Yet Another (Super) Chip 8 Emulator

An Octo compatible XO Chip, Super Chip, and Chip 8 emulator.

What is it?
License
Installing
1. Ubuntu Installation
2. Windows Installation
Running
Customization
1. Keys
2. Debug Keys
ROM Compatibility
Further Documentation

What is it?

This project is a Chip 8 emulator written in Python 3. The original purpose of the project was to create a simple learning emulator that was well documented and coded in terms that were easy to understand. It was also an exercise to learn more about Python. The result is a simple command-line based Chip 8 emulator.

In addition to supporting Chip 8 ROMs, the emulator also supports the XO Chip and Super Chip specifications. Note that while there are no special flags that are needed to run an XO Chip, Super Chip, or normal Chip 8 ROM, there are other compatibility flags that may need to be set for the ROM to run properly. See the Quirks Modes documentation below for more information.

There are two other versions of the emulator written in different languages:

License

This project makes use of an MIT style license. Please see the file called LICENSE.

Installing

Copy the source files to a directory of your choice. In addition to the source, you will need the following required software packages:

I strongly recommend creating a virtual environment using the virtualenv builder as well as the virtualenvwrapper tools. With these tools, you can easily create a virtual sandbox to install pygame and run the emulator in, without touching your master Python environment.

Ubuntu Installation

The installation under Ubuntu 20.04 requires several different steps:

Install SDL libraries. The SDL (Simple DirectMedia Layer) libraries are used by PyGame to draw images on the screen. Several other dependencies are needed by SDL in order to install PyGame. To install the required SDL libraries (plus dependencies) from the command-line:
```
sudo apt install python3 python3-dev libsdl-dev libfreetype6-dev \
libsdl-image1.2-dev libsdl-mixer1.2-dev libsdl-ttf2.0-dev libsdl-sound1.2-dev \
libportmidi-dev
```
Install PIP. The pip package manager is used for managing Python packages. To install pip from the command-line:
```
sudo apt install python3-pip
```

(Optional) Install virtual environment support for Python:

Install virtual environment support:

pip3 install virtualenv
pip3 install virtualenvwrapper

First you must update your .bashrc file in the home directory and add a few lines to the bottom of that file:

cat >> ~/.bashrc << EOF
export VIRTUALENVWRAPPER_PYTHON=/usr/bin/python3
export WORKON_HOME=$HOME/.virtualenvs
export PATH=$PATH:$HOME/.local/bin
source $HOME/.local/bin/virtualenvwrapper.sh
EOF

Next you must source the .bashrc file:
```
source ~/.bashrc
```
Finally, you can create the environment:
```
mkvirtualenv chip8
```

Clone (or download) the Chip 8 emulator project:

sudo apt install git
git clone https://github.com/craigthomas/Chip8Python.git

Install the requirements from the project:
```
pip install -r requirements.txt
```

Windows Installation

Download and install Python 3.6.8 for Windows. Make sure that pip and Add python.exe to Path options are checked when performing the installation. Later versions of Python 3 are also likely to work correctly with the emulator.
(Optional) Install virtual environment support for Python. Run the following commands from a command prompt:
1. Install the virtual environment wrapper:
```
pip install virtualenv
pip install virtualenvwrapper-win
```
1. Create a new environment for the Chip 8 emulator:
```
mkvirtualenv chip8
```
Install Git for Windows.
Clone (or download) the source files from GitHub. Run the following commands in a command prompt window:
```
git clone https://github.com/craigthomas/Chip8Python.git
```
Install the requirements for the project. Run the following commands in a command prompt window in the directory where you cloned or downloaded the source files:
```
pip install -r requirements.txt
```

Running

Running a ROM

Note that if you created a virtual environment as detailed above, you will need to workon that environment before starting the emulator:

workon chip8

The command-line interface requires a single argument, which is the full path to a Chip 8 ROM. Run the following command in the directory where you cloned or downloaded the source files:

python yac8e.py /path/to/rom/filename

This will start the emulator with the specified ROM.

Screen Scale

The --scale switch will scale the size of the window (the original size at 1x scale is 64 x 32):

python yac8e.py /path/to/rom/filename --scale 10

The command above will scale the window so that it is 10 times the normal size.

Instructions Per Second

The --ticks switch will limit the number of instructions per second that the emulator is allowed to run. By default, the value is set to 1,000. Minimum values are 200. Use this switch to adjust the running time of ROMs that execute too quickly. For simplicity, each instruction is assumed to take the same amount of time.

python yac8e.py /path/to/rom/filename --ticks 2000

Quirks Modes

Over time, various extensions to the Chip8 mnemonics were developed, which resulted in an interesting fragmentation of the Chip8 language specification. As discussed in Octo's Mastering SuperChip documentation, one version of the SuperChip instruction set subtly changed the meaning of a few instructions from their original Chip8 definitions. This change went mostly unnoticed for many implementations of the Chip8 langauge. Problems arose when people started writing programs using the updated language model - programs written for "pure" Chip8 ceased to function correctly on emulators making use of the altered specification.

To address this issue, Octo implements a number of quirks modes so that all Chip8 software can run correctly, regardless of which specification was used when developing the Chip8 program. This same approach is used here, such that there are several quirks flags that can be passed to the emulator at startup to force it to run with adjustments to the language specification.

Additional quirks and their impacts on the running Chip8 interpreter are examined in great depth at Chromatophore's HP48-Superchip repository. Many thanks for this detailed explanation of various quirks found in the wild!

Shift Quirks

The --shift_quirks flag will change the way that register shift operations work. In the original language specification two registers were required: the destination register x, and the source register y. The source register y value was shifted one bit left or right, and stored in x. For example, shift left was defined as:

Vx = Vy << 1

However, with the updated language specification, the source and destination register are assumed to always be the same, thus the y register is ignored and instead the value is sourced from x as such:

Vx = Vx << 1

Index Quirks

The --index_quirks flag controls whether post-increments are made to the index register following various register based operaitons. For load (Fn65) and store (Fn55) register operations, the original specification for the Chip8 language results in the index register being post-incremented by the number of registers stored. With the Super Chip8 specification, this behavior is not always adhered to. Setting --index_quirks will prevent the post-in
