Kilij

A ~25,000-line C++17 code obfuscation framework for LLVM 20. Twelve composable IR-level transforms and a custom bytecode virtual machine, usable as a drop-in Clang pass plugin (Kilij.{so|dll}) or baked into a full toolchain build.

The centerpiece is the VM: it translates function bodies into a custom ISA (17 opcodes, 8 type kinds, register-file model), emits bytecode, and generates a per-module interpreter entirely in LLVM IR. Three encoding layers (affine, MBA, Feistel) and layout hardening make the bytecode non-trivial to lift back.

Platform support

| Platform | Status | Notes | |---|---|---| | Windows x86_64 | Full support | All 12 transforms + VM; IAT obfuscation and extern hiding are Windows-only; prebuilt binaries available | | Linux x86_64 | Builds, untested | All 12 transforms + VM; no prebuilt binaries yet; behavior not guaranteed | | Windows ARM64 | Partial | IAT obfuscation disabled (x64 PEB walk) | | Other | Untested | Core IR passes are target-independent; VM/IAT may need porting |

Comparison

| Feature | O-LLVM | Hikari | Pluto | Polaris | Kilij | |---------|:------:|:------:|:-----:|:-------:|:-----:| | Flattening | Y | Y | Y | Y | Y | | Bogus CFG | Y | Y | Y | Y | Y | | Substitution | Y | Y | Y | Y | Y | | MBA | Partial | | Y | Y | Y | | String encryption | | Y | Y | Y | Y | | Split blocks | Y | Y | Y | | Y | | Constant encryption | | | Y | Partial | Y | | Indirect branches | | Y | | Y | Y | | Indirect calls | | Y | Y | Y | Y | | Opaque predicates | | | | | Y | | VM virtualization | | | | | Y | | IAT obfuscation | | | | | Y | | LLVM version | 4 | 8 | 14 | 16 | 20 |

Y = supported, Partial = limited

What it looks like

main() from the showcase binary at four levels, decompiled in IDA:

| Unobfuscated | Passes only | |:---:|:---:| | | |

| Passes + VM (vm-select=all) | VM dispatch loop | |:---:|:---:| | | |

Architecture

Plugin.cpp                     pass registration (OptimizerLastEPCallback)
 |
 +-- VM/                       bytecode virtual machine (~15k lines)
 |    +-- VMPass.cpp            entry point, function selection
 |    +-- VMIR.cpp              VM IR types, printing, and helpers
 |    +-- VMBytecode.cpp        VM IR -> bytecode emission
 |    +-- VMInterpreter.cpp     VM IR executor for differential testing
 |    +-- VMEncode.cpp          affine / MBA / Feistel encoding
 |    +-- VMEmitInterp.cpp      opcode-mode interpreter (~3,800 lines)
 |    +-- VMEmitRegion.cpp      region-mode emission
 |    +-- VMLowering.cpp        LLVM IR -> VM IR lowering
 |    +-- VMRegionFormation.cpp region selection
 |
 +-- Flattening.cpp            switch-based CFG dispatch (Feistel-encoded)
 +-- BogusControlFlow.cpp      opaque conditional branches + junk clones
 +-- SplitBasicBlock.cpp       basic block fragmentation
 +-- MBAObfuscation.cpp        mixed boolean-arithmetic rewrites
 +-- Substitution.cpp          arithmetic replacement with canceling constants
 +-- IndirectBranch.cpp        XOR-encoded branch/call tables, split keys, decoys
 +-- StringObfuscation.cpp     XOR-shift stream cipher, FNV-1a verify, atomic CAS
 +-- ConstObfuscation.cpp      volatile global key + rotate XOR
 +-- OpaquePredicates.cpp      7 families: DiffSquares, XorEq, Powmod, Collatz, MinorQuadric, QSeries, Composite
 +-- IATObfuscation.cpp        PEB walk + export scan (Windows x64)
 +-- CryptoUtils.cpp           AES-CTR PRNG, FNV-1a, modular inverse
 +-- Utils.cpp                 annotations, skip logic, growth budgets

Docs

• Getting started
• Building from source
• All flags and passes
• VM architecture and modes
• Detailed build instructions
• Troubleshooting
• Contributing

Features

Control flow (4 passes): flattening, bogus control flow, block splitting, indirect branches

Data flow (4 passes): MBA, substitution, constant encryption, string encryption

Call/import obfuscation (3 passes): indirect calls (table + split-key + decoys), IAT obfuscation (thunk or PEB-resolver backend), extern hiding

Opaque predicates (7 families): DiffSquares (algebraic identity), XorEq, Powmod (Fermat's Little Theorem), Collatz (bounded conjecture), MinorQuadric, QSeries, Composite -- salted with readcyclecounter + FNV

VM virtualization: custom ISA, three execution modes (opcode / basic-block / region), three encoding layers (affine / MBA / Feistel), bytecode layout hardening (shuffled fields, randomized stride, rotated+XOR'd 8-bit fields), encoded PC, indirect dispatch, bogus handlers, per-module state shuffling

Prerequisites

• CMake >= 3.20
• Ninja (recommended) or Make
• LLVM 20 development headers (only for standalone plugin builds)
• Python 3 (for running tests only)

Windows toolchain builds also require Visual Studio Build Tools with MSVC x64.

