csvmonkey

This is a header-only vectorized, lazy-decoding, zero-copy CSV file parser. Given appropriate input data and hardware, the C++ version can tokenize ~1.9 GiB/sec of input in one thread. For a basic summing task, the Python version is ~5x faster than csv.reader and ~10x faster than csv.DictReader, while maintaining a similarly usable interface.

This still requires a ton of work. For now it's mostly toy code.

Requires a CPU supporting Intel SSE4.2 and a C++11 compiler that bundles smmintrin.h. For non-SSE4.2 machines, a reasonable fallback implementation is also provided.

As of writing, csvmonkey comfortably leads <a href="https://bitbucket.org/ewanhiggs/csv-game">Ewan Higg's csv-game</a> microbenchmark of 24 CSV parsers.

How It Works

• Vectorized: scanning for values that change parser state is done using Intel SSE 4.2 PCMPISTRI instruction. PCMPISTRI can locate the first occurence of up to four values within a 16 byte vector, allowing searching 16 input bytes for end of line, escape, quote, or field separators in one instruction.

• Zero Copy: the user supplies the parser's input buffer. The output is an array of column offsets within a row, each flagged to indicate whether an escape character was detected. The highest throughput is achieved in combination with memory-mapped files, where none of the OS, application or parser make any bulk copies.

• Lazy Decoding: input is not copied or unquoted until requested. Since a flag indicates the presence of escapes, a fast path can avoid any bytewise decode in the usual case where no escape is present. Due to lazy decoding, csvmonkey is extremely effective at tasks that scan only a subset of data, for example one or two columns from a large many-columned CSV. This use case is the original motivation for the design.

• Header Only: the parser has no third-party dependencies, just some templates defined in csvmonkey.hpp.

Python Usage

You can install the library through pip:

pip install csvmonkey

If this fails on ubuntu, first install clang:

sudo apt-get install clang

Then run:

CC=clang pip install csvmonkey

You can also install the library locally by cloning this repo and running:

pip install -e .

Then you can use it likewise:

1. import csvmonkey
2. csvmonkey.from_path() for a memory-mapped file, csvmonkey.from_file() for any file-like object with a read() method, or csvmonkey.from_iter() for any iterable object that yields lines or file chunks, e.g. from_iter(open("ram.csv")).

By default a magical Row object is yielded during iteration. This object is only a window into the currently parsed data, and becomes invalid upon the next iteration. Row data is accessed either by index or by key (if header=True) using:

for row in csvmonkey.from_path("ram.csv", header=True):
    row[20]  # by index
    row["UnBlendedCost"]  # by header value

If your CSV contains a header, specify header=True to read it during construction. If the CSV lacks a header but dict-like behaviour is desired, pass a header explicitly as header=("a", "b", "c", "d").

Element access causes the relevant chunk of the row to be copied to the heap and returned as a Python string.

Rows may be converted to dicts via row.asdict(), tuples via row.astuple() or lists via row.aslist(). If you want rows to be produced directly in concrete form, pass yields="list", yields="tuple", yields="dict" keyword arguments.

Unicode

Unicode is supported for character sets where delimiters and line endings are represented by one byte. To configure Unicode, pass an encoding parameter, and optionally an errors parameter.

• "bytes": Return bytes (default on Python 2)
• "utf-8": Decode as UTF-8 (default on Python 3)
• "ascii": Decode as ASCII
• "latin1": Decode as LATIN1
• "locale": Decode according to the active C locale
• "...": Decode according some codec "..." known to Python

Where possible, prefer exact spelling and case matching one of the above encodings, to ensure an associated fast path is used.

Python Benchmark

ram.csv is 614MiB with 1,540,093 records of 22 columns and approximately 418 bytes per record. An anonymized version is checked into LFS as tests/data/anon-ram.csv.zstd.

Python 2.7 Sum: convert to float and sum single column:

| Mode | Rate | Ratio | i7-6700HQ | Xeon E5530 | Core i5-2435M | |--------------------------|------------|-------|-----------|------------|---------------| | csvmonkey lazy decode | 1098 MiB/s | - | 0.559s | 0.9s | 1.29s | | csvmonkey yields="tuple" | 642 MiB/s | 1.7x | 0.956s | 1.87s | 2.17s | | csvmonkey yields="dict" | 281 MiB/s | 3.8x | 2.18s | 4.57s | 5.04s | | csv.reader | 223 MiB/s | 4.9x | 2.75s | 5.88s | 11.1s | | csv.DictReader | 85 MiB/s | 12.7x | 7.15s | 16.3s | 25.0s |

