Xpo SyncFramework Docs

Documentation for SyncFramework. A set of XPO providers for database synchronization created by BitFrameworks and Xari

Xpo SyncFramework is a commercial product, you can get pricing information by contacting us at info@xari.io

Requirements

The official nuget feed from developer Express is required since all references comes from the nuget feed, more information here.

https://docs.devexpress.com/GeneralInformation/116042/installation/install-devexpress-controls-using-nuget-packages/obtain-your-nuget-feed-url

The official nuget feed from BitFrameworks is required. Use the following command line to add the repository

dotnet nuget add source https://nuget.bitframeworks.com/nuget/public/v3/index.json -n bitframeworks

Here you can find more information on how to add a nuget package source. https://docs.microsoft.com/en-us/dotnet/core/tools/dotnet-nuget-add-source

How to install the template

Install the template from a nuget file

dotnet new -i BitXari.XafSyncTemplate.21.1.3.29.nupkg

--or--

Install the template from a nuget feed

dotnet new -i BitXari.XafSyncTemplate::21.1.3.29

--or--

Install the template from a nuget feed

dotnet new -i BitXari.XafSyncTemplate::21.1.3.29 --nuget-source https://nuget.bitframeworks.com/nuget/public/v3/index.json

How to uninstall the template

dotnet new -u BitXari.XafSyncTemplate

More information about uninstalling templates here https://docs.microsoft.com/en-us/dotnet/core/tools/dotnet-new-uninstall

How to see template help information

dotnet new XafXamarinOfflineSync --help

How to create a new project

To create a new Xaf App (windows forms net 5 and blazor net 5) application with a SyncServer

dotnet new XafXamarinOfflineSync --name YourProjectName

To create a new Xaf App (windows forms net 5 and blazor net 5) application with a SyncServer and Android client

dotnet new XafXamarinOfflineSync --name YourProjectName --android

To create a new Xaf App (windows forms net 5 and blazor net 5) application with a SyncServer and iOs client

dotnet new XafXamarinOfflineSync --name YourProjectName --ios

To create a new Xaf App (windows forms net 5 and blazor net 5) application with a SyncServer and iOs and Android clients

dotnet new XafXamarinOfflineSync --ios --android --name YourProjectName

How to connect your emulators to the Sync Server running in your computer

There are many ways to connect your emulators to the sync server running in your computer, our preferred option is using Ngrok but you can also follow the official Microsoft documentation, all links below

Connect to local web services https://docs.microsoft.com/en-us/xamarin/cross-platform/deploy-test/connect-to-local-web-services

Ngrok exposes local servers behind NATs and firewalls to the public internet over secure tunnels. https://ngrok.com/

Use ngrok quickly and easily from within Visual Studio. ngrok allows you to expose a local server behind a NAT or firewall to the internet. "Demo without deploying." https://marketplace.visualstudio.com/items?itemName=DavidProthero.NgrokExtensions

How to upgrade nuget versions for your project

When you create a solution using this template you will get a build props file as the one in the link below

Build Props File

<Project>
	<PropertyGroup>
		<!--DevExpress version-->
		<DevExpressVersion>21.1.3</DevExpressVersion>
		<!--SyncFramework Version-->
		<SyncFrameworkVersion>21.1.3.29</SyncFrameworkVersion>
		<!--demo or licensed-->
		<NugetReferences>demo</NugetReferences>
		<!--Additional references-->
		<BITXpo>21.1.3.5841</BITXpo>
		<BITAspNetCore>21.1.3.5841</BITAspNetCore>
		<BITDataTransferRestClientNet>21.1.3.5841</BITDataTransferRestClientNet>
	</PropertyGroup>
</Project>

Using this file you can easily change the versions of your nuget packages

DevExpressVersion: set the version of devexpress references
SyncFrameworkVersion: set the version of the SyncFramework
NugetReferences: use demo to reference the trial version of the SyncFramework otherwise use licensed if you own the full version of the framework
BITXpo: Infrastructure needed for network communication https://github.com/egarim/BitFrameWorks/tree/master/src/Xpo/BIT.Data.Xpo
BITAspNetCore: Infrastructure needed for network communication https://github.com/egarim/BitFrameWorks/tree/master/src/Xpo/BIT.AspNetCore.Xpo
BITDataTransferRestClientNet: needed for network communication https://github.com/egarim/BitFrameWorks/tree/master/src/Core/BIT.Data.Functions.RestClientNet

Getting started: Create your first offline app with synchronization

If you are new using our SyncFramework solution follow this tutorial to create your first app

Getting Started

General recommendations

Databases

Don't share delta databases between applications

Android

Make sure that you provide an unique name for your application package in AndroidManifest Otherwise you might end up using an old database for your application and you will get exceptions when processing the deltas

Binary data

Avoid storing binary data on your database if it's possible, binary data (like FileData from XAF) may use a lot of space in the database, which might result in larger delta transactions. Large deltas take a longer time to synchronize and can drain your mobile device battery and data plan

Limitations

Auto generated integer primery keys:Avoid using XPObjects that uses an Integer key, integer auto-increment keys depends on the database engine internal infrastructure and they are not possible to replicate. It’s out of the scope of the SyncFramework

https://docs.devexpress.com/XPO/3311/create-a-data-model/xpo-classes-comparison
