tlsfp

Run a local HTTPS server or search through a pcap file and return client TLS data and/or fingerprints (ja3 and ja4).

Background

I first became interested in TLS fingerprinting when it was offered as a solution by a CDN provider at one of my previous jobs. The Solutions Engineer explained that we could use their new TLS fingerprint hash (instead of a combination of IP address and User-Agent) to block malicious clients who breach the WAF. Another engineer had analysed our WAF data from the previous month and identified a couple of fingerprints to block. I was told the malicious actor had been rotating their IP address to evade detection, enabling them to scrape our website in peace by staying under WAF rate limits. And now, using their SSL fingerprint, we could block them completely.

Wow. That's cool, I thought. I was fascinated but had lots of thoughts and questions running through my mind. Is it really that easy to uniquely identify a user from a TLS handshake? That doesn't seem very privacy-preserving. Farewell to CGNAT issues? How unique are TLS fingerprints? What specific data is used to build the fingerprint? I responded that it sounded great but I wanted to look into it and better understand how it worked before rolling it out. I said I'd get back to them soon and set myself a weekly reminder in slack to investigate.

A couple of weeks had passed and I got a reminder email about the deployment. I was busy and hadn't yet looked into it. I confirmed the WAF change had been rolled out to staging and did some quick tests using curl and firefox to make sure nothing was broken. OK. All looks good. Let's deploy it. Well, 5 minutes later we had our first complaint that the website was down. Luckily it came internally from a staff member, so gathering information for troubleshooting was easy.

It turned out that all Chrome users (using the latest release at the time) were blocked. The WAF change was immediately rolled back.

TLDR: A WAF deployment that blocked clients based on a TLS fingerprint inadvertently blocked a large chunk of website visitors who were using a specific version of Chrome browser.

Getting started

What is TLS fingerprinting?

TLS fingerprinting is a technique used to identify specific clients (e.g. software, web browsers, devices, bots, malware) based on the unique characteristics of their TLS handshake, specifically the Client Hello.
The most recent open-source TLS fingerprinting implementation (ja4) involves building a fingerpring based on these key elements:

Protocol: The protocol used by the client (i.e. TCP or QUIC)
Version: The TLS version used.
SNI: Whether a domain or IP was specified by the client.
Number of Cipher Suites. These are the cryptographic algorithms supported by the client.
Number of Extensions. Extensions are additional options or features supported by the client during the handshake e.g. SNI, ALPN (Application-Layer Protocol Negotiation), and others that enhance the capabilities and performance of the TLS connection.
First ALPN value. This is an extension allowing the application layer to negotiate which protocol should be used over a secure connection (e.g. HTTP1.1 or HTTP/2).
Truncated SHA256 Hash of the Cipher Suites (sorted)
Truncated SHA256 Hash of the Extensions (sorted) + Signature Algorithms (in the order they appear)

Here's an example of a ja4 fingerprint:

t13d4213h2_171bc101b036_5f0018e59d20

The raw version of the same fingerprint:

t13d4213h2_002f,0032,0033,0035,0038,0039,003c,003d,0040,0067,006a,006b,009c,009d,009e,009f,00a2,00a3,00ff,1301,1302,1303,1304,c009,c00a,c013,c014,c023,c027,c02b,c02c,c02f,c030,c09c,c09d,c09e,c09f,c0ac,c0ad,cca8,cca9,ccaa_000a,000b,000d,0015,0016,0017,001b,002b,002d,0031,0033_0403,0503,0603,0807,0808,0809,080a,080b,0804,0805,0806,0401,0501,0601,0303,0301,0402,0502,0602,0302,0203,0201,0202

Requirements

Python 3.10+
Python curio module for async socket operations. See requirements.txt.

How it works

tlsfp.py is imported and contains functions for unpacking TLS handshake data (specifically the ClientHello message) and building the fingerprints.
tls_vars.py is imported and contains data for verifying and mapping numerous bits of data used during a TLS handshake e.g. cipher suites, signature algorithms etc.
server.py starts a TCP server and listens on your chosen port. When a connection is received, the data in the socket receive buffer is checked to determine whether it appears to be a client TLS handshake request. If it does, the server-side TLS handshake is initiated and the data in the socket buffer is consumed. After completing the handshake we check for a valid HTTP request and respond with the client's TLS data (as hex strings) and fingerprints in JSON format.
http_helpers.py is imported and contains helper functions for our very crude HTTPS server.
pcap.py reads a given pcap file and finds all TLS ja4 fingerprints and prints them out.

Security Considerations

This tool is intended for educational purposes and is not production-ready.
It currently does not support parsing QUIC packets, only TLS over TCP.
Use in a secure, controlled environment as it uses self-signed certificates.

