NEWS 2019-Feb-23 - video!
Explaining software v55 video released on youtube:

--> watch

chainhammer v59

TPS measurements of parity aura, geth clique, quorum, tobalaba, etc. It should work with any Ethereum type chain; we focused on PoA consensus.

instructions

video

The brand new release v55 is now presented & explained in a useful video on youtube.

folders

hammer/ - submits many transactions, while watching the recent blocks
reader/ - reads blocks; visualizes TPS, blocktime, gas, bytes - see reader/README.md
docs/ - see esp. reproduce.md, cloud.md, FAQ.md, new: azure.md
results/ - for each client one markdown file; results/runs/ - auto-generated pages
logs/ - check this first if problems
networks/ - network starters & external repos via install script, see below
scripts/ - installers and other iseful bash scripts
env/ - Python virtualenv, created via install script, see below
tests/ - start whole integration test suite via ./pytest.sh

chronology

See the results/ folder:

log.md: initial steps; also tried Quorum's private transactions
quorum.md: raft consensus, quorum is a geth fork
tobalaba.md: parity fork of EnergyWebFoundation
quorum-IBFT.md: IstanbulBFT, 2nd consensus algo in quorum
geth.md: geth clique PoA algorithm
parity.md: parity aura PoA algorithm, many attempts to accelerate
eos.md: not begun yet
substrate.md: not begun yet

results summary

Outdated table in which I had run each of the experiments manually in autumn 2018; soon re-done completely, using the below automation. So please contact me now, if you know how to accelerate any of these clients:

| hardware | node type |----------- |----------- | t2.micro | parity aura | 4 | t2.large | parity aura | 4 | t2.xlarge | parity aura | 4 | t2.2xlarge | parity aura | 4 | | | t2.micro | parity instantseal | 1 | t2.xlarge | parity instantseal | 1 | | | t2.2xlarge | geth clique | t2.xlarge | geth clique | t2.xlarge | geth clique | 3+1 | t2.large | geth clique | t2.small | geth clique | t2.micro | geth clique | 3+1 | | | t2.micro SWAP | quorum crux IBFT | 4 | | | t2.micro | quorum crux IBFT | 4 | t2.large | quorum crux IBFT | 4 | t2.xlarge | quorum crux IBFT | 4 | t2.xlarge | quorum crux IBFT | 4 | t2.2xlarge | quorum crux IBFT | 4 | c5.4xlarge | quorum crux IBFT | 4 | #nodes | config | peak TPS_av | final TPS_av | |-------- |-------- |------------- |-------------- | | (D) | 45.5 | 44.3 | | (D) | 53.5 | 52.9 | | (J) | 57.1 | 56.4 | | (D) | 57.6 | 57.6 | | | | | | | (G) | 42.3 | 42.3 | | (J) | 48.1 | 48.1 | | | | | | | 3+1 +2 | (B) | 421.6 | 400.0 | | 3+1 +2 | (B) | 386.1 | 321.5 | | (K) | 372.6 | 325.3 | | 3+1 +2 | (B) | 170.7 | 169.4 | | 3+1 +2 | (B) | 96.8 | 96.5 | | (H) | 124.3 | 122.4 | | | | | | | (I) SWAP! | 98.1 | 98.1 | | | | | | | (F) | lack of RAM | | | (F) | 207.7 | 199.9 | | (F) | 439.5 | 395.7 | | (L) | 389.1 | 338.9 | | (F) | 435.4 | 423.1 | | (F) test_getNearestEntry() | 536.4 | 524.3 |

Reproduce these results easily; for the config column also see there. Quickest reproduction with my Amazon AMI readymade image. And see that bottom of parity.md and geth.md and quorum-IBFT.md for the latest runs, issues, and additional details.

faster wider more

how I initially got this faster, on Quorum, step by step, please do read the 1st logbook log.md
then I improved per client, see each in #chronology above
(possible TODOs - any other ideas?)

but not much more needed = the current version is already fully automated. Use it! May it help you to improve the speed of your Ethereum client!

you

Add yourself to other-projects.md using chainhammer, or projects which are similar to this.