Getting started

All flags are passed as -mllvm -<flag>. Full list: docs/PASSES.md (or clang -mllvm -help).

Quick start with prebuilt toolchain

Download kilij-clang20-win64.zip from GitHub Releases and extract it. Linux binaries are not yet available; build from source instead (see below).

The zip contains:

kilij-clang20-win64/
  bin/            clang.exe, opt.exe, Kilij.dll, lld-link.exe, llvm-as/dis/objdump
  lib/            runtime libraries
  examples/       smoke test inputs (_tmp_kilij_smoke.c, .ll)
  quickstart/     verification scripts

Run the showcase script to build and run a small C++ program at four obfuscation levels (unobfuscated, passes-only, VM-only, full). Requires Visual Studio Build Tools for MSVC headers/libs:

quickstart\build_showcase_exe.bat

This produces four executables under quickstart\out\showcase\ and runs each one to confirm correctness. To verify the lower-level toolchain pieces individually:

quickstart\run_clang_obf_ir.bat    &REM clang with obfuscation flags
quickstart\run_opt_plugin.bat      &REM opt loading Kilij.dll

Then use the extracted clang directly on your own code:

bin\clang.exe -O2 foo.cpp -o foo.exe -mllvm -fla -mllvm -bcf

-fpass-plugin is not needed -- passes are linked into this clang.

Build the plugin (recommended for development)

Build the standalone out-of-tree pass plugin against an existing LLVM 20 installation. This is the fastest way to iterate on the passes.

cmake -S . -B build -G Ninja \
  -DLLVM_DIR=/path/to/llvm/lib/cmake/llvm
ninja -C build Kilij

This produces Kilij.so (Linux) or Kilij.dll (Windows). Use it with any LLVM 20 clang:

clang++ -O2 foo.cpp -o foo \
  -fpass-plugin=./build/lib/Kilij.so \
  -mllvm -fla -mllvm -bcf

Or via opt (IR in / IR out):

opt -load-pass-plugin=./build/lib/Kilij.so \
  -passes='fla,bcf' \
  -S in.ll -o out.ll

Windows note: the standalone Kilij.dll is built to import symbols from the included opt.exe (static plugin model). Use it via opt -load-pass-plugin=... or use the prebuilt clang (passes baked in).

Build complete toolchain from source

Build a full clang/opt/lld toolchain with Kilij baked in. The release scripts clone LLVM 20.1.0, copy Kilij into the tree, apply patches, and build everything.

Linux:

bash release/build_linux.sh

Windows (from a PowerShell prompt):

powershell -ExecutionPolicy Bypass -File release\build_windows.ps1

The scripts produce a packaged release archive under _release_out/. You can customize the LLVM source directory, build directory, and job count via environment variables (Linux) or parameters (Windows). See docs/BUILDING.md for full details.

Verify it works

After building, run a quick smoke test to confirm the plugin loads and transforms code:

# Write a minimal test file
echo 'int foo(int x) { return x * 2 + 1; }' > /tmp/test.c

# Run with flattening enabled (standalone plugin)
clang -O2 -fpass-plugin=./build/lib/Kilij.so \
  -mllvm -fla -c /tmp/test.c -o /tmp/test.o

# Or with the full toolchain build
./bin/clang -O2 -mllvm -fla -c /tmp/test.c -o /tmp/test.o

If it compiles without errors, the plugin is working. Add -mllvm -obf-verify for extra safety (runs the LLVM verifier after every transform).

Quick configs

# light
-mllvm -fla -mllvm -bcf -mllvm -mba -mllvm -split

# vm
-mllvm -vm-mode=opcode -mllvm -vm-encode=mba -mllvm -vm-select=all

# windows iat (safe default, keeps imports)
-mllvm -obf-iat -mllvm -obf-iat-backend=thunk

If you're turning on lots of transforms at once while bringing up a new target, add -mllvm -obf-verify (and optionally -mllvm -obf-dump-ir).

For reproducible builds, set -mllvm -obf-seed=<N>.

Building from source

If you want to modify the passes or build for a different target.

Full toolchain build + packaging (recommended):

• Windows: release/build_windows.ps1
• Linux (WSL/Linux): release/build_linux.sh

These scripts pin an LLVM commit, copy Kilij into llvm/lib/Transforms/Obfuscation, build clang/opt/lld + the Kilij pass plugin, then package release archives.

Standalone plugin (faster, needs existing LLVM 20):

cmake -S . -B build-obf -G Ninja \
  -DLLVM_DIR=/path/to/llvm/lib/cmake/llvm
ninja -C build-obf Kilij

More details: docs/BUILDING.md.

Configuration notes

Enable a small set of transforms and iterate. If you turn on many passes at once, use -obf-verify (and optionally -obf-dump-ir) while you bring up targets.

Passes

Flags are always -mllvm -<flag>.

• Flattening: -fla
• Bogus CFG: -bcf (-bcf_loop, -bcf_prob)
• Split: -split
• MBA: `-mba