Installation

Clone the repository and use pip to install the required modules:

git clone https://github.com/elpy1/tlsfp.git
cd tlsfp
python -mpip install --user -r requirements.txt

Usage

These scripts have been tested on my local machine using OpenSSL 3.2.1 30 Jan 2024 (Library: OpenSSL 3.2.1 30 Jan 2024) and Python 3.12 with TLS 1.2 and TLS 1.3 data.

Get fingerprints from HTTPS server

Generate a self-signed key and certificate

Use openssl to generate the private key and cert, specifying the CN as localhost:

$ openssl req -x509 -sha256 -newkey rsa:2048 -keyout /tmp/server.key -out /tmp/server.crt -days 365 -nodes -subj /CN=localhost
.+...+......+..+...+....+........+++++++++++++++++++++++++++++++++++++++*............+..+.........+.+...+...........+....+...+.........+...+.....+.+......+......+.....+....+........+.+.....+......+..........+...+...+..+......+....+..+......+...+....+........+....+...+............+++++++++++++++++++++++++++++++++++++++*.+..+......+.........++++++
.......+...+..+...............+...+.+..+.......+..+......+.......+.....+.+............+..+.+.....+......+.+........+...............+...................+..+++++++++++++++++++++++++++++++++++++++*..+++++++++++++++++++++++++++++++++++++++*...........+...+.+.....+................+.....+.+...+...............++++++
-----

After verifing that the key and certificate files were created successfully, move on to the next step to start the server.

Start the server locally

Run the server script to listen for connections locally on port 4433:

python server.py --key /tmp/server.key --cert /tmp/server.crt --host 127.0.0.1 --port 4433

Get fingerprints

Visit https://localhost:4433/tls in your browser and accept the warning (due to using a self-signed certificate).

Alternatively, use curl --insecure/-k:

$ curl -v -k https://localhost:4433/tls

The server will return a JSON object with TLS fingerprint data, such as:

{"tls_data": {"protocol_version": "0303", "cipher_suites": ["fafa", "1301", "1302", "1303", "c02b", "c02f", "c02c", "c030", "cca9", "cca8", "c013", "c014", "009c", "009d", "002f", "0035"], "extensions": ["caca", "4469", "002b", "001b", "0010", "000b", "000d", "000a", "0012", "0023", "0000", "0005", "0033", "ff01", "002d", "0017", "fafa", "0015"], "server_name": "6c6f63616c686f7374", "ec_point_formats": ["00"], "supported_groups": ["dada", "001d", "0017", "0018"], "alpn": ["6832", "687474702f312e31"], "signature_algorithms": ["0403", "0804", "0401", "0503", "0805", "0501", "0806", "0601"], "supported_versions": ["1a1a", "0304", "0303"]}, "tls_fingerprints": {"ja3_r": "771,4865-4866-4867-49195-49199-49196-49200-52393-52392-49171-49172-156-157-47-53,17513-43-27-16-11-13-10-18-35-0-5-51-65281-45-23-21,29-23-24,0", "ja3": "b9067e67ecd275c2086c44955ce25543", "ja4_r": "t13d1516h2_002f,0035,009c,009d,1301,1302,1303,c013,c014,c02b,c02c,c02f,c030,cca8,cca9_0005,000a,000b,000d,0012,0015,0017,001b,0023,002b,002d,0033,4469,ff01_0403,0804,0401,0503,0805,0501,0806,0601", "ja4": "t13d1516h2_8daaf6152771_e5627efa2ab1", "ja4_ro": "t13d1516h2_1301,1302,1303,c02b,c02f,c02c,c030,cca9,cca8,c013,c014,009c,009d,002f,0035_4469,002b,001b,0010,000b,000d,000a,0012,0023,0000,0005,0033,ff01,002d,0017,0015_0403,0804,0401,0503,0805,0501,0806,0601", "ja4_o": "t13d1516h2_acb858a92679_4a3e79e229c6"}}

Try a different browser and check the fingerprint data. Each different client (e.g. curl and firefox) is likely to have its own fingerprint. Different versions of clients are also likely to affect fingerprints. Some clients even purposefully randomise elements of their handshake data.

You can use openssl to view the protocol messages passed between client and server during the TLS handshake:

$ echo -e 'GET /tls HTTP/1.1\r\nHost:localhost:4433\r\n\r\n' | openssl s_client -connect localhost:4433 -msg

Example usage with curl and jq

Get ja4 fingerprint only:

$ curl -s -k https://localhost:4433/tls | jq '.tls_fingerprints.ja4'
"t13d4213h2_171bc101b036_5f0018e59d20"

Get all fingerprints:

$ curl -s -k https://localhost:4433/tls | jq '.tls_fingerprints'
{
  "ja3_r": "771,4866-4867-4865-4868-49196-49200-52393-52392-49325-49195-49199-49324-49187-49191-49162-49172-49161-49171-157-49309-156-49308-61-60-53-47-163-159-52394-49311-162-158-49310-107-106-103-64-57-56-51-50-255,0-11-10-16-22-23-49-13-43-45-51-27-21,
