Deepdrive

The easiest way to experiment with self-driving AI

Simulator requirements

• Linux
• Python 3.6+
• 10GB disk space
• 8GB RAM

Optional - baseline agent requirements

• CUDA capable GPU (tested and developed on 970, 1070, and 1060's)
• 1.7 <= Tensorflow < 2.0 See Tensorflow install tips

Install

1. Create a Miniconda env

2. Clone

git clone https://github.com/deepdrive/deepdrive
cd deepdrive

Optional - Activate the Python conda env or virtualenv with Tensorflow installed, then

Note: If you use Anaconda (we recommend Miniconda) - only use pip install in your deepdrive conda environment, never conda install

3. Install

python install.py  # Do not run as sudo! Use Miniconda or virtualenv to install without sudo.

Cloud

Cloud setup instructions

Examples

Forward-agent

python example.py

Synchronous forward-agent

python example_sync.py

• Remote agent example - operates over the network using the deepdrive remote api

Mnet2 baseline agent

python main.py --mnet2-baseline --experiment my-baseline-test

Built-in C++ FSM / PID agent that can overtake in the canyons map

python main.py --path-follower --experiment my-path-follower-test

Record training data for imitation learning / behavioral cloning

python main.py --record --jitter-actions --sync

Note that we recorded the baseline dataset in sync mode which is much slower than async mode. Async mode probably is fine to record in, we just haven't got around to trying it out for v3.

Optional: Convert to HDF5 files to tfrecords (for training MNET2)

python main.py --hdf5-2-tfrecord

Train on recorded data

python main.py --train [--agent dagger|dagger_mobilenet_v2|bootstrapped_ppo2] --recording-dir <your-hdf5-or-tfrecord-dir>

Train on our dataset

Grab the dataset

python main.py --train --recording-dir <the-directory-with-the-dataset> [--agent dagger|dagger_mobilenet_v2|bootstrapped_ppo2]

Tensorboard

tensorboard --logdir="<your-deepdrive-home>/tensorflow"

Where <your-deepdrive-home> below is by default in $HOME/Deepdrive and can be configured in $HOME/.deepdrive/deepdrive_dir

Running unit tests

pytest tests/unit_tests/test_sanity.py

Key binds

• <kbd>Esc</kbd> - Pause (Quit in Unreal Editor)
• <kbd>Enter</kbd> - Pause with no menu
• <kbd>P</kbd> - Pause in Unreal Editor
• <kbd>1</kbd> - Chase cam
• <kbd>2</kbd> - Orbit (side) cam
• <kbd>3</kbd> - Hood cam
• <kbd>4</kbd> - Free cam (use WASD to fly)
• <kbd>Space</kbd> - Handbrake
• <kbd>Alt+Tab</kbd> - Control other windows / Show mouse
• <kbd></kbd> - Unreal console - do things like stat FPS`
• <kbd>M</kbd> - Drive the car with the keyboard WASD - be sure sync is off - Also known issue: Only works in path-follower mode right now
• <kbd>Ctrl-number</kbd> - Change sun position - works for 1 => 7
• <kbd>B</kbd> - Show vehicle bounding boxes
• <kbd>N</kbd> - Show vehicle collision boxes
• <kbd>Page Up</kbd> - Next vehicle
• <kbd>Page Down</kbd> - Prev vehicle

Observation data

All values returned in the observation keep Unreal conventions, specifically

• All distances are in centimeters per Unreal's default data type
• All rotations / angular values are in the order of roll, pitch, yaw in degrees
• x,y,z is forward, right, up

