Introduction

Jmspy is a java library that allows recording of java methods invocations, saving data into a file called snapshot and analyzing it using jmspy viewer. The library uses CGLib to create proxies and graph data structure representing method invocations. It supports any number of nested call structures, e.g.:

object.getCollection().iterator().next().getProperty()

Jmspy is aware of the most used collection types like list, set and map, including unmodifiable collections from jdk and empty collections.

Jmspy-core

The components which form the basic API are:

MethodInvocationRecorder - the main class which the user interacts with. ProxyFactory - a factory to create proxies for objects ContextExplorer - an interface that’s used to provide additional information about invocation context.

Here are some more details on them.

ProxyFactory

This factory allows creating proxies for client objects. There is an ability to configure the factory before using it, which can be useful if you deal with complex objects and you need some workarounds to create proxies. ProxyFactory is a singleton, i.e. you can initialize it only once using ProxyFactory#getInstance(Configuration config) and pass an instance of Configuration. Example:

Configuration.Builder builder = Configuration.builder()
                .ignoreType(DataLoader.class) // objects with type DataLoader for which no proxy should be created
                .ignoreType(java.util.logging.Logger.class) // ignore objects with type DataLoader
                .ignorePackage("com.mongodb");  // ignore objects with types exist in specified package
ProxyFactory proxyFactory = ProxyFactory.getInstance(builder.build());

ContextExplorer

This is an interface which provides more information on the invocation context. Jmspy has some built-in implementations, for instance FreemarkerContextExplorer from jmspy-ext-freemarker. This implementation allows retrieving information on request url and FTL page. You can register only one ContextExplorer per MethodInvocationRecorder. The ContextExplorer interface has two methods:

• getRootContextInfo - gets info about the root invocation context, such as application name, request url and etc. This method is invoked as soon as an invocation record is created via the MethodInvocationRecorder#record(java.lang.reflect.Method, Object)} method.
• getCurrentContextInfo - gets info about current invocation context such as page name and etc. This method is invoked as soon as a method of proxy object is intercepted.

MethodInvocationRecorder

This is the main class with which the user must interact. This class has several constructors with an ability to pass the ProxyFactory and the ContextExplorer. It also has a default constructor, which yields a default configuration of ProxyFactory, but no default implementation for ContextExplorer is used. Thus, all three variants described below are correct:

• (1) java new MethodInvocationRecorder();
• (2) java new MethodInvocationRecorder(ProxyFactory.getInstance(Configuration.builder().build()));
• (3) see the code below

MethodInvocationRecorder methodInvocationRecorder = new MethodInvocationRecorder(new ContextExplorer() {
            @Override
            public InvocationContextInfo getRootContextInfo() {
                return null;
            }

            @Override
            public InvocationContextInfo getCurrentContextInfo() {
                return null;
            }
        });

• (4) = 2+3

Restrictions

Jmspy uses CGLIB lib to create proxies and there are several restrictions that come from CGLIB nature. CGLIB uses inheritance when it creates dynamic proxy. Thus, each proxy belongs to a generated instrumented class that extends original type by including interfaces. Java has several restrictions with class inheritance, namely:

• Final class cannot be extended
• Final methods cannot be overridden

Also CGLIB can't create proxies for nested classes that have default/package modifier and loaded using bootstrap class loader, for example the classes from core Java libraries located in the <JAVA_HOME>/jre/lib directory, for instance Collections#UnmodifiableList.class. All this issues are partially resolved in jmspy-core, for example the restrictions with final classes or classes from java core libraries can be resolved using feature called Wrapper. If JMSpy fails to create proxy for a class then it will automatically try to create a wrapper for target class and create proxy for wrapper instead of target class. This approach works fine if you have an interface for a class and you work with this interface instead of concrete implementation. For example:

