OpenCV: Open Source Computer Vision Library

Videoio Module

• This Videoio Module can be supported for Opencv version 4.5.5 with both Linux and Windows OS.

APIs Introduced

• bool getDevices(int &devices);
• bool getDeviceInfo(int device, String &deviceName, String &vid, String &pid, String &devicePath);
• bool getFormats(int &formats);
• bool getFormatType(int format, String &formatType, int &width, int &height, int &fps);
• bool setFormatType(int format)
• bool get(int propId, int &min, int &max, int &steppingDelta, int &supportedMode, int &currentValue, int &currentMode, int &defaultValue);
• bool set(int propId, int value, int mode);

APIs Explanation

bool getDevices(int &devices);

• Get total number of camera devices connected to the port.

bool getDeviceInfo(int device, String &deviceName, String &vid, String &pid, String &devicePath);

• Get specific camera device information such Device name, Device path, VendorID and productID.

bool getFormats(int &formats);

• Get total number of video formats supported by the camera device.

bool getFormatType(int format, String &formatType, int &width, int &height, int &fps);

• Get video resolution, video format and fps supported by the camera

bool setFormatType(int format);

• Set the video format, resolution and fps to the device.

bool get(int propId, int &min, int &max, int &steppingDelta, int &supportedMode, int &currentValue, int &currentMode, int &defaultValue);

• Get specific UVC Property(Brightness, Contrast,...) minimum value, maximum value, current value, default value, steppingDelta, current mode and supported mode.

bool set(int propId, int value, int mode);

• Set specific UVC Property(Brightness, Contrast, Hue,...) value and mode.

Y8GrabberFilter

• The Y8GrabberFilter Transform Filter is to grab the Y8 Frames as SampleGrabber. The SampleGrabber Input Pin does not accept the Y8 Format.

PythonScript

• Python Script can be used to access the UVC settings, HID settings, Streaming and Image capture of any e-con System cameras in both Windows and Linux.

OpenCVCam Command Line Application

• OpenCVCam command line application can be used to access the UVC settings, HID settings, Streaming and Image capture of any e-con System cameras in both Windows and Linux.

How to Use

• OpenCV can be downloaded from here

	$ cd opencv

	$ git checkout <opencv version>

• Replace Videoio module from OpenCV with this videoio module
• Build OpenCV using this Installation manual
• Information on how to use those newly Introduced APIs were explained in API Documentation
• OpenCVCam command line application can be downloaded from here, which is used to access OpenCV APIs
• Run Sample application using this user manual

Supported Camera's

* See3CAM_CU20
* See3CAM_CU30
* Seecam_CU38
* See3CAM_CU130
* See3CAM_CU135
* See3CAM_10CUG
* See3CAM_11CUG
* See3CAM_12CUNIR
* See3CAM_30 (Liquid Lens)
* See3CAM_130 Autofocus
* See3CAM_CU55
* FSCAM_CU135
* See3CAM_CU55M
* See3CAM_20CUG
* See3CAM_CU22
* See3CAM_CU27
* See3CAM_160
* See3CAM_CU81
* e-cam82USB
* See3CAM_CU135M_H03R1
* See3CAM_CU135M_H01R1
* See3CAM_CU135M
* See3CAM_27CUG
* See3CAM_CU83
* See3CAM_50CUG_M
* See3CAM_16CUG_M
* See3CAM_CU512M
* See3CAM_50CUG
* e-cam512USB
* See3CAM_CU200
* See3CAM_CU200M
* See3CAM_CU200MH
* See3CAM_CU84
* See3CAM_CU31
* See3CAM_CU83_H03R1
* See3CAM_37CUGM

Releases

• Latest releases can be downloaded from this link

What's new

• Added Support for OpenCV 4.5.5

Release

• OpenCV v1.0.4 - 10-Oct-22
• OpenCV v1.0.3 - 15-Aug-20
• OpenCV v1.0.2 - 03-Jun-20
• OpenCV v1.0.1 - 17-Dec-19
• OpenCV v1.0.0 - 27-Jul-18
