CloudFoundry User Account and Authentication (UAA) Server

The UAA is a multi-tenant identity management service, used in Cloud Foundry, but also available as a stand alone OAuth2 server. Its primary role is as an OAuth2 provider, issuing tokens for client applications to use when they act on behalf of Cloud Foundry users. It can also authenticate users with their Cloud Foundry credentials and can act as an SSO service using those credentials (or others). It has endpoints for managing user accounts and for registering OAuth2 clients, as well as various other management functions.

UAA Server

The authentication service is uaa. It's a plain Spring MVC webapp. Deploy as normal in Tomcat or your container of choice, or execute ./gradlew run (or ./gradlew bootRun) to run it directly from uaa directory in the source tree. When running with Gradle, it listens on port 8080 and the URL is http://localhost:8080/uaa

The UAA Server supports the APIs defined in the UAA-APIs document. To summarise:

1. The OAuth2 /oauth/authorize and /oauth/token endpoints

2. A /login_info endpoint to allow querying for required login prompts

3. A /check_token endpoint, to allow resource servers to obtain information about an access token submitted by an OAuth2 client.

4. A /token_key endpoint, to allow resource servers to obtain the verification key to verify token signatures

5. SCIM user provisioning endpoint

6. OpenID connect endpoints to support authentication /userinfo. Partial OpenID support.

Authentication can be performed by command line clients by submitting credentials directly to the /oauth/authorize endpoint (as described in UAA-API doc). There is an ImplicitAccessTokenProvider in Spring Security OAuth that can do the heavy lifting if your client is Java.

Use Cases

1. Authenticate

    GET /login


   A basic form login interface.

2. Approve OAuth2 token grant

    GET /oauth/authorize?client_id=app&response_type=code...


   Standard OAuth2 Authorization Endpoint.

3. Obtain access token

    POST /oauth/token


   Standard OAuth2 Authorization Endpoint.

Co-ordinates

• Tokens: A note on tokens, scopes and authorities
• Technical forum: cf-dev mailing list
• Docs: docs/
• API Documentation: http://docs.cloudfoundry.org/api/uaa/
• Specification: The OpenID Connect Core Framework including the Oauth 2 Authorization Framework
• LDAP: UAA LDAP Integration

Quick Start

Requirements:

• Java 21 or 25

If this works, you are in business:

$ git clone git://github.com/cloudfoundry/uaa.git
$ cd uaa
$ ./gradlew run

The apps all work together with the apps running on the same port (8080) as /uaa, /app and /api.

UAA will log to a file called uaa.log which can be found using the following command:

$ sudo lsof | grep uaa.log

which you should find under something like:-

scripts/boot/tomcat/logs/

Demo of command line usage on a local server

First, run the UAA server as described above:

$ ./gradlew run

From another terminal, you can use curl to verify that UAA has started by requesting system information:

$ curl --silent --show-error --head localhost:8080/uaa/login | head -1
HTTP/1.1 200

For complex requests it is more convenient to interact with UAA using uaac, the UAA Command Line Client.

Running as a Spring Boot Application

Three separate Gradle tasks can be used to run the Spring Boot application

• ./gradlew run — alias that kills any running UAA and starts the application (recommended)
• ./gradlew bootRun — the built-in Spring Boot Gradle task
• ./gradlew bootWarRun — use a JavaExec Gradle task to launch the runnable .war file
• Manual run, as show below, to be run after ./gradlew assemble
• Using ./scripts/boot/boot-with-tls.sh — runs http/8080 and https/8443

java -DCLOUDFOUNDRY_CONFIG_PATH=`pwd`/scripts/boot \
    -DSECRETS_DIR=`pwd`/scripts/boot \
    -Djava.security.egd=file:/dev/./urandom \
    -Dmetrics.perRequestMetrics=true \
    -Dserver.servlet.context-path=/uaa \
    -Dserver.tomcat.basedir=`pwd`/scripts/boot/tomcat \
    -Dlogging.config=`pwd`/scripts/boot/log4j2.properties \
    -Dsmtp.host=localhost \
    -Dsmtp.port=2525 \
    -Dspring.profiles.active=hsqldb \
    -Dstatsd.enabled=true \
    -Dfile.encoding=UTF-8 \
    -Duser.country=US \
    -Duser.language=en \
    -Duser.variant -jar `pwd`/uaa/build/libs/cloudfoundry-identity-uaa-0.0.0.war

Running Spring Boot standalone allows us to run the integration tests against it using the ./gradlew integrationTest with the system property preventing Gradle from starting up Apache Tomcat.

