growbox01/fan/set
Request
{
"fanSpeed": 150
}
Response
The current context.
{
"me": "GrowBox01",
"fsMounted": "1",
"fanSpeed": 255,
"bme": {
"temperature": 20.80,
"humidity": 45.48,
"pressure": 99961.20,
"timestamp": 1712060127
},
"bmeRetained": [
{
"temperature": 20.83,
"humidity": 44.85,
"pressure": 99960.22,
"timestamp": 1712057103
},
{
"temperature": 20.85,
"humidity": 45.49,
"pressure": 99970.94,
"timestamp": 1712053501
},
{
"temperature": 20.90,
"humidity": 47.11,
"pressure": 99957.71,
"timestamp": 1712049899
}
]
}
D1 Mini Board Config
<a href="./res/arduino.json">arduino.json</a> or:
<div align="center"> <img src="./res/board-config.png" width="400" /> </div>Inline Fan Fritzing
100Ohm Resistor, BC337 Transistor, D1 Mini, 24v Stepdown. If you dissassemble the Fan you will find GND, VCC, R+ R- as pins on the driver board. CAUTION 220v are transformed on the same board, be aware of it. The R+ and R- pins are connected to the control knob cable, I reused this. <a href="./InlineFan.fzz"> <img src="./res/InlineFan_Steckplatine.png"> </a>
Amazon Basket
|Item|Description|
|-|-|
| <a target="_blank" href="https://amzn.to/3TDTPma">ESP-8622 D1 Mini</a> | D1 Mini to operate the Web-API. |
| <a target="_blank" href="https://amzn.to/4avrZPI">Transistor BC337</a> | A BC337 transistor. |
| <a target="_blank" href="https://amzn.to/4aB79hM">100Ohm Resistor</a> | A 100Ohm resistor. |
| <a target="_blank" href="https://amzn.to/3VyUdVE">Some cables</a> | I always take silicone wrapped cables because of their heat resistance and general durability.
| <a target="_blank" href="https://amzn.to/3J1IyHe">24v Stepdown</a> | Any stepdown converter from 24v to 5v. |
| <a target="_blank" href="https://amzn.to/3TYbDtB">GY-BME280</a> | GY-BME280 sensor for humidity / temperature / pressure. |
Those are affiliate links, use them if you want to support me :)