(Especially if you work in one of the dev teams, you know your client code best - ) please try to improve the above results, e.g. by varying the CLI arguments with which the nodes are started; I don't see that as my job, you will be much more successful with that.

See parity PE#9393, parity SE#58521, geth GE#17447, quorum Q#479.

Please report back when you have done other / new measurements.

install and run

All this is developed and much tested on Debian, locally and in the AWS cloud. New: Ubuntu now also supported, see below.

quickstart

N.B.: Better do this on a disposable cloud, or virtualbox machine; because the installation makes lasting changes and needs sudo!

After unpacking a ZIP of the downloaded repo, or by

git clone https://github.com/drandreaskrueger/chainhammer drandreaskrueger_chainhammer
ln -s drandreaskrueger_chainhammer CH
cd CH

you now only need these two lines to prepare and run the 1st experiment!

scripts/install.sh
CH_TXS=1000 CH_THREADING="sequential" ./run.sh $HOSTNAME-TestRPC testrpc

You will then have a diagram, and a HTML and MD page about this run!

(on Ubuntu instead: scripts/install.sh docker ubuntu )

activate docker

Better now logout & login, or close the terminal, and open a new terminal, because the above scripts/install.sh might have enabled docker for the the first time for this user. Then:

All supported clients in one go:

For the full integration test, run each client for a short moment:

export CH_MACHINE=yourChoice
./run-all_small.sh

For detailed instructions, please see docs/, esp. reproduce.md, and for troubleshooting FAQ.md and github issues.

benchmarking a remote node

Chainhammer can now be stripped down to its pure benchmarking abilities, i.e. without the installation of docker and without the three local network starters (parity-deploy, geth-dev, quorum-crux). It was successfully used to benchmark the Microsoft Azure blockchain-as-a-service product. The essential difference is to start the installation with the switch nodocker:

scripts/install.sh nodocker

So, if you just want to benchmark your existing Ethereum node or network, have a look at the manual docs/azure.md .

unittests

./pytest.sh

enables the virtualenv, then starts a testrpc-py Ethereum simulator on http://localhost:8545 in the background, logging into tests/logs/; then runs ./deploy.py andtests; and finally runs all the unittests, also logging into tests/logs/.

(Instead of testrpc-py) if you want to run tests with another node, just start that; and run pytest manually:

source env/bin/activate
py.test -v --cov

There were 98 tests on January 23rd, all 98 PASSED (see this logfile --> cat tests/logs/*.ansi because colors) on these different Ethereum providers:

testrpc instantseal (testrpc-py) 13 seconds
geth Clique (geth-dev) 63 seconds
quorum IBFT (blk-io/crux) 59 seconds
parity instantseal (parity-deploy) 8 seconds
parity aura (parity-deploy) 72 seconds

credits

Please credit this as:

benchmarking scripts "chainhammer"
maintainer: Dr Andreas Krueger 2018-2020
https://github.com/drandreaskrueger/chainhammer

Consider to submit your improvements & usage as pull request. Thanks.

development was supported by

v01-v35 financed by Electron.org.uk 2018
v40-v55 financed by Web3Foundation 2018-2019
v58-v59 financed by Microsoft Azure 2019

logo

Thank you very much!

short summary

The open source tools 'chainhammer' submits a high load of smart contract transactions to an Ethereum based blockchain, then 'chainreader' reads the whole chain, and produces diagrams of TPS, blocktime, gasUsed and gasLimit, and the blocksize. https://github.com/drandreaskrueger/chainhammer

# The following diagrams are outdated! Just make your own, new ones, with:
CH_MACHINE=yourChoice ./run-all_large.sh

chainhammer: hammer --> reader --> diagrams

examples:

geth clique on AWS t2.xlarge

geth.md = geth (go ethereum client), "Clique" consensus.

50,000 transactions to an Amazon t2.xlarge machine.

Interesting artifact that after ~14k transactions, the speed drops consid