Python 2.7 No-op: Iterate complete file, no other processing:

| Mode | Rate | Ratio | i7-6700HQ | Xeon E5530 | |--------------------------|------------|-------|-----------|------------| | csvmonkey lazy decode | 1906 MiB/s | - | 0.322s | 0.444s | | csvmonkey yields="tuple" | 831 MiB/s | 2.3x | 0.738s | 1.4s | | csvmonkey yields="dict" | 318 MiB/s | 6.0x | 1.93s | 4.26s | | csv.reader | 248 MiB/s | 7.6x | 2.47s | 5.31s | | csv.DictReader | 92 MiB/s | 20.5x | 6.62s | 15.2s |

Python 3.6 No-op: Iterate complete file, includes charset decoding

| Mode | Rate | Ratio | i7-6700HQ | |---------------------------------------------|------------|------------|------------| | csvmonkey lazy decode | 1906 MiB/s | - | 0.322s | | csvmonkey yields="tuple", encoding="bytes" | 833 MiB/s | 2.3x | 0.737s | | csvmonkey yields="tuple", encoding="latin1" | 579 MiB/s | 3.3x | 1.06s | | csvmonkey yields="tuple" | 495 MiB/s | 3.8x | 1.24s | | csvmonkey yields="dict" | 235 MiB/s | 8.1x | 2.61s | | csv.reader | 121 MiB/s | 15.7x | 5.07s | | csv.DictReader | 55 MiB/s | 34.4x | 11.1s |

Command lines

Sum:

python -mtimeit -n1 -r3 -s 'import csvmonkey' 'sum(float(row["UnBlendedCost"]) for row in csvmonkey.from_path("ram.csv", header=True))'
python -mtimeit -n1 -r3 -s 'import csvmonkey' 'sum(float(row[20]) for row in csvmonkey.from_path("ram.csv", header=True, yields="tuple"))'
python -mtimeit -n1 -r3 -s 'import csvmonkey' 'sum(float(row["UnBlendedCost"]) for row in csvmonkey.from_path("ram.csv", header=True, yields="dict"))'
python -mtimeit -n1 -r3 -s 'import csv' 'r = csv.reader(open("ram.csv")); next(r); sum(float(row[20]) for row in r)'
python -mtimeit -n1 -r3 -s 'import csv' 'sum(float(row["UnBlendedCost"]) for row in csv.DictReader(open("ram.csv")))'

No-op:

python -mtimeit -n1 -r3 -s 'import csvmonkey' 'all(csvmonkey.from_path("ram.csv", header=True))'
python -mtimeit -n1 -r3 -s 'import csvmonkey' 'all(csvmonkey.from_path("ram.csv", header=True, yields="tuple"))'
python -mtimeit -n1 -r3 -s 'import csvmonkey' 'all(csvmonkey.from_path("ram.csv", header=True, yields="dict"))'
python -mtimeit -n1 -r3 -s 'import csv' 'all(csv.reader(open("ram.csv")))'
python -mtimeit -n1 -r3 -s 'import csv' 'all(csv.DictReader(open("ram.csv")))'

C++ Usage

1. Copy csvmonkey.hpp to your project and include it.
2. CFLAGS=-msse4.2 -O3
3. See Makefile for an example of producing a profile-guided build (worth an extra few %).
4. Instantiate MappedFileCursor (zero copy) or FdStreamCursor (buffered), attach it to a CsvReader.
5. Invoke read_row() and use row().by_value() to pick out CsvCell pointers for your desired columns.
6. Pump read_row() in a loop and use cell's ptr(), size(), as_str(), equals() and as_double() methods while read_row() returns true.

TODO

• COW pointer interface to as_str().
• ~~Finish Python 3 support~~
• ~~Ensure Python ReaderObject is always 16-byte aligned~~
• Fix handling of last row when it:
  • lacks newline, or
  • is truncated after final quote, or
  • is truncated within a quote, or
  • is truncated within an escape
• Restartable: fix quadratic behaviour when StreamCursor yields lines and CSV rows span lines
• ~~Python from_file() that uses read() in preference to __iter__().~~
• ~~Fix CRLF / LFCR handling.~~
• ~~StreamCursor error / exception propagation.~~
• ~~Remove hard 256 column limit & fix crash if it's exceeded.~~
• ~~Ensure non-SSE fallback return codes match SSE when not found.~~
• ~~Map single zero page after file pages in MappedFileCursor~~
• ~~Add trailing 16 NUL bytes to BufferedStreamCursor~~
• ~~Remove hard-coded page size~~
• ~~(Single byte separator) Unicode support.~~
• (Multi byte separator) Unicode support.