Debugging local server

To load JDWP agent for UAA jvm debugging, start the server as follows:

./gradlew run -Pdebug

You can then attach your debugger to port 5005 of the jvm process.

To suspend the server start-up until the debugger is attached (useful for debugging start-up code), start the server as follows:

./gradlew run -Pdebugs

Note: You can also use bootRun instead of run for these commands. To change the port that the debug command listens on, set the debugPort property, as follows:

./gradlew run -Pdebug -PdebugPort=5006

Running a local UAA server with different databases

./gradlew run (or ./gradlew bootRun) runs the UAA server with hsqldb database by default.

MySql

1. Start the mysql server (e.g. a mysql docker container)

% docker run --name mysql1 -e MYSQL_ROOT_PASSWORD=changeme -d -p3306:3306 mysql

2. Create the uaa database (e.g., in mysql interactive session)

% mysql -h 127.0.0.1 -u root -p
...
mysql> create database uaa;

3. Run the UAA server with the mysql profile

% ./gradlew -Dspring.profiles.active=mysql run

PostgreSQL

1. Start the postgresql server (e.g. a postgres docker container)

docker run --name postgres1 -p 5432:5432 -e POSTGRES_PASSWORD=mysecretpassword -d postgres

2. Create the uaa database (e.g. in psql interactive session)

% psql -h 127.0.0.1 -U postgres

create database uaa;
create user root with superuser password 'changeme';

3. Run the UAA server with the postgresql profile

% ./gradlew -Dspring.profiles.active=postgresql run

4. Once the UAA server started, you can see the tables created in the uaa database (e.g., in psql interactive session)

\c uaa
psql (14.5 (Homebrew), server 15.0 (Debian 15.0-1.pgdg110+1))
WARNING: psql major version 14, server major version 15.
         Some psql features might not work.
You are now connected to database "uaa" as user "postgres".
\d
List of relations
 Schema |             Name              |   Type   | Owner
--------+-------------------------------+----------+-------
 public | authz_approvals               | table    | root
 public | expiring_code_store           | table    | root
 public | external_group_mapping        | table    | root
 public | external_group_mapping_id_seq | sequence | root
 public | group_membership              | table    | root
 public | group_membership_id_seq       | sequence | root
 public | groups                        | table    | root
 public | identity_provider             | table    | root
 public | identity_zone                 | table    | root
 public | oauth_client_details          | table    | root
 public | oauth_code                    | table    | root
 public | oauth_code_id_seq             | sequence | root
 public | revocable_tokens              | table    | root
 public | schema_version                | table    | root
 public | sec_audit                     | table    | root
 public | sec_audit_id_seq              | sequence | root
 public | spring_session                | table    | root
 public | spring_session_attributes     | table    | root
 public | user_info                     | table    | root
 public | users                         | table    | root
(23 rows)

Running tests

You can run the integration tests with docker

$ run-integration-tests.sh <dbtype>

This will create a docker container running uaa + ldap + a database whereby integration tests are run against.

$ run-integration-tests.sh hsqldb boot

will create a docker container and run the integration tests against a Spring Boot instance using HSQLDB

Using Docker to test with postgresql or mysql

The default uaa unit tests (./gradlew test integrationTest) use hsqldb.

To run the unit tests with docker:

$ run-unit-tests.sh <dbtype>

Using Gradle to test with Postgres or MySQL

You need a locally running database. You can launch Postgres 15 and MySQL 8 locally with docker compose:

$ docker compose --file scripts/docker-compose.yml up

If you wish to launch only one of the DBs, select the appropriate service name:

$ docker compose --file scripts/docker-compose.yml up postgresql

Then run the test with the appropriate profile:

$ ./gradlew '-Dspring.profiles.active=postgresql' \
    --no-daemon \
    test

There are special guarantees in place to avoid pollution between tests, so be sure to run the images from the compose script, and run your test with --no-daemon. To learn more, read docs/testing.md.

To run a single test

The default uaa unit tests (./gradlew test) use hsqldb.

Start by finding out which Gradle project your test belongs to. You can find all projects by running

$ ./gradlew projects

To run a specific t
