Py4JFML 1.0

A Python wrapper for JFML.

Py4JFML can be used in the same way of JFML (see JFML documentation). To see how to use Py4JFML, have a look at the example files in the testlib folder.

Installation

1. Download the file py4jfml-1.0.tar.gz from the dist folder

2. run

   $ pip3 install py4jfml-1.0.tar.gz

If you want to test the library, you can extract the testlib folder from the archive and execute one of the contained scripts. You should start JFML by running

java -cp "lib/*" jfml_entrypoint.JFML_EntryPoint

assuming that the four jar files are in the local folder. Then, you could run some examples:

$ python3 CreateInvertedPendulumMamdaniExampleXML1.py

This should carry out the follwing text (trunked):

FUZZY SYSTEM: invertedPendulum - MAMDANI
KNOWLEDGEBASE:
  *Angle - domain[0.0, 255.0] - input
	very negative -  trapezoid [a: 0.0, b: 0.0, c: 48.0, d: 88.0]
	negative -  triangular [a: 48.0, b: 88.0, c: 128.0]
	zero -  triangular [a: 88.0, b: 128.0, c: 168.0]
	positive -  triangular [a: 128.0, b: 168.0, c: 208.0]
	very positive -  trapezoid [a: 168.0, b: 208.0, c: 255.0, d: 255.0]
	very negative or negative -  trapezoid [a: 0.0, b: 0.0, c: 88.0, d: 128.0]
	positive or very positive -  trapezoid [a: 128.0, b: 168.0, c: 255.0, d: 255.0]

(...)

RULEBASE:
  *mamdani - rulebase1: OR=MAX; AND=MIN; ACTIVATION=MIN
	RULE 1: rule1 - (0.0) IF Angle IS very negative or negative AND ChangeAngle IS very negative or negative THEN Force IS very negative [weight=1.0]
	RULE 2: rule2 - (0.0) IF Angle IS very negative AND ChangeAngle IS zero THEN Force IS very negative [weight=1.0]
	RULE 3: rule3 - (0.0) IF Angle IS very negative AND ChangeAngle IS positive THEN Force IS negative [weight=1.0]
	RULE 4: rule4 - (0.0) IF Angle IS very negative AND ChangeAngle IS very positive THEN Force IS zero [weight=1.0]
(...)

Also, the file InvertedPendulumMamdani1.xml should be generated and written in the current directory.

Dependencies

Py4JFML depends on py4j, which is automatically downloaded and installed if necessary.

Licence

Py4JFML is released under GPLv3 licence.

Known issues

• Currently, Py4JFML does not implement the compatibility package of JFML. As a consequence, only the FML format is supported.
• In Windows, a Py4JNetworkError could arise when executing Py4JFML. This is a known issue of py4j and occurs when the library tries to shut down the py4j server before terminating. This problem does not affect the functionality of the library, but you may get a memory leakage due to the server still running after the program termination.

Changelog

0.1

First release

0.1.1

Installation documentation fix (pip)

1.0

First release. Interoperability experiment implemented.