{

  'acceleration': array([-264.26913452, -227.578125  ,  105.16122437]),
  'angular_acceleration': array([210980.234375, 105423.765625,  38187.28125 ]),
  'angular_velocity': array([2.59908962, 3.8214705 , 1.87282801]),
  'brake': 0.0,
  'camera_count': 1,
  'cameras': [{  'aspect_ratio': 1.0,
                 'capture_height': 227,
                 'capture_width': 227,
                 'depth_data': array([0.9995  , 0.9995  , 0.9995  , ...,
                     0.005146, 0.005146, 0.005146], dtype=float16),
                 'horizontal_field_of_view': 1.7654,
                 'id': 1,
                 'image': array([[[ 40.,  78., 110.] ..., dtype=float32),
                 'image_data': array([0.283  , 0.557  , 0.82,
                     ..., 0.02321, 0.02574, 0.02599], dtype=float16),
                 'image_raw': array([[[144, 195, 233]..., dtype=uint8),
                 'type': 0
              }],
  'capture_timestamp': 4132.511303506,
  'dimension': array([514.99609375, 514.99609375,  91.1796875 ]),  # Vehicle dimensions
  'distance_along_route': 70658.828125,  # centimeters of progress made along route to destination
  'distance_to_center_of_lane': 1038.8463134765625,  # centimeters to center of lane
  'world': { 'vehicle_positions': [ [ -15800.8193359375,
                                      38030.23828125,
                                      19894.62890625],
                                    [ -13854.9384765625,
                                      39296.91015625,
                                      20041.6484375],
                                    [ -10323.2744140625,
                                      39767.69921875,
                                      20409.265625],
                                    [ -6528.05810546875,
                                      38875.75390625,
                                      21034.83984375],
                                    [ 4577.29150390625,
                                      36155.37890625,
                                      22704.166015625]]},
  'distance_to_next_agent': 326125.625, # Next agent in our lane
  'distance_to_next_opposing_agent': -1.0,  # Next agent in opposite lane
  'distance_to_prev_agent': 30758.2734375,   # Next agent in our lane
  'forward_vector': array([-0.8840133 , -0.4375411 , -0.16455328]),
  'gym_action': [0, 1, 0, 0, True],
  'gym_done': False,
  'gym_reward': -2.4653405387152016,
  'handbrake': 0,
  'is_game_driving': 0,
  'is_passing': 0,
  'is_resetting': 205,
  'lap_number': 0,
  'last_collision': { 'collidee_velocity': array([0., 0., 0.]),
                      'collision_location': 'rear_right_fender',
                      'collision_normal': array([0., 0., 0.]),
                      'time_since_last_collision': 0.0,
                      'time_stamp': 4105.741911045,
                      'time_utc': 1562958070},
  'position': array([-10163.55371094,  17115.17382812,  22500.29492188]),
  'right_vector': array([-0.8840133 , -0.4375411 , -0.16455328]),
  'rotation': array([ 0.10010731, -0.16530512, -2.68199444]),
  'route_length': 273551.21875,
  'episode_return': { 'avg_kph': 0,
             'closest_vehicle_cm': 15812.662932649602,
             'closest_vehicle_cm_while_at_least_4kph': 15812.662932649602,
             'cm_along_route': 18730.72265625,
             'collided_with_vehicle': False,
             'collided_with_non_actor': True,
             'end_time': '1969-12-31T16:00:00-08:00',
             'episode_time': 11.5,
             'gforce_penalty': 90.68476390028613,
             'got_stuck': False,
             'lane_deviation_penalty': 255.7695629358121,
             'max_gforce': 0.8785649610557551,
             'max_kph': 138.7572978515625,
             'max_lane_deviation_cm': 1038.8463134765625,
             'num_steps': 0,
             'prev_progress_pct': 6.70844576752594,
             'progress_pct': 6.8472451856879175,
             'progress_reward': 0.0,
             'route_length_cm': 273551.21875,
             'speed_reward': 371.6081579415893,
             'start_time': '2019-07-12T12:00:59.003417-07:00',
             'time_penalty': 0.0,
             'total': 25.15383110549117,
             'wrong_way': False},
  'speed': 3854.369384765625,
  'steering': 0.0,
  'throttle': 1.0,
  'up_vector': array([-0.8840133 , -0.4375411 , -0.16455328]),
  'velocity': array([-3404.32958984, -1700.12841797,  -613.90289307]),
  'view_mode': 'normal',
}

Additional observation data can be exposed without compiling C++ or Blueprints by accessing the Unreal API with UnrealEnginePython.

Benchmark

Agents are automatically graded via Botleague

Dataset

100GB (8.2 hours of driving) of camera, depth, steering, throttle, and brake of an 'oracle' path following agent. We rotate between three different cameras: normal, wide, and semi-truck - with random camera intrisic/extrinsic perturbations at the beginning of each episode (lap). This boosted performance on the benchmark by 3x. We also use DAgger to collect course correction data as in previous versions of Deepdrive.

1. Get the AWS CLI
2. Ensure you have 104GB of free space
3. Download our dataset of mixed Windows (Unreal PIE + Unreal packaged) and Linux + variable camera and corrective action recordings (generated with --record)

cd <the-directory-you-want>
aws s3 sync s3://deepdrive/data/baseline_tfrecords .

or for the legacy HDF5 files for training AlexNet

aws s3 sync s3://deepdrive/data/baseline .

If you'd like to check out our Tensorboard training session, you can download the 1GB tfevents files here, unzip, and run

tensorboard --logdir <your-unzipped-dir>

and checkout [this view](htt