Interface

public interface IFinalClass {
    String getId();
}

Class

public final class FinalClass implements IFinalClass {

    private String id;

    public String getId() {
        return id;
    }

    public void setId(String id) {
        this.id = id;
    }
}

App class:

public static void main(String[] args) {
        MethodInvocationRecorder invocationRecorder = new MethodInvocationRecorder();
        IFinalClass finalClass = new FinalClass();
        IFinalClass proxy = invocationRecorder.record(finalClass);
        System.out.println(isCglibProxy(proxy));
    }

Although the FinalClass is final class the result is true

Also you can register your own wrapper for FinalClass if you want, example:

public class FinalClassWrapper implements IFinalClass, Wrapper<IFinalClass> {

    private IFinalClass target;

    public FinalClassWrapper() {
    // default constructor
    }

    @Override
    public void setTarget(IFinalClass target) {
        this.target = target;
    }

    @Override
    public IFinalClass getTarget() {
        return target;
    }

    @Override
    public Class<? extends Wrapper<IFinalClass>> getType() {
        return FinalClassWrapper.class;
    }

    @Override
    public String getId() {
        return "wrapper: " + target.getId();
    }
}

Now you need to register this wrapper:

    public static void main(String[] args) {
        Configuration conf = Configuration.builder()
                .registerWrapper(FinalClass.class, FinalClassWrapper.class) //register our wrapper
                .build();
        ProxyFactory proxyFactory = ProxyFactory.getInstance(conf);
        MethodInvocationRecorder invocationRecorder = new MethodInvocationRecorder(proxyFactory);
        IFinalClass finalClass = new FinalClass();  // change class FinalClass to interface IFinalClass
        IFinalClass proxy = invocationRecorder.record(finalClass); // change class FinalClass to interface IFinalClass
        System.out.println(isCglibProxy(proxy));
        System.out.println(proxy.getId());
    }

Now execution result is:

true
wrapper: 1

As you can see, jmspy managed to create the proxy.

NOTICE: The wrapper implementation FinalClassWrapper has default constructor, it isn't required but desirable. You can register a wrapper for an interface but in this case a proxies for all classes that implement this interface will be created using registered wrapper. If you want have different wrappers for different implementations then you need to register a wrapper for a class rather than an interface.

Issues with final methods also can be solved using the Wrapper approach, but what if you don’t have an interface for the FinalClass.class? You can’t extend it hence the decorator pattern wouldn’t work here. In this case you need to use Jmspy-agent

Jmspy-agent

It’s a java agent that uses asm library to transform classes, which solves the issues with final classes, methods and absent constructors. You just need to specify the jmspy-agent at your application startup via the appropriate command line parameter for JVM. You can pass an argument to the agent to indicate which classes or packages should be instrumented. It considers whole string after '=' as a single parameter. Basically, you have two variants to pass the parameter:

1. using javaagent parameter example:

-javaagent:{path_to_jar}/jmspy-agent-x.y.z.jar=com.github.dmgcodevil.jmspy.example.Candidate.class,com.github.dmgcodevil.jmspy.test.data

2. usning property file: jmspy_agent.properties The property file should be placed at the top level of your project, for example: 'src/main/resources/jmspy_agent.properties' or ‘src/test/resources/jmspy_agent.properties' The exact property name is "instrumentedResources", for instance: instrumentedResources=com.github.dmgcodevil.jmspy.example.Candidate.class Arguments allow specifying concrete classes that should be instrumented or whole packages. The agent expects the argument as a string of the following format: [ {canonicalClassName}.class, {package}, {canonicalClassName}.class, ... ] Thus, it's possible to specify classes or packages as required.

There are several significant points to mention:

1. If agentArgs/property file weren't specified (nonexistent property file or empty string), then all classes will be transformed.
2. Classes and packages must be separated by the ',' symbol.
3. A class name must end with '.class' suffix, otherwise it will be considered as a package name.

In some cases the preferable option is to use package names in the agentArgs instead of specifying concrete class names, unless you know the exact class name at runtime. This is because of the possibility that nested or anonymous classes with names like com/site/project/URLClassPath$FileLoader$1 will not be transformed, if you specify an incorrect name. In this case it’s better to specify a package name like com.site.project

How to integrate JMSp
